IXEL40N400 Information
IXEL40N400 by Littelfuse Inc is an IGBT.
IGBTs are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for IXEL40N400
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
03AH0413
|
Newark | Igbt, 4Kv, 90A, 150Deg C, 380W, Continuous Collector Current:90A, Collector Emitter Saturation Voltage:2.4V, Power Dissipation:380W, Collector Emitter Voltage Max:4Kv, No. Of Pins:3Pins, Operating Temperature Max:150°C Rohs Compliant: Yes |Littelfuse IXEL40N400 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 143 |
|
$98.0500 / $103.8400 | Buy Now |
|
DISTI #
V36:1790_15876779
|
Arrow Electronics | Trans IGBT Chip N-CH 4000V 90A 380W 3-Pin(3+Tab) ISOPLUS I5-PAK Min Qty: 1 Package Multiple: 1 Lead time: 36 Weeks Date Code: 2241 | Americas - 1732 |
|
Buy Now | |
|
DISTI #
75577731
|
RS | Disc IGBT NPT-Very Hi Voltage ISOPLUS264 Min Qty: 25 Package Multiple: 1 Lead time: 8 Weeks, 0 Days Container: Bulk | 0 |
|
$154.7400 | RFQ |
|
DISTI #
68463869
|
Verical | Trans IGBT Chip N-CH 4000V 90A 380W 3-Pin(3+Tab) ISOPLUS I5-PAK Min Qty: 1 Package Multiple: 1 Date Code: 2241 | Americas - 1732 |
|
$45.5100 | Buy Now |
|
DISTI #
65266797
|
Verical | Trans IGBT Chip N-CH 4000V 90A 380W 3-Pin(3+Tab) ISOPLUS I5-PAK Min Qty: 1 Package Multiple: 1 | Americas - 143 |
|
$121.2487 / $145.2308 | Buy Now |
Part Details for IXEL40N400
IXEL40N400 CAD Models
IXEL40N400 Part Data Attributes
|
|
IXEL40N400
Littelfuse Inc
Buy Now
Datasheet
|
Compare Parts:
IXEL40N400
Littelfuse Inc
Insulated Gate Bipolar Transistor, 40A I(C), 4000V V(BR)CES, N-Channel, I5PAK-3
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | LITTELFUSE INC | |
| Package Description | I5PAK-3 | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| Samacsys Manufacturer | LITTELFUSE | |
| Case Connection | ISOLATED | |
| Collector Current-Max (IC) | 40 A | |
| Collector-Emitter Voltage-Max | 4000 V | |
| Configuration | SINGLE | |
| Gate-Emitter Thr Voltage-Max | 7 V | |
| Gate-Emitter Voltage-Max | 20 V | |
| JESD-30 Code | R-PSIP-T3 | |
| Number of Elements | 1 | |
| Number of Terminals | 3 | |
| Operating Temperature-Max | 125 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | IN-LINE | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Polarity/Channel Type | N-CHANNEL | |
| Power Dissipation-Max (Abs) | 380 W | |
| Qualification Status | Not Qualified | |
| Reference Standard | UL RECOGNIZED | |
| Surface Mount | NO | |
| Terminal Form | THROUGH-HOLE | |
| Terminal Position | SINGLE | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Transistor Application | GENERAL PURPOSE SWITCHING | |
| Transistor Element Material | SILICON | |
| Turn-off Time-Nom (toff) | 1170 ns | |
| Turn-on Time-Nom (ton) | 260 ns |
