Part Details for GS2961AIBE3 by Semtech Corporation
Results Overview of GS2961AIBE3 by Semtech Corporation
- Distributor Offerings: (6 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Price & Stock for GS2961AIBE3
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
06X0131
|
Newark | Hd/Sd Sdi Receiver, 3Gbps, Bga-100, Ic Type:Sdi Integrated Receiver, Supply Voltage Min:3.13V, Supply Voltage Max:3.47V, Ic Case/Package:Bga, No. Of Pins:100Pins, Operating Temperature Min:-20°C, Operating Temperature Max:85°C Rohs Compliant: Yes |Semtech GS2961AIBE3 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 213 |
|
$47.3300 | Buy Now |
|
DISTI #
GS2961AIBE3-ND
|
DigiKey | IC VIDEO RECEIVER 100BGA Min Qty: 1 Lead time: 16 Weeks Container: Tray |
2780 In Stock |
|
$55.4703 / $76.0700 | Buy Now |
|
DISTI #
947-GS2961AIBE3
|
Mouser Electronics | Video ICs 3G SDI Receiver - with EQ, no audio RoHS: Compliant | 204 |
|
$50.2900 / $57.0100 | Buy Now |
|
DISTI #
GS2961AIBE3
|
Avnet Silica | Receiver with Adaptive Cable Equalizer 100Pin BGA (Alt: GS2961AIBE3) RoHS: Compliant Min Qty: 168 Package Multiple: 168 Lead time: 18 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
|
Braemac Americas-Symmetry | 3G SDI Receiver - with EQ, no audio Min Qty: 1 | In Stock |
|
$42.0000 / $52.0000 | Buy Now |
|
|
Vyrian | General Purpose ICs | 341 |
|
RFQ |
Part Details for GS2961AIBE3
GS2961AIBE3 CAD Models
GS2961AIBE3 Part Data Attributes
|
|
GS2961AIBE3
Semtech Corporation
Buy Now
Datasheet
|
Compare Parts:
GS2961AIBE3
Semtech Corporation
Consumer Circuit,
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | SEMTECH CORP | |
| Package Description | BGA-100 | |
| Reach Compliance Code | unknown | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | SEMTECH | |
| Consumer IC Type | CONSUMER CIRCUIT | |
| JESD-30 Code | S-PBGA-B100 | |
| Length | 11 mm | |
| Number of Functions | 1 | |
| Number of Terminals | 100 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -20 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | LBGA | |
| Package Equivalence Code | BGA100,10X10,40 | |
| Package Shape | SQUARE | |
| Package Style | GRID ARRAY, LOW PROFILE | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Seated Height-Max | 1.7 mm | |
| Supply Voltage-Max (Vsup) | 1.26 V | |
| Supply Voltage-Min (Vsup) | 1.14 V | |
| Surface Mount | YES | |
| Temperature Grade | OTHER | |
| Terminal Form | BALL | |
| Terminal Pitch | 1 mm | |
| Terminal Position | BOTTOM | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Width | 11 mm |
