LM25118Q1MH/NOPB Information
LM25118Q1MH/NOPB by Texas Instruments is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| LM25118Q1MHX/NOPB | Texas Instruments | Automotive Grade, 3-42V Wide Vin, Current Mode Non-Synchronous Buck-Boost Controller 20-HTSSOP -40 to 125 | |
| LM25118Q1MHE/NOPB | Texas Instruments | Automotive Grade, 3-42V Wide Vin, Current Mode Non-Synchronous Buck-Boost Controller 20-HTSSOP -40 to 125 | |
| LM25118Q1MH/NOPB | Texas Instruments | Automotive Grade, 3-42V Wide Vin, Current Mode Non-Synchronous Buck-Boost Controller 20-HTSSOP -40 to 125 |
Price & Stock for LM25118Q1MH/NOPB
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
LM25118Q1MH/NOPB-ND
|
DigiKey | IC REG CTRLR BUCK 20TSSOP Min Qty: 219 Lead time: 12 Weeks Container: Tube | Temporarily Out of Stock |
|
$3.9415 | Buy Now |
|
DISTI #
595-LM25118Q1MH/NOPB
|
Mouser Electronics | Switching Controllers Wide Vtg Range Buck- Boost Cntlr A 595-LM25118Q1MHENOPB RoHS: Compliant | 219 |
|
$3.6400 / $8.2300 | Buy Now |
|
|
Greenchips | Date Code: 19+/MY | 410 |
|
$2.0040 / $2.5870 | Buy Now |
|
|
Greenchips | Date Code: 22+/MY | 211 |
|
$2.1380 / $2.7590 | Buy Now |
|
|
Greenchips | Date Code: N/A | 0 |
|
$2.0040 / $2.5870 | Buy Now |
|
|
Vyrian | Other Function Semiconductors | 15042 |
|
RFQ |
Part Details for LM25118Q1MH/NOPB
LM25118Q1MH/NOPB CAD Models
LM25118Q1MH/NOPB Part Data Attributes
|
|
LM25118Q1MH/NOPB
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
LM25118Q1MH/NOPB
Texas Instruments
3-42-V wide VIN, current mode non-synchronous buck-boost controller, AEC-Q100 qualified 20-HTSSOP -40 to 125
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Additional Feature | SEATED HGT-NOM | |
| Analog IC - Other Type | SWITCHING CONTROLLER | |
| Control Mode | CURRENT-MODE | |
| Control Technique | PULSE WIDTH MODULATION | |
| Input Voltage-Max | 42 V | |
| Input Voltage-Min | 3 V | |
| Input Voltage-Nom | 24 V | |
| JESD-30 Code | R-PDSO-G20 | |
| JESD-609 Code | e3 | |
| Length | 6.5 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 1 | |
| Number of Terminals | 20 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current-Max | 10 A | |
| Output Voltage-Max | 38 V | |
| Output Voltage-Min | 1.23 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HTSSOP | |
| Package Equivalence Code | TSSOP20,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Screening Level | AEC-Q100 | |
| Seated Height-Max | 1.1 mm | |
| Surface Mount | YES | |
| Switcher Configuration | BUCK-BOOST | |
| Switching Frequency-Max | 500 kHz | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 4.4 mm |
