LM12458CIVX/NOPB Information
LM12458CIVX/NOPB by Texas Instruments is an Other Signal Circuit.
Other Signal Circuits are under the broader part category of Signal Circuits.
A signal is an electronic means of transmitting information, either as an analog signal with continuous values or a digital signal with discrete values. Signals are used in various systems and networks. Read more about Signal Circuits on our Signal Circuits part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| LM12458CIVX/NOPB | Texas Instruments | 12-Bit Plus Sign Data Acquisition System with Self-Calibration 44-PLCC -40 to 85 | |
| DS96174CN/NOPB | Rochester Electronics LLC | DS96174 - Line Driver, 4 Func, 4 Driver, BIPolar, PDIP16 | |
| LM611IM/NOPB | Rochester Electronics LLC | LM611IM - Operational Amplifier, 7000uV Offset-Max, BIPolar |
Price & Stock for LM12458CIVX/NOPB
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
85989348
|
Verical | 8-Channel Single ADC SAR 114ksps 12-bit+Sign Parallel 44-Pin PLCC T/R RoHS: Compliant Min Qty: 25 Package Multiple: 1 Date Code: 1801 | Americas - 7900 |
|
$22.5625 | Buy Now |
|
DISTI #
85990289
|
Verical | 8-Channel Single ADC SAR 114ksps 12-bit+Sign Parallel 44-Pin PLCC T/R RoHS: Compliant Min Qty: 25 Package Multiple: 1 Date Code: 1301 | Americas - 6500 |
|
$22.5625 | Buy Now |
|
DISTI #
85997322
|
Verical | 8-Channel Single ADC SAR 114ksps 12-bit+Sign Parallel 44-Pin PLCC T/R RoHS: Compliant Min Qty: 25 Package Multiple: 1 Date Code: 1701 | Americas - 2000 |
|
$22.5625 | Buy Now |
|
|
Rochester Electronics | LM12458 12-Bit Plus Sign Data Acquisition System with Self-Calibration RoHS: Compliant Status: Obsolete Min Qty: 1 | 16400 |
|
$14.4400 / $18.0500 | Buy Now |
Part Details for LM12458CIVX/NOPB
LM12458CIVX/NOPB CAD Models
LM12458CIVX/NOPB Part Data Attributes
|
|
LM12458CIVX/NOPB
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
LM12458CIVX/NOPB
Texas Instruments
88 kSPS, 12-Bit Plus Sign Data Acquisition System with Self-Calibration 44-PLCC -40 to 85
|
| Rohs Code | No | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | LCC | |
| Package Description | GREEN, PLASTIC, LCC-44 | |
| Pin Count | 44 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Analog IC - Other Type | ANALOG CIRCUIT | |
| Input Voltage-Max | 5.5 V | |
| Input Voltage-Min | ||
| JESD-30 Code | S-PQCC-J44 | |
| JESD-609 Code | e3 | |
| Length | 16.585 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Channels | 8 | |
| Number of Functions | 1 | |
| Number of Terminals | 44 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | QCCJ | |
| Package Equivalence Code | LDCC44,.7SQ | |
| Package Shape | SQUARE | |
| Package Style | CHIP CARRIER | |
| Peak Reflow Temperature (Cel) | 245 | |
| Seated Height-Max | 4.57 mm | |
| Supply Voltage-Max (Vsup) | 3 V | |
| Supply Voltage-Min (Vsup) | 3 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | YES | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | J BEND | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 16.585 mm |
Alternate Parts for LM12458CIVX/NOPB
This table gives cross-reference parts and alternative options found for LM12458CIVX/NOPB. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of LM12458CIVX/NOPB, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| LM12458CIV | Texas Instruments | Check for Price | 12-Bit Plus Sign Data Acquisition System with Self-Calibration 44-PLCC -40 to 85 | LM12458CIVX/NOPB vs LM12458CIV |
| LM12458CIVX | Texas Instruments | Check for Price | SPECIALTY ANALOG CIRCUIT, PQCC44, PLASTIC, LCC-44 | LM12458CIVX/NOPB vs LM12458CIVX |
