3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for LM25118Q1MHE/NOPB by Texas Instruments
Results Overview of LM25118Q1MHE/NOPB by Texas Instruments
- Distributor Offerings: (5 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
LM25118Q1MHE/NOPB Information
LM25118Q1MHE/NOPB by Texas Instruments is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| DS96174CN/NOPB | Rochester Electronics LLC | DS96174 - Line Driver, 4 Func, 4 Driver, BIPolar, PDIP16 | |
| LM611IM/NOPB | Rochester Electronics LLC | LM611IM - Operational Amplifier, 7000uV Offset-Max, BIPolar |
Price & Stock for LM25118Q1MHE/NOPB
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-39604-1-ND
|
DigiKey | IC REG CTRLR BUCK 20TSSOP Min Qty: 1 Lead time: 12 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
414 In Stock |
|
$3.6036 / $6.3600 | Buy Now |
|
DISTI #
595-LM25118Q1MHENOPB
|
Mouser Electronics | Switching Controllers Wide Vtg Range Buck- Boost Cntlr A 595-LM25118Q1MH/NOPB RoHS: Compliant | 216 |
|
$3.6400 / $8.2200 | Buy Now |
|
DISTI #
J56:1989_04123380
|
Arrow Electronics | DC/DC Cntrlr Single-OUT Step Down/Step Up 500kHz Automotive AEC-Q100 20-Pin HTSSOP EP T/R RoHS: Compliant Min Qty: 250 Package Multiple: 250 Lead time: 12 Weeks | Europe - 250 |
|
$3.2940 / $3.8730 | Buy Now |
|
|
Quest Components | SWITCHING CONTROLLER, CURRENT-MODE, 10A, 500KHZ SWITCHING FREQ-MAX, PDSO20 | 190 |
|
$3.2400 / $8.1000 | Buy Now |
|
|
Vyrian | Other Function Semiconductors | 3875 |
|
RFQ |
Part Details for LM25118Q1MHE/NOPB
LM25118Q1MHE/NOPB CAD Models
LM25118Q1MHE/NOPB Part Data Attributes
|
|
LM25118Q1MHE/NOPB
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
LM25118Q1MHE/NOPB
Texas Instruments
3-42-V wide VIN, current mode non-synchronous buck-boost controller, AEC-Q100 qualified 20-HTSSOP -40 to 125
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Additional Feature | SEATED HGT-NOM | |
| Analog IC - Other Type | SWITCHING CONTROLLER | |
| Control Mode | CURRENT-MODE | |
| Control Technique | PULSE WIDTH MODULATION | |
| Input Voltage-Max | 42 V | |
| Input Voltage-Min | 3 V | |
| Input Voltage-Nom | 24 V | |
| JESD-30 Code | R-PDSO-G20 | |
| JESD-609 Code | e3 | |
| Length | 6.5 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 1 | |
| Number of Terminals | 20 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current-Max | 10 A | |
| Output Voltage-Max | 38 V | |
| Output Voltage-Min | 1.23 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HTSSOP | |
| Package Equivalence Code | TSSOP20,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Screening Level | AEC-Q100 | |
| Seated Height-Max | 1.1 mm | |
| Surface Mount | YES | |
| Switcher Configuration | BUCK-BOOST | |
| Switching Frequency-Max | 500 kHz | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 4.4 mm |
LM25118Q1MHE/NOPB Frequently Asked Questions (FAQ)
-
The maximum operating temperature range for the LM25118Q1MHE/NOPB is -40°C to 125°C.
-
To ensure the stability of the output voltage, it is recommended to use a minimum output capacitance of 10uF with an ESR of 1Ω or less, and to place the capacitor as close to the output pin as possible.
-
The recommended input capacitor value for the LM25118Q1MHE/NOPB is 10uF to 22uF, with an ESR of 1Ω or less.
-
Yes, the LM25118Q1MHE/NOPB is qualified for automotive and industrial applications, and is suitable for use in high-reliability systems.
-
The power dissipation of the LM25118Q1MHE/NOPB can be calculated using the formula: Pd = (Vin - Vout) x Iout, where Vin is the input voltage, Vout is the output voltage, and Iout is the output current.
