FDMS86540 Information
FDMS86540 by onsemi is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for FDMS86540
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
46AC8817
|
Newark | Mosfet, N-Ch, 60V, 129A, Power 56, Channel Type:N Channel, Drain Source Voltage Vds:60V, Continuous Drain Current Id:129A, Transistor Mounting:Surface Mount, Rds(On) Test Voltage:10V, Gate Source Threshold Voltage Max:3.2V Rohs Compliant: Yes |Onsemi FDMS86540 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 5878 |
|
$1.4400 / $1.9000 | Buy Now |
|
DISTI #
95T0007
|
Newark | Fet 60V 3.4 Mohm Pqfn56/Reel Rohs Compliant: Yes |Onsemi FDMS86540 RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.7400 / $0.9210 | Buy Now |
|
DISTI #
FDMS86540CT-ND
|
DigiKey | MOSFET N-CH 60V 20A/50A 8PQFN Min Qty: 1 Lead time: 14 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
27303 In Stock |
|
$0.7213 / $2.0000 | Buy Now |
|
DISTI #
FDMS86540
|
Avnet Americas | Trans MOSFET N-CH 60V 20A 8-Pin Power 56 T/R - Tape and Reel (Alt: FDMS86540) RoHS: Compliant Min Qty: 962 Package Multiple: 1 Lead time: 0 Weeks, 2 Days Container: Reel | 74650 Partner Stock |
|
$0.6319 / $0.6893 | Buy Now |
|
DISTI #
FDMS86540
|
Avnet Americas | Trans MOSFET N-CH 60V 20A 8-Pin Power 56 T/R - Tape and Reel (Alt: FDMS86540) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 14 Weeks, 0 Days Container: Reel | 0 |
|
$0.6453 / $0.6689 | Buy Now |
|
DISTI #
512-FDMS86540
|
Mouser Electronics | MOSFETs 60V N-Channel PowerTrench MOSFET RoHS: Compliant | 6994 |
|
$0.7120 / $1.9600 | Buy Now |
|
DISTI #
V72:2272_06338214
|
Arrow Electronics | Trans MOSFET N-CH 60V 20A 8-Pin PQFN EP T/R Min Qty: 1 Package Multiple: 1 Lead time: 14 Weeks Date Code: 2235 Container: Cut Strips | Americas - 761 |
|
$0.7034 / $0.7632 | Buy Now |
|
|
Onlinecomponents.com | PT7 60V/20V Nch PowerTrench Mosfet - 8LD, PQFN, JEDEC MO-240 AA, 5.0X6.0MM RoHS: Compliant | 0 |
|
$0.6900 / $1.0400 | Buy Now |
|
DISTI #
85980658
|
Verical | Trans MOSFET N-CH 60V 20A 8-Pin PQFN EP T/R Min Qty: 323 Package Multiple: 1 Date Code: 2201 | Americas - 1128 |
|
$0.9638 / $1.1611 | Buy Now |
|
DISTI #
63487341
|
Verical | Trans MOSFET N-CH 60V 20A 8-Pin PQFN EP T/R Min Qty: 9 Package Multiple: 1 Date Code: 2235 | Americas - 761 |
|
$0.7034 / $0.7512 | Buy Now |
Part Details for FDMS86540
FDMS86540 CAD Models
FDMS86540 Part Data Attributes
|
|
FDMS86540
onsemi
Buy Now
Datasheet
|
Compare Parts:
FDMS86540
onsemi
N-Channel PowerTrench® MOSFET 60V, 129A, 3.4mΩ, PQFN-8, 3000-REEL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | PQFN-8 | |
| Package Description | ROHS COMPLIANT, POWER 56, 8 PIN | |
| Manufacturer Package Code | 483AE | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 2 Days | |
| Samacsys Manufacturer | onsemi | |
| Avalanche Energy Rating (Eas) | 228 mJ | |
| Case Connection | DRAIN | |
| Configuration | SINGLE WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 60 V | |
| Drain Current-Max (ID) | 20 A | |
| Drain-source On Resistance-Max | 0.0034 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| JEDEC-95 Code | MO-240AA | |
| JESD-30 Code | R-PDSO-F5 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 5 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 150 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity/Channel Type | N-CHANNEL | |
| Power Dissipation-Max (Abs) | 96 W | |
| Pulsed Drain Current-Max (IDM) | 350 A | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) - annealed | |
| Terminal Form | FLAT | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON |
