IPA057N08N3GXKSA1 Information
IPA057N08N3GXKSA1 by Infineon Technologies AG is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for IPA057N08N3GXKSA1
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
34AC1645
|
Newark | Mosfet, N-Ch, 80V, 60A, To-220Fp, Transistor Polarity:N Channel, Continuous Drain Current Id:60A, Drain Source Voltage Vds:80V, On Resistance Rds(On):0.0049Ohm, Rds(On) Test Voltage Vgs:10V, Threshold Voltage Vgs:2.8V, Power Rohs Compliant: Yes |Infineon IPA057N08N3GXKSA1 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 0 |
|
$1.5900 / $3.1900 | Buy Now |
|
DISTI #
448-IPA057N08N3GXKSA1-ND
|
DigiKey | MOSFET N-CH 80V 60A TO220-FP Min Qty: 1 Lead time: 16 Weeks Container: Tube |
416 In Stock |
|
$0.9980 / $3.1000 | Buy Now |
|
DISTI #
IPA057N08N3GXKSA1
|
Avnet Americas | - Rail/Tube (Alt: IPA057N08N3GXKSA1) RoHS: Compliant Min Qty: 500 Package Multiple: 500 Lead time: 16 Weeks, 0 Days Container: Tube | 0 |
|
$0.8331 / $0.8763 | Buy Now |
|
DISTI #
69266337
|
Verical | Trans MOSFET N-CH 80V 60A 3-Pin(3+Tab) TO-220FP Tube RoHS: Compliant Min Qty: 26 Package Multiple: 1 Date Code: 2314 | Americas - 1500 |
|
$1.1300 / $2.4400 | Buy Now |
|
DISTI #
87836651
|
Verical | Trans MOSFET N-CH 80V 60A 3-Pin(3+Tab) TO-220FP Tube RoHS: Compliant Min Qty: 221 Package Multiple: 1 Date Code: 2301 | Americas - 311 |
|
$1.0505 / $1.7000 | Buy Now |
|
|
Rochester Electronics | IPA057N08 - N-Channel Power MOSFET RoHS: Compliant Status: Active Min Qty: 1 | 341 |
|
$0.8404 / $1.3600 | Buy Now |
|
DISTI #
IPA057N08N3GXKSA1
|
TME | Transistor: N-MOSFET, unipolar, 80V, 60A, 39W, TO220FP Min Qty: 1 | 0 |
|
$0.8600 / $1.3300 | RFQ |
|
DISTI #
IPA057N08N3GXKSA1
|
IBS Electronics | SINGLE N-CHANNEL 80 V 5.7 MOHM 52 NC OPTIMOS™, POWER MOSFET - TO-220-3FP Min Qty: 500 Package Multiple: 1 | 0 |
|
$1.2025 / $1.2610 | Buy Now |
|
DISTI #
IPA057N08N3GXKSA1
|
Chip One Stop | Semiconductors RoHS: Compliant pbFree: Yes Min Qty: 1 Lead time: 0 Weeks, 1 Days Container: Tube | 1500 |
|
$1.0300 / $2.7500 | Buy Now |
|
DISTI #
SP000454442
|
EBV Elektronik | Power MOSFET N Channel 80 V 60 A 00049 ohm TO220FP Through Hole (Alt: SP000454442) RoHS: Compliant Min Qty: 500 Package Multiple: 500 Lead time: 17 Weeks, 0 Days | EBV - 0 |
|
Buy Now |
Part Details for IPA057N08N3GXKSA1
IPA057N08N3GXKSA1 CAD Models
IPA057N08N3GXKSA1 Part Data Attributes
|
|
IPA057N08N3GXKSA1
Infineon Technologies AG
Buy Now
Datasheet
|
Compare Parts:
IPA057N08N3GXKSA1
Infineon Technologies AG
Power Field-Effect Transistor, 60A I(D), 80V, 0.0057ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-220AB, GREEN, PLASTIC, TO-220FP, 3 PIN
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | INFINEON TECHNOLOGIES AG | |
| Part Package Code | TO-220AB | |
| Package Description | GREEN, PLASTIC, TO-220FP, 3 PIN | |
| Pin Count | 3 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 16 Weeks | |
| Samacsys Manufacturer | Infineon | |
| Avalanche Energy Rating (Eas) | 290 mJ | |
| Case Connection | ISOLATED | |
| Configuration | SINGLE WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 80 V | |
| Drain Current-Max (ID) | 60 A | |
| Drain-source On Resistance-Max | 0.0057 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| JEDEC-95 Code | TO-220AB | |
| JESD-30 Code | R-PSFM-T3 | |
| JESD-609 Code | e3 | |
| Number of Elements | 1 | |
| Number of Terminals | 3 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 175 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | FLANGE MOUNT | |
| Polarity/Channel Type | N-CHANNEL | |
| Pulsed Drain Current-Max (IDM) | 240 A | |
| Qualification Status | Not Qualified | |
| Surface Mount | NO | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | THROUGH-HOLE | |
| Terminal Position | SINGLE | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON |
