FDMB2307NZ Information
FDMB2307NZ by onsemi is a Small Signal Field-Effect Transistor.
Small Signal Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for FDMB2307NZ
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
94T9954
|
Newark | Dual Commondrain N-Ch. Po/Reel |Onsemi FDMB2307NZ RoHS: Not Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
Buy Now | |
|
DISTI #
FDMB2307NZFSCT-ND
|
DigiKey | MOSFET 2N-CH 6MLP Min Qty: 1 Lead time: 21 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
8865 In Stock |
|
$0.3370 / $1.4100 | Buy Now |
|
DISTI #
FDMB2307NZ
|
Avnet Americas | Transistor MOSFET Array Dual N-CH 20V 9.7A 6-Pin MLP T/R - Tape and Reel (Alt: FDMB2307NZ) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 111 Weeks, 0 Days Container: Reel | 0 |
|
RFQ | |
|
|
Rochester Electronics | Small Signal Field-Effect Transistor, 2-Element, N-Channel, MOSFET RoHS: Compliant Status: End of Life / Last Time Buy Min Qty: 1 | 158 |
|
$0.2831 / $0.4566 | Buy Now |
|
DISTI #
FDMB2307NZ
|
TME | Transistor: N-MOSFET x2, unipolar, 20V, 9.7A, Idm: 40A, 2.2W, WDFN8 Min Qty: 1 | 0 |
|
$0.4410 / $0.7280 | RFQ |
|
DISTI #
FDMB2307NZ
|
Richardson RFPD | POWER MOSFET TRANSISTOR RoHS: Compliant Min Qty: 1 | 0 |
|
RFQ |
Part Details for FDMB2307NZ
FDMB2307NZ CAD Models
FDMB2307NZ Part Data Attributes
|
|
FDMB2307NZ
onsemi
Buy Now
Datasheet
|
Compare Parts:
FDMB2307NZ
onsemi
Dual Common Drain N-Channel PowerTrench® MOSFET 20V , 9.7A, 16.5mΩ, WDFN-6, 3000-REEL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | WDFN-6 | |
| Package Description | 3 X 2 MM, 0.80 MM HEIGHT, ROHS COMPLIANT, MLP, 6 PIN | |
| Manufacturer Package Code | 511CX | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 111 Weeks | |
| Samacsys Manufacturer | onsemi | |
| Case Connection | DRAIN | |
| Configuration | COMMON DRAIN, 2 ELEMENTS WITH BUILT-IN DIODE | |
| Drain Current-Max (ID) | 9.7 A | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| Feedback Cap-Max (Crss) | 320 pF | |
| JESD-30 Code | R-PDSO-N6 | |
| JESD-609 Code | e4 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 2 | |
| Number of Terminals | 6 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 150 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity/Channel Type | N-CHANNEL | |
| Power Dissipation-Max (Abs) | 2.2 W | |
| Surface Mount | YES | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | NO LEAD | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON |
