EDZVT2R2.0B Information
EDZVT2R2.0B by ROHM Semiconductor is a Zener Diode.
Zener Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for EDZVT2R2.0B
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
81AC4704
|
Newark | Zener Diode, 2V, 0.15W, Sod-523, Zener Voltage Vz Typ:2V, Power Dissipation Pd:150Mw, Diode Case Style:Sod-523, Zener Tolerance ±:-, No. Of Pins:2Pins, Operating Temperature Max:150°C, Product Range:Edzv Series, Automotive Rohs Compliant: Yes |Rohm EDZVT2R2.0B RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 15650 |
|
$0.0570 / $0.1720 | Buy Now |
|
DISTI #
EDZVT2R2.0BCT-ND
|
DigiKey | DIODE ZENER 2V 150MW EMD2 Min Qty: 1 Lead time: 17 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
7878 In Stock |
|
$0.0262 / $0.2100 | Buy Now |
|
DISTI #
EDZVT2R2.0B
|
Avnet Americas | DIODE ZENER SINGLE 2V 2% 150MW 2-PIN EMD T/R - Tape and Reel (Alt: EDZVT2R2.0B) RoHS: Compliant Min Qty: 8000 Package Multiple: 8000 Lead time: 22 Weeks, 0 Days Container: Reel | 0 |
|
RFQ | |
|
DISTI #
755-EDZVT2R2.0B
|
Mouser Electronics | Zener Diodes Diode Zener Sgl 2V 150mW RoHS: Compliant | 14975 |
|
$0.0260 / $0.2100 | Buy Now |
|
DISTI #
65086749
|
Verical | Zener Diode Single 2.11V 4% 100Ohm 150mW 2-Pin EMD T/R RoHS: Compliant Min Qty: 1516 Package Multiple: 1 Date Code: 2201 | Americas - 24000 |
|
$0.0444 / $0.0482 | Buy Now |
|
DISTI #
87836282
|
Verical | Zener Diode Single 2.11V 4% 100Ohm 150mW 2-Pin EMD T/R RoHS: Compliant Min Qty: 2156 Package Multiple: 1 Date Code: 2214 | Americas - 7569 |
|
$0.1150 | Buy Now |
|
DISTI #
61304536
|
Verical | Zener Diode Single 2.11V 4% 100Ohm 150mW 2-Pin EMD T/R RoHS: Compliant Min Qty: 388 Package Multiple: 1 Date Code: 2201 | Americas - 388 |
|
$0.2022 | Buy Now |
|
DISTI #
EDZVT2R2.0B
|
IBS Electronics | EDZVT2R2.0B by ROHM is a Zener diode with a 2.0V breakdown voltage, SOD-523 package, and low leakage current, ideal for voltage regulation and protection in compact electronic circuits. Min Qty: 8000 Package Multiple: 1 | 0 |
|
$0.0357 / $0.0377 | Buy Now |
|
|
LCSC | Independent Type 2.02V2.2V 150mW 2V SOD-523 Zener Diodes ROHS | 20900 |
|
$0.0110 / $0.0163 | Buy Now |
Part Details for EDZVT2R2.0B
EDZVT2R2.0B CAD Models
EDZVT2R2.0B Part Data Attributes
|
|
EDZVT2R2.0B
ROHM Semiconductor
Buy Now
Datasheet
|
Compare Parts:
EDZVT2R2.0B
ROHM Semiconductor
Zener Diode, 2.11V V(Z), 4.27%, 0.15W, Silicon, Unidirectional, SC-79, 2 PIN
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ROHM CO LTD | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.50 | |
| Factory Lead Time | 22 Weeks | |
| Samacsys Manufacturer | ROHM Semiconductor | |
| Additional Feature | HIGH RELIABILITY | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | ZENER DIODE | |
| JESD-30 Code | R-PDSO-F2 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity | UNIDIRECTIONAL | |
| Power Dissipation-Max | 0.15 W | |
| Reference Voltage-Nom | 2 V | |
| Surface Mount | YES | |
| Technology | ZENER | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | FLAT | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 10 | |
| Voltage Tol-Max | 4.27% | |
| Working Test Current | 5 mA |
