Capacitors / Aluminum Electrolytic Capacitors / EEVFK1E222M
Datasheets
EEVFK1E222M by: Panasonic Electronic Components

Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 25V, 20% +Tol, 20% -Tol, 2200uF, Surface Mount, 6767, CHIP

Part Details for EEVFK1E222M by Panasonic Electronic Components

Results Overview of EEVFK1E222M by Panasonic Electronic Components

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

EEVFK1E222M Information

EEVFK1E222M by Panasonic Electronic Components is an Aluminum Electrolytic Capacitor.
Aluminum Electrolytic Capacitors are under the broader part category of Capacitors.

A capacitor is a passive electronic component that stores energy. Capacitors are commonly used for energy storage, voltage suppression, and signal filtering. Read more about Capacitors on our Capacitors part category page.

Price & Stock for EEVFK1E222M

Part # Distributor Description Stock Price Buy
DISTI # 85AK4410
Newark Cap, Alu Elec, 2200Uf, 25V, Smd, Capacitor Case/Package:Radial Can - Smd, Capacitance:2200Μf, Voltage(Dc):25V, Esr:-, Lifetime @ Temperature:5000 Hours @ 105°C, Polarity:Polar, Product Range:Fk Series, Capacitance Tolerance:± 20% Rohs Compliant: Yes |Panasonic EEVFK1E222M RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape 1250
  • 1 $0.9550
  • 10 $0.9550
  • 25 $0.9550
  • 50 $0.9550
$0.9550 Buy Now
DISTI # 17AC6857
Newark Cap, 2200Μf, 25V, Smd Reel, Ae Capacitor Case:Radial Can - Smd, Capacitance:2200Μf, Voltage Rating:25V, Esr:-, Product Range:Fk Series, Lifetime @ Temperature:5000 Hours @ 105°C, Operating Temperature Min:-55°C, Operating Temperaturerohs Compliant: Yes |Panasonic EEVFK1E222M RoHS: Compliant Min Qty: 125 Package Multiple: 1 Date Code: 1 Container: Reel 750
  • 125 $1.0900
  • 250 $1.0500
  • 500 $1.0100
  • 750 $1.0000
  • 1,250 $0.9930
$0.9930 / $1.0900 Buy Now
DISTI # 70068605
RS Capacitor, Aluminum Electrolytic, Ecap 2200uF 25V J16 Case FK SMT Min Qty: 1 Package Multiple: 1 Container: Bulk 0
  • 1 $1.8100
  • 25 $1.7200
  • 50 $1.6600
$1.6600 / $1.8100 RFQ
Bristol Electronics   1000
RFQ
Quest Components CAP,AL2O3,2.2MF,25VDC,20-% TOL,20+% TOL 72
  • 1 $3.7500
  • 9 $2.7500
  • 28 $2.5000
$2.5000 / $3.7500 Buy Now
Quest Components CAP,AL2O3,2.2MF,25VDC,20-% TOL,20+% TOL (Also Known As: EEV-FK1E222M) 72
  • 1 $3.7500
  • 9 $2.7500
  • 28 $2.5000
$2.5000 / $3.7500 Buy Now
DISTI # EEVFK1E222M
TME Capacitor: electrolytic, low ESR, SMD, 2200uF, 25VDC, Ø16x16.5mm Min Qty: 125 0
  • 125 $1.2100
$1.2100 RFQ
Ameya Holding Limited Cap Aluminium SMD 2200uF 20% 25V 105C 5000hrs 1800mA 16X17 Auto 500-Authorized Distributor
Buy Now RFQ
ComSIT USA Electronic Component RoHS: Compliant Stock DE - 0
Stock ES - 500
Stock US - 0
Stock MX - 0
Stock CN - 0
Stock HK - 0
RFQ
DISTI # SMC-EEVFK1E222M
Sensible Micro Corporation AS6081 Certified Vendor, 1 Year Warranty RoHS: Compliant Min Qty: 25 Lead time: 0 Weeks, 1 Days Container: Tape & Reel 28
RFQ
Chip 1 Exchange INSTOCK 750
RFQ
DISTI # EEVFK1E222M
Avnet Abacus Aluminum Electrolytic Capacitor 2200 uF 25 V 20 5000 hours 105C Radial Can SMD - Tape and Reel (Alt: EEVFK1E222M) RoHS: Compliant Min Qty: 250 Package Multiple: 125 Lead time: 23 Weeks, 0 Days Container: Reel Abacus - 125
Buy Now
New Advantage Corporation CapAluSMD2200uF20%25V105C5000hrs1800mA16x16.5AutoLowESR RoHS: Compliant Min Qty: 1 Package Multiple: 125 1625
  • 125 $1.5000
  • 1,625 $1.3900
$1.3900 / $1.5000 Buy Now
Vyrian Capacitors 4847
RFQ

Part Details for EEVFK1E222M

EEVFK1E222M CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

EEVFK1E222M Part Data Attributes

Parametric Data
EEVFK1E222M Panasonic Electronic Components
Buy Now Datasheet
Compare Parts:
EEVFK1E222M Panasonic Electronic Components Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 25V, 20% +Tol, 20% -Tol, 2200uF, Surface Mount, 6767, CHIP
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer PANASONIC CORP
Package Description CHIP
Reach Compliance Code compliant
ECCN Code EAR99
Factory Lead Time 21 Weeks
Samacsys Manufacturer Panasonic
Capacitance 2200 µF
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Diameter 16 mm
Dielectric Material ALUMINUM (WET)
Height 16.5 mm
JESD-609 Code e3
Leakage Current 0.55 mA
Length 17 mm
Mounting Feature SURFACE MOUNT
Negative Tolerance 20%
Number of Terminals 2
Operating Temperature-Max 105 °C
Operating Temperature-Min -55 °C
Package Shape CYLINDRICAL PACKAGE
Package Style SMT
Packing Method TR, EMBOSSED, 13 INCH
Polarity POLARIZED
Positive Tolerance 20%
Rated (DC) Voltage (URdc) 25 V
Reference Standard AEC-Q200
Ripple Current 1350 mA
Size Code 6767
Surface Mount YES
Tan Delta 0.16
Terminal Finish Tin (Sn)
Terminal Shape FLAT
Width 17 mm

EEVFK1E222M Related Parts

EEVFK1E222M Frequently Asked Questions (FAQ)

  • The recommended soldering temperature for EEVFK1E222M is 260°C for 10 seconds or less.

  • Yes, the EEVFK1E222M capacitor is RoHS (Restriction of Hazardous Substances) compliant, meaning it does not contain hazardous substances like lead, mercury, or cadmium.

  • The ESR of the EEVFK1E222M capacitor is 0.015 ohms at 100 kHz.

  • Yes, the EEVFK1E222M capacitor is designed to operate in high-temperature environments, with a maximum operating temperature of 125°C.

  • Yes, the EEVFK1E222M capacitor meets the requirements for automotive applications, including AEC-Q200 qualification.
