EEVFK1K680Q Information
EEVFK1K680Q by Panasonic Electronic Components is an Aluminum Electrolytic Capacitor.
Aluminum Electrolytic Capacitors are under the broader part category of Capacitors.
A capacitor is a passive electronic component that stores energy. Capacitors are commonly used for energy storage, voltage suppression, and signal filtering. Read more about Capacitors on our Capacitors part category page.
Price & Stock for EEVFK1K680Q
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
73AC6939
|
Newark | Cap, 68Μf, 80V, Radial, Smd, Ae Capacitor Case:Radial Can - Smd, Capacitance:68Μf, Voltage Rating:80V, Esr:-, Product Range:Fk Series, Lifetime @ Temperature:5000 Hours @ 105°C, Operating Temperature Min:-55°C, Operating Temperature Rohs Compliant: Yes |Panasonic EEVFK1K680Q RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 35 |
|
$0.7720 / $1.4500 | Buy Now |
|
DISTI #
49W7702
|
Newark | Aluminum Electrolytic Capacitor, 68Uf, 80V, 20%, Smd, Full Reel, Capacitor Case/Package:Radial Can - Smd, Capacitance:68Μf, Voltage(Dc):80V, Esr:-, Lifetime @ Temperature:5000 Hours @ 105°C, Polarity:Polar, Product Range:Fk Series Rohs Compliant: Yes |Panasonic EEVFK1K680Q RoHS: Compliant Min Qty: 250 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.5530 / $0.7190 | Buy Now |
|
DISTI #
80564408
|
Verical | Cap Aluminum Lytic 68uF 80V 20% (12.5 X 13.5mm) SMD 0.5A 5000h 105°C T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 200 Package Multiple: 200 | Americas - 2000 |
|
$0.6123 / $0.7128 | Buy Now |
|
|
Quest Components | ALUMINUM ELECTROLYTIC CAPACITOR, POLARIZED, ALUMINUM (WET), 80V, 20% +TOL, 20% -TOL, 68UF, SURFACE MOUNT, 5353 | 19 |
|
$1.5000 / $2.4000 | Buy Now |
|
|
Quest Components | ALUMINUM ELECTROLYTIC CAPACITOR, POLARIZED, ALUMINUM (WET), 80V, 20% +TOL, 20% -TOL, 68UF, SURFACE MOUNT, 5353 (Also Known As: EEV-FK1K680Q) | 19 |
|
$1.5000 / $2.4000 | Buy Now |
|
DISTI #
EEVFK1K680Q
|
TME | Capacitor: electrolytic, low ESR, SMD, 68uF, 80VDC, Ø12.5x13.5mm Min Qty: 200 | 0 |
|
$0.7700 | RFQ |
|
DISTI #
EEVFK1K680Q
|
Avnet Abacus | Aluminum Electrolytic Capacitor 68 uF 80 V 20 5000 hours 105C Radial Can SMD - Tape and Reel (Alt: EEVFK1K680Q) RoHS: Compliant Min Qty: 400 Package Multiple: 200 Lead time: 23 Weeks, 0 Days Container: Reel | Abacus - 0 |
|
Buy Now |
Part Details for EEVFK1K680Q
EEVFK1K680Q CAD Models
EEVFK1K680Q Part Data Attributes
|
|
EEVFK1K680Q
Panasonic Electronic Components
Buy Now
Datasheet
|
Compare Parts:
EEVFK1K680Q
Panasonic Electronic Components
Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 80V, 20% +Tol, 20% -Tol, 68uF, Surface Mount, 5353, CHIP
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | PANASONIC CORP | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 21 Weeks | |
| Samacsys Manufacturer | Panasonic | |
| Capacitance | 68 µF | |
| Capacitor Type | ALUMINUM ELECTROLYTIC CAPACITOR | |
| Diameter | 12.5 mm | |
| Dielectric Material | ALUMINUM (WET) | |
| Height | 13.5 mm | |
| JESD-609 Code | e3 | |
| Leakage Current | 0.0544 mA | |
| Length | 13.5 mm | |
| Mounting Feature | SURFACE MOUNT | |
| Negative Tolerance | 20% | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 105 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Shape | CYLINDRICAL PACKAGE | |
| Package Style | SMT | |
| Packing Method | TR, EMBOSSED, 13 INCH | |
| Polarity | POLARIZED | |
| Positive Tolerance | 20% | |
| Rated (DC) Voltage (URdc) | 80 V | |
| Reference Standard | AEC-Q200 | |
| Ripple Current | 375 mA | |
| Size Code | 5353 | |
| Surface Mount | YES | |
| Tan Delta | 0.08 | |
| Terminal Finish | Tin (Sn) | |
| Terminal Shape | FLAT | |
| Width | 13.5 mm |
