ERJS020R00X Information
ERJS020R00X by Panasonic Electronic Components is a Metal Glaze/Thick Film Resistor.
Metal Glaze/Thick Film Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for ERJS020R00X
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
85AK4535
|
Newark | Res, Jumper, 1A, Thick Film, 0402, Resistor Case/Package:0402 [1005 Metric], Resistor Technology:Thick Film, Power Rating:100Mw, Current Rating:1A, Product Range:Erj-S02 Series, Product Length:1.02Mm, Product Width:0.5Mm Rohs Compliant: Yes |Panasonic ERJS020R00X RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 14085 |
|
$0.0360 / $0.0430 | Buy Now |
|
DISTI #
83AK4411
|
Newark | Res, Jumper, 1A, Thick Film, 0402, Resistor Case/Package:0402 [1005 Metric], Resistor Technology:Thick Film, Power Rating:100Mw, Current Rating:1A, Product Range:Erj-S02 Series, Product Length:1.02Mm, Product Width:0.5Mm Rohs Compliant: Yes |Panasonic ERJS020R00X RoHS: Compliant Min Qty: 10000 Package Multiple: 1 Date Code: 1 Container: Reel | 0 |
|
$0.0330 / $0.0350 | Buy Now |
|
|
Quest Components | FIXED RESISTOR, METAL GLAZE/THICK FILM, 0.1W, 0OHM, SURFACE MOUNT, 0402 | 4064 |
|
$0.0378 / $0.0840 | Buy Now |
|
|
Quest Components | FIXED RESISTOR, METAL GLAZE/THICK FILM, 0.1W, 0OHM, SURFACE MOUNT, 0402 (Also Known As: ERJ-S020R00X) | 4064 |
|
$0.0378 / $0.0840 | Buy Now |
|
DISTI #
ERJS020R00X
|
TME | Resistor: thick film, SMD, 0402, 0Ω, 63mW, -55÷155°C Min Qty: 10000 | 0 |
|
$0.0317 | RFQ |
|
DISTI #
ERJS020R00X
|
Avnet Abacus | Zero Ohm Resistor Jumper 0402 1005 Metric Thick Film 100 mW 1 A Surface Mount Device - Tape and Reel (Alt: ERJS020R00X) RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Lead time: 21 Weeks, 0 Days Container: Reel | Abacus - 0 |
|
Buy Now |
Part Details for ERJS020R00X
ERJS020R00X CAD Models
ERJS020R00X Part Data Attributes
|
|
ERJS020R00X
Panasonic Electronic Components
Buy Now
Datasheet
|
Compare Parts:
ERJS020R00X
Panasonic Electronic Components
Fixed Resistor, Metal Glaze/thick Film, 0.1W, 0ohm, Surface Mount, 0402, CHIP, ROHS COMPLIANT
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | PANASONIC CORP | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8533.21.00.30 | |
| Factory Lead Time | 15 Weeks | |
| Samacsys Manufacturer | Panasonic | |
| Additional Feature | ANTI-SULFUR, RATED CURRENT: 1A | |
| Construction | Rectangular | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 155 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Height | 0.35 mm | |
| Package Length | 1 mm | |
| Package Shape | RECTANGULAR PACKAGE | |
| Package Style | SMT | |
| Package Width | 0.5 mm | |
| Packing Method | TR, PUNCHED, 7 INCH | |
| Rated Power Dissipation (P) | 0.1 W | |
| Rated Temperature | 70 °C | |
| Reference Standard | AEC-Q200, IEC60115-8 | |
| Resistance | ||
| Resistor Type | JUMPER | |
| Size Code | 0402 | |
| Surface Mount | YES | |
| Technology | METAL GLAZE/THICK FILM | |
| Terminal Finish | MATTE TIN OVER NICKEL | |
| Terminal Shape | WRAPAROUND |
