EEUFC1V121 Information
EEUFC1V121 by Panasonic Electronic Components is a Fixed Capacitor.
Fixed Capacitors are under the broader part category of Capacitors.
A capacitor is a passive electronic component that stores energy. Capacitors are commonly used for energy storage, voltage suppression, and signal filtering. Read more about Capacitors on our Capacitors part category page.
Price & Stock for EEUFC1V121
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
17T5115
|
Newark | Aluminum Electrolytic Capacitor, 120Uf, 35V, Radial, Capacitance:120Μf, Voltage(Dc):35V, Capacitance Tolerance:± 20%, Capacitor Terminals:Radial Leaded, Lifetime @ Temperature:2000 Hours @ 105°C, Polarity:Polar, Lead Spacing:3.5Mm Rohs Compliant: Yes |Panasonic EEUFC1V121 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 6637 |
|
$0.1280 / $0.4020 | Buy Now |
|
DISTI #
70068513
|
RS | Capacitor, Aluminum Electrolytic, Fc Radial Elec Cap 120uF 35V Min Qty: 1 Package Multiple: 1 Container: Bulk | 20 |
|
$0.3580 | Buy Now |
|
|
Bristol Electronics | 9 |
|
RFQ | ||
|
|
Quest Components | CAP,AL2O3,120UF,35VDC,20-% TOL,20+% TOL | 502 |
|
$0.2229 / $0.7430 | Buy Now |
|
|
Quest Components | CAP,AL2O3,120UF,35VDC,20-% TOL,20+% TOL (Also Known As: EEU-FC1V121) | 502 |
|
$0.2229 / $0.7430 | Buy Now |
|
|
Quest Components | CAP,AL2O3,120UF,35VDC,20-% TOL,20+% TOL (Also Known As: EEU-FC1V121) | 474 |
|
$0.2229 / $0.7430 | Buy Now |
|
|
Quest Components | CAP,AL2O3,120UF,35VDC,20-% TOL,20+% TOL | 474 |
|
$0.2229 / $0.7430 | Buy Now |
|
|
Quest Components | CAP,AL2O3,120UF,35VDC,20-% TOL,20+% TOL (Also Known As: EEU-FC1V121) | 65 |
|
$0.1486 / $0.2229 | Buy Now |
|
|
Quest Components | CAP,AL2O3,120UF,35VDC,20-% TOL,20+% TOL | 65 |
|
$0.1486 / $0.2229 | Buy Now |
|
DISTI #
EEUFC1V121
|
TME | Capacitor: electrolytic, low ESR, THT, 120uF, 35VDC, Ø8x11.5mm Min Qty: 1 | 212 |
|
$0.1450 / $0.4390 | Buy Now |
Part Details for EEUFC1V121
EEUFC1V121 CAD Models
EEUFC1V121 Part Data Attributes
|
|
EEUFC1V121
Panasonic Electronic Components
Buy Now
Datasheet
|
Compare Parts:
EEUFC1V121
Panasonic Electronic Components
Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 35V, 20% +Tol, 20% -Tol, 120uF, Through Hole Mount, RADIAL LEADED, ROHS COMPLIANT
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | PANASONIC CORP | |
| Package Description | RADIAL LEADED | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8532.22.00.20 | |
| Factory Lead Time | 21 Weeks | |
| Samacsys Manufacturer | Panasonic | |
| Capacitance | 120 µF | |
| Capacitor Type | ALUMINUM ELECTROLYTIC CAPACITOR | |
| Diameter | 8 mm | |
| Dielectric Material | ALUMINUM (WET) | |
| JESD-609 Code | e3 | |
| Leakage Current | 0.042 mA | |
| Length | 11.5 mm | |
| Mounting Feature | THROUGH HOLE MOUNT | |
| Negative Tolerance | 20% | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 105 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Shape | CYLINDRICAL PACKAGE | |
| Package Style | Radial | |
| Packing Method | BULK | |
| Polarity | POLARIZED | |
| Positive Tolerance | 20% | |
| Rated (DC) Voltage (URdc) | 35 V | |
| Reference Standard | AEC-Q200 | |
| Ripple Current | 360.75 mA | |
| Surface Mount | NO | |
| Tan Delta | 0.12 | |
| Terminal Finish | Tin (Sn) | |
| Terminal Pitch | 3.5 mm | |
| Terminal Shape | WIRE |
Alternate Parts for EEUFC1V121
This table gives cross-reference parts and alternative options found for EEUFC1V121. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of EEUFC1V121, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| RXK121M1VBK-0811 | Lelon Electronics Corp | Check for Price | Aluminum Electrolytic Capacitor, Polarized, Aluminum, 35V, 20% +Tol, 20% -Tol, 120uF, | EEUFC1V121 vs RXK121M1VBK-0811 |
| EEUFC1V121(B) | Panasonic Electronic Components | Check for Price | Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 35V, 20% +Tol, 20% -Tol, 120uF, Through Hole Mount, RADIAL LEADED, ROHS COMPLIANT | EEUFC1V121 vs EEUFC1V121(B) |
| TPZ1V151M0811M | Taicon Corporation | Check for Price | Aluminum Electrolytic Capacitor, Polarized, Aluminum, 35V, 20% +Tol, 20% -Tol, 120uF | EEUFC1V121 vs TPZ1V151M0811M |
| ECR1VGK121MLL35080011 | Nantong Jianghai Capacitor Co Ltd | Check for Price | Aluminum Electrolytic Capacitor, Polarized, Aluminum, 35V, 20% +Tol, 20% -Tol, 120uF, | EEUFC1V121 vs ECR1VGK121MLL35080011 |
| RZF121M1VBK-0811 | Surge Components Inc | Check for Price | Aluminum Electrolytic Capacitor, Polarized, Aluminum, 35V, 20% +Tol, 20% -Tol, 120uF, | EEUFC1V121 vs RZF121M1VBK-0811 |
| RZF121M1VSA-0811 | Surge Components Inc | Check for Price | Aluminum Electrolytic Capacitor, Polarized, Aluminum, 35V, 20% +Tol, 20% -Tol, 120uF, | EEUFC1V121 vs RZF121M1VSA-0811 |
| GL121M035 | Capxon Electronic Technology Co Ltd | Check for Price | Aluminum Electrolytic Capacitor, Polarized, Aluminum, 35V, 20% +Tol, 20% -Tol, 120uF, | EEUFC1V121 vs GL121M035 |
| RZF121M1VSF-0811 | Surge Components Inc | Check for Price | Aluminum Electrolytic Capacitor, Polarized, Aluminum, 35V, 20% +Tol, 20% -Tol, 120uF, | EEUFC1V121 vs RZF121M1VSF-0811 |
| RZF121M1VBC-0811 | Surge Components Inc | Check for Price | Aluminum Electrolytic Capacitor, Polarized, Aluminum, 35V, 20% +Tol, 20% -Tol, 120uF, | EEUFC1V121 vs RZF121M1VBC-0811 |
