Power Circuits / Power Supply Modules / HDR-30-24
Datasheets
HDR-30-24 by:

AC-DC Regulated Power Supply Module,

Part Details for HDR-30-24 by Mean Well

Results Overview of HDR-30-24 by Mean Well

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Education and Research Computing and Data Storage Aerospace and Defense Agriculture Technology Robotics and Drones

HDR-30-24 Information

HDR-30-24 by Mean Well is a Power Supply Module.
Power Supply Modules are under the broader part category of Power Circuits.

A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.

Price & Stock for HDR-30-24

Part # Distributor Description Stock Price Buy
DISTI # 44AC5203
Newark Power Supply, Ac-Dc, 24V, 1.5A, Power Supply Applications:Ite, No. Of Outputs:1 Output, Output Power Max:36W, Output Voltage - Output 1:24V, Output Current - Output 1:1.5A, Output Voltage - Output 2:-, Output Current - Output 2:- Rohs Compliant: Yes |Mean Well HDR-30-24 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk 1586
  • 1 $19.3800
  • 10 $18.9900
  • 25 $18.6000
  • 50 $18.0200
  • 100 $17.4400
  • 250 $16.8600
  • 500 $16.2800
$16.2800 / $19.3800 Buy Now
DISTI # 1866-2244-ND
DigiKey AC/DC DIN RAIL SUPPLY 24V 36W Min Qty: 1 Lead time: 12 Weeks Container: Box 405
In Stock
  • 1 $19.0400
  • 5 $17.3980
  • 10 $16.7340
  • 25 $15.8964
$15.8964 / $19.0400 Buy Now
DISTI # HDR-30-24
Avnet Americas AC/DC Power Supply Single-OUT 24V 1.5A 36W - Boxed Product (Development Kits) (Alt: HDR-30-24) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 19 Weeks, 3 Days Container: Box 0
  • 1 $14.8000
  • 5 $14.1000
  • 10 $13.5000
  • 20 $13.1000
$13.1000 / $14.8000 Buy Now
DISTI # 709-HDR30-24
Mouser Electronics DIN Rail Power Supplies 36W 24V 1.5A Class II DIN Rail RoHS: Compliant 961
  • 1 $17.4000
  • 10 $16.6400
  • 25 $15.9000
  • 96 $15.2000
  • 288 $14.6400
$14.6400 / $17.4000 Buy Now
DISTI # E54:1762_10951939
Arrow Electronics AC/DC Power Supply Single-OUT 24V 1.5A 36W 4-Pin RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 25 Weeks Date Code: 2449 Europe - 1454
  • 1 $14.9500
  • 5 $14.4500
$14.4500 / $14.9500 Buy Now
DISTI # 70971523
RS Power Supply, AC-DC, DIN Rail, 36W, 24V,1.5A, 85-264V In, Industrial Min Qty: 1 Package Multiple: 1 Lead time: 16 Weeks, 0 Days Container: Bulk 523
  • 1 $38.2200
  • 10 $36.6900
  • 25 $35.5500
  • 50 $34.4000
  • 100 $33.2500
$33.2500 / $38.2200 Buy Now
Future Electronics HDR Series 36W 24V Power Supply RoHS: Compliant pbFree: Yes Min Qty: 1 Package Multiple: 1 Lead time: 16 Weeks Container: Tray 9
Tray
  • 1 $15.5400
  • 3 $15.3500
  • 10 $15.1500
  • 20 $15.0300
  • 40 $14.8000
$14.8000 / $15.5400 Buy Now
Onlinecomponents.com AC/DC Power Supply - 1 Output - 24V@1.5A - 36W RoHS: Compliant 1359 In Stock
263 Factory Stock
  • 1 $14.8000
  • 5 $14.1000
  • 10 $13.5000
  • 20 $13.1000
$13.1000 / $14.8000 Buy Now
DISTI # 87510425
Verical AC/DC Power Supply Single-OUT 24V 1.5A 36W 4-Pin RoHS: Compliant Min Qty: 5 Package Multiple: 1 Americas - 6257
  • 5 $17.0500
  • 10 $14.8470
$14.8470 / $17.0500 Buy Now
DISTI # 86360437
Verical AC/DC Power Supply Single-OUT 24V 1.5A 36W 4-Pin RoHS: Compliant Min Qty: 4 Package Multiple: 1 Date Code: 2436 Americas - 1319
  • 4 $18.3259
  • 5 $17.0500
  • 10 $16.3037
  • 20 $15.7742
$15.7742 / $18.3259 Buy Now
DISTI # 87176528
Verical AC/DC Power Supply Single-OUT 24V 1.5A 36W 4-Pin RoHS: Compliant Min Qty: 3 Package Multiple: 1 Americas - 18
  • 3 $14.9000
  • 5 $14.7000
  • 10 $13.7000
$13.7000 / $14.9000 Buy Now
Future Electronics HDR Series 36W 24V Power Supply Min Qty: 1 Package Multiple: 1 9
null
  • 1 $15.5400
  • 3 $15.3500
  • 10 $15.1500
  • 20 $15.0300
  • 40 $14.8000
$14.8000 / $15.5400 Buy Now
DISTI # HDR-30-24
TME Power supply: switching, for DIN rail, 36W, 24VDC, 1.5A, 85÷264VAC Min Qty: 1 75
  • 1 $14.8000
  • 5 $14.1000
  • 10 $13.5000
  • 20 $13.1000
$13.1000 / $14.8000 Buy Now
DISTI # HDR-30-24
IBS Electronics POWER SUPPLY AC-DC DIN RAIL 36W 24V 1.5A 85-264V IN INDUSTRIAL | MEAN WELL HDR-30-24 Min Qty: 1 Package Multiple: 1 1368
  • 1 $19.2400
  • 3 $19.9550
  • 10 $17.5500
  • 20 $17.0300
  • 40 $19.2400
$17.0300 / $19.9550 Buy Now
DISTI # 000000000005553391
Sager DIN Rail Power Supplies 36W 24V 1.5A Class II DIN Rail Min Qty: 1 770
  • 1 $14.8000
  • 5 $14.1000
  • 10 $13.5000
  • 20 $13.1000
$13.1000 / $14.8000 Buy Now
DISTI # HDR-30-24
Chip One Stop Electromechanicals RoHS: Compliant Min Qty: 1 Lead time: 0 Weeks, 1 Days Container: Bulk 18
  • 1 $14.9000
  • 5 $14.7000
  • 10 $13.7000
  • 100 $13.2000
$13.2000 / $14.9000 Buy Now
Master Electronics AC/DC Power Supply - 1 Output - 24V@1.5A - 36W RoHS: Compliant 1359 In Stock
263 Factory Stock
  • 1 $14.8000
  • 5 $14.1000
  • 10 $13.5000
  • 20 $13.1000
$13.1000 / $14.8000 Buy Now

Part Details for HDR-30-24

HDR-30-24 Part Data Attributes

Parametric Data
HDR-30-24 Mean Well
Buy Now Datasheet
Compare Parts:
HDR-30-24 Mean Well AC-DC Regulated Power Supply Module,
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer MEAN WELL ENTERPRISES CO LTD
Package Description PACKAGE-5
Reach Compliance Code compliant
ECCN Code EAR99
Factory Lead Time 19 Weeks, 3 Days
Samacsys Manufacturer Mean Well
Additional Feature ALSO OPERATES AT 277 VAC AND FROM 120-370 VDC
Analog IC - Other Type AC-DC REGULATED POWER SUPPLY MODULE
Approvals CB, CE, EAC, EN, IEC, TUV, UL
Control Mode VOLTAGE-MODE
Efficiency (Main Output) 89%
Input Voltage-Max 264 V
Input Voltage-Min 85 V
Input Voltage-Nom 115 V
JESD-30 Code R-XXMA-X5
Line Regulation-Max 1%
Load Regulation-Max 1%
Number of Functions 1
Number of Outputs 1
Number of Terminals 5
Operating Temperature-Max 70 °C
Operating Temperature-Min -30 °C
Output Current-Max 1.5 A
Output Voltage-Max 29 V
Output Voltage-Min 21.6 V
Output Voltage-Nom 24 V
Package Body Material UNSPECIFIED
Package Code XMA
Package Shape RECTANGULAR
Package Style MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Cel) NOT SPECIFIED
Protections OVER LOAD; OVER VOLTAGE; SHORT CIRCUIT
Ripple Voltage (Main Out) 0.053025 Vrms
Surface Mount NO
Technology HYBRID
Temperature Grade OTHER
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Total Power Output-Max 36 W
Trim/Adjustable Output YES

HDR-30-24 Frequently Asked Questions (FAQ)

  • The maximum operating temperature range for the HDR-30-24 is -20°C to 60°C, with a derating of 2.5% per °C above 40°C.

  • Yes, the HDR-30-24 is designed to operate in a humid environment, with a relative humidity of up to 95% non-condensing.

  • The HDR-30-24 requires a minimum load of 10% of the maximum rated output current to maintain stable operation.

  • No, the HDR-30-24 is not designed for parallel operation. Attempting to parallel multiple units may result in unstable operation or damage to the power supplies.

  • The hold-up time for the HDR-30-24 is approximately 16ms, which is the time the power supply can maintain output voltage regulation during a brief input power interruption.
