HSMS-C280 Information
HSMS-C280 by Avago Technologies is a Visible LED.
Visible LEDs are under the broader part category of Optoelectronics.
Optoelectronic components work to detect, generate, and control light. They can essentially produce and/or react to light. Read more about Optoelectronics on our Optoelectronics part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| 54HC280/B2A | Rochester Electronics LLC | 54HC280 - Parity Generator/Checker, CMOS, LCC. Dual Marked (86077012A) | |
| SN54HC280J/B | Rochester Electronics LLC | SN54HC280J - PARITY GENERATOR/CHECKER, 9-BIT ODD/EVEN | |
| FCE17B25SC280 | Amphenol Communications Solutions | Filter D-Sub Connectors, Input Output Connectors, FCE17 series, 25pin, Socket, 47000pF |
Part Details for HSMS-C280
HSMS-C280 CAD Models
HSMS-C280 Part Data Attributes
|
|
HSMS-C280
Avago Technologies
Buy Now
Datasheet
|
Compare Parts:
HSMS-C280
Avago Technologies
SINGLE COLOR LED, HIGH EFFICIENCY RED, 1mm, 1 X 0.50 MM, 0.40 MM HEIGHT, PLASTIC, MINIATURE, SMT, 2 PIN
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | AVAGO TECHNOLOGIES INC | |
| Package Description | 1 X 0.50 MM, 0.40 MM HEIGHT, PLASTIC, MINIATURE, SMT, 2 PIN | |
| Reach Compliance Code | compliant | |
| HTS Code | 8541.40.20.00 | |
| Samacsys Manufacturer | Avago Technologies | |
| Color | HIGH EFFICIENCY RED | |
| Color@Wavelength | Orange | |
| Configuration | SINGLE | |
| Forward Current-Max | 0.02 A | |
| Forward Voltage-Max | 2.6 V | |
| JESD-609 Code | e4 | |
| Lens Type | UNTINTED DIFFUSED | |
| Luminous Intensity-Nom | 10.0 mcd | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Functions | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -30 °C | |
| Optoelectronic Device Type | SINGLE COLOR LED | |
| Overall Height | 0.4 mm | |
| Packing Method | TR, 7 INCH | |
| Peak Wavelength | 630 nm | |
| Reverse Voltage-Max | 5 V | |
| Shape | RECTANGULAR | |
| Size | 1 mm | |
| Surface Mount | YES | |
| Terminal Finish | GOLD OVER NICKEL | |
| Terminal Pitch | 1 mm | |
| Viewing Angle | 130 deg |
