Part Details for EEHZA1H680P by Panasonic Electronic Components
Results Overview of EEHZA1H680P by Panasonic Electronic Components
- Distributor Offerings: (13 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Industrial Automation
EEHZA1H680P Information
EEHZA1H680P by Panasonic Electronic Components is an Aluminum Electrolytic Capacitor.
Aluminum Electrolytic Capacitors are under the broader part category of Capacitors.
A capacitor is a passive electronic component that stores energy. Capacitors are commonly used for energy storage, voltage suppression, and signal filtering. Read more about Capacitors on our Capacitors part category page.
Price & Stock for EEHZA1H680P
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
85AK4375
|
Newark | Cap, Alu Elec, Hybrid, 68Uf, 50V, Smd, Capacitance:68Μf, Capacitance Tolerance:± 20%, Voltage(Dc):50V, Capacitor Case/Package:Radial Can - Smd, Esr:0.03Ohm, Lifetime @ Temperature:10000 Hours @ 105°C, Product Diameter:8Mm Rohs Compliant: Yes |Panasonic EEHZA1H680P RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 6739 |
|
$0.5750 | Buy Now |
|
DISTI #
17AC6843
|
Newark | Cap, 68Μf, 50V, 20% Rohs Compliant: Yes |Panasonic EEHZA1H680P RoHS: Compliant Min Qty: 500 Package Multiple: 1 Date Code: 1 Container: Reel | 2000 |
|
$0.8080 | Buy Now |
|
DISTI #
79356573
|
Verical | Cap Aluminum Polymer Hybrid 68uF 50VDC 20%( 8 X 10.2mm) SMD 0.03 Ohm 1.8A 10000h 105°C T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 500 Package Multiple: 500 Date Code: 2329 | Americas - 2000 |
|
$1.0049 / $1.0309 | Buy Now |
|
|
Bristol Electronics | 526 |
|
RFQ | ||
|
|
Quest Components | CAPACITOR, ALUMINUM ELECTROLYTIC, SOLID POLYMER, POLARIZED, 50 V, 68 UF, SURFACE MOUNT, 3333 | 144 |
|
$0.9000 / $2.4000 | Buy Now |
|
|
Quest Components | CAPACITOR, ALUMINUM ELECTROLYTIC, SOLID POLYMER, POLARIZED, 50 V, 68 UF, SURFACE MOUNT, 3333 (Also Known As: EEH-ZA1H680P) | 144 |
|
$0.9000 / $2.4000 | Buy Now |
|
DISTI #
EEHZA1H680P
|
TME | Capacitor: hybrid, 68uF, 50VDC, ESR: 30mΩ, ZA, SMD, ±20%, -55÷105°C Min Qty: 10 | 0 |
|
$0.6600 / $0.7800 | RFQ |
|
DISTI #
EEHZA1H680P
|
Avnet Abacus | Hybrid Aluminium Electrolytic Capacitor 68 F 20 50 V Radial Can SMD 003 ohm - Tape and Reel (Alt: EEHZA1H680P) RoHS: Compliant Min Qty: 500 Package Multiple: 500 Lead time: 23 Weeks, 0 Days Container: Reel | Abacus - 1000 |
|
Buy Now | |
|
|
Greenchips | Date Code: 23+/JP | 640 |
|
RFQ | |
|
|
Greenchips | Date Code: N/A | 0 |
|
RFQ |
Part Details for EEHZA1H680P
EEHZA1H680P CAD Models
EEHZA1H680P Part Data Attributes
|
|
EEHZA1H680P
Panasonic Electronic Components
Buy Now
Datasheet
|
Compare Parts:
EEHZA1H680P
Panasonic Electronic Components
Aluminum Electrolytic Capacitor, Polarized, Aluminum (solid Polymer), 50V, 20% +Tol, 20% -Tol, 68uF, Surface Mount, 3333, CHIP, ROHS COMPLIANT
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | PANASONIC CORP | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8532.22.00.20 | |
| Factory Lead Time | 14 Weeks | |
| Samacsys Manufacturer | Panasonic | |
| Additional Feature | ESR IS MEASURED AT 100 KHZ | |
| Capacitance | 68 µF | |
| Capacitor Type | ALUMINUM ELECTROLYTIC CAPACITOR | |
| Dielectric Material | ALUMINUM (SOLID POLYMER) | |
| ESR | 30 mΩ | |
| Height | 10.2 mm | |
| Leakage Current | 0.034 mA | |
| Length | 8.3 mm | |
| Mounting Feature | SURFACE MOUNT | |
| Negative Tolerance | 20% | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 105 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Shape | CYLINDRICAL PACKAGE | |
| Package Style | SMT | |
| Packing Method | TR, EMBOSSED, 15 INCH | |
| Polarity | POLARIZED | |
| Positive Tolerance | 20% | |
| Rated (DC) Voltage (URdc) | 50 V | |
| Reference Standard | AEC-Q200 | |
| Ripple Current | 270 mA | |
| Size Code | 3333 | |
| Surface Mount | YES | |
| Tan Delta | 0.10 | |
| Terminal Shape | FLAT | |
| Width | 8.3 mm |
