Part Details for L7808ACV-DG by STMicroelectronics
Results Overview of L7808ACV-DG by STMicroelectronics
- Distributor Offerings: (4 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
L7808ACV-DG Information
L7808ACV-DG by STMicroelectronics is a Linear Regulator IC.
Linear Regulator ICs are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for L7808ACV-DG
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
497-15581-5-ND
|
DigiKey | IC REG LINEAR 8V 1.5A TO220 Min Qty: 1 Lead time: 99 Weeks Container: Tube |
617 In Stock |
|
$0.6896 / $1.4300 | Buy Now |
|
DISTI #
L7808ACV-DG
|
Avnet Americas | LDO Regulator Pos 8V 1.5A 3-Pin TO-220 Tube - Rail/Tube (Alt: L7808ACV-DG) RoHS: Compliant Min Qty: 3000 Package Multiple: 1000 Lead time: 111 Weeks, 0 Days Container: Tube | 0 |
|
RFQ | |
|
|
STMicroelectronics | Positive voltage regulator ICs RoHS: Compliant Min Qty: 1 | 1 |
|
$0.5000 / $0.9500 | Buy Now |
|
DISTI #
L7808ACV-DG
|
EBV Elektronik | LDO Regulator Pos 8V 15A 3Pin TO220 Tube (Alt: L7808ACV-DG) RoHS: Compliant Min Qty: 50 Package Multiple: 50 Lead time: 53 Weeks, 0 Days | EBV - 0 |
|
Buy Now |
Part Details for L7808ACV-DG
L7808ACV-DG CAD Models
L7808ACV-DG Part Data Attributes
|
|
L7808ACV-DG
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
L7808ACV-DG
STMicroelectronics
Positive voltage regulator ICs
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | STMICROELECTRONICS | |
| Package Description | TO-220, 3 PIN | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 111 Weeks | |
| Date Of Intro | 1980-01-04 | |
| Samacsys Manufacturer | STMicroelectronics | |
| Input Voltage-Max | 25 V | |
| Input Voltage-Min | 10.6 V | |
| JESD-30 Code | R-XSFM-T3 | |
| JESD-609 Code | e3 | |
| Number of Functions | 1 | |
| Number of Terminals | 3 | |
| Operating Temperature TJ-Max | 125 °C | |
| Operating Temperature TJ-Min | ||
| Output Current1-Max | 1.5 A | |
| Output Voltage1-Max | 8.3 V | |
| Output Voltage1-Min | 7.7 V | |
| Output Voltage1-Nom | 8 V | |
| Package Body Material | UNSPECIFIED | |
| Package Code | SFM | |
| Package Shape | RECTANGULAR | |
| Package Style | FLANGE MOUNT | |
| Packing Method | TUBE | |
| Regulator Type | FIXED POSITIVE SINGLE OUTPUT STANDARD REGULATOR | |
| Surface Mount | NO | |
| Technology | BIPOLAR | |
| Terminal Finish | MATTE TIN | |
| Terminal Form | THROUGH-HOLE | |
| Terminal Position | SINGLE | |
| Voltage Tolerance-Max | 3.8% |
L7808ACV-DG Frequently Asked Questions (FAQ)
-
The maximum input voltage that can be applied to the L7808ACV-DG is 35V, although it's recommended to keep it below 25V for optimal performance and reliability.
-
To ensure stability, make sure to use a minimum output capacitance of 10uF with an ESR (Equivalent Series Resistance) of less than 5 ohms, and keep the input capacitance as close to the regulator as possible.
-
The minimum input voltage required for the L7808ACV-DG to regulate the output voltage is around 10.5V, although it's recommended to keep it above 11V for optimal performance.
-
The L7808ACV-DG is rated for operation up to 150°C, but its performance and reliability may degrade at high temperatures. It's recommended to derate the output current and input voltage at high temperatures.
-
Use a TVS (Transient Voltage Suppressor) diode or a varistor in parallel with the input capacitor to protect the L7808ACV-DG from input voltage transients and spikes.
