Part Details for LDECB3100MA0N00 by KEMET Corporation
Results Overview of LDECB3100MA0N00 by KEMET Corporation
- Distributor Offerings: (2 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Renewable Energy
LDECB3100MA0N00 Information
LDECB3100MA0N00 by KEMET Corporation is a Film Capacitor.
Film Capacitors are under the broader part category of Capacitors.
A capacitor is a passive electronic component that stores energy. Capacitors are commonly used for energy storage, voltage suppression, and signal filtering. Read more about Capacitors on our Capacitors part category page.
Price & Stock for LDECB3100MA0N00
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
90AC4570
|
Newark | 0,33 U 50Vv |Kemet LDECB3100MA0N00 RoHS: Not Compliant Min Qty: 2250 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.2610 / $0.3490 | Buy Now |
|
DISTI #
LDECB3100MA0N00-ND
|
DigiKey | CAP FILM 0.1UF 20% 50VDC 1210 Min Qty: 2250 Lead time: 30 Weeks Container: Tape & Reel (TR) | Limited Supply - Call |
|
$0.3078 | Buy Now |
Part Details for LDECB3100MA0N00
LDECB3100MA0N00 CAD Models
LDECB3100MA0N00 Part Data Attributes
|
|
LDECB3100MA0N00
KEMET Corporation
Buy Now
Datasheet
|
Compare Parts:
LDECB3100MA0N00
KEMET Corporation
Film Capacitor, Polyethylene Naphthalate, 50V, 20% +Tol, 20% -Tol, 0.1uF, Surface Mount, 1210
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | KEMET ELECTRONICS CORP | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8532.25.00.45 | |
| Samacsys Manufacturer | KEMET | |
| Capacitance | 0.1 µF | |
| Capacitor Type | FILM CAPACITOR | |
| Dielectric Material | POLYETHYLENE NAPHTHALATE | |
| Height | 2.1 mm | |
| Length | 3.3 mm | |
| Mounting Feature | SURFACE MOUNT | |
| Negative Tolerance | 20% | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Shape | RECTANGULAR PACKAGE | |
| Package Style | SMT | |
| Packing Method | TR, PLASTIC, 7 INCH | |
| Positive Tolerance | 20% | |
| Rated (AC) Voltage (URac) | 40 V | |
| Rated (DC) Voltage (URdc) | 50 V | |
| Reference Standard | AEC-Q200 | |
| Size Code | 1210 | |
| Surface Mount | YES | |
| Terminal Shape | WRAPAROUND | |
| Width | 2.5 mm |
