DSDI60-18A Information
DSDI60-18A by Littelfuse Inc is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for DSDI60-18A
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
02AH9896
|
Newark | Rectifier, 1.8Kv, 63A, To-247Ad, Repetitive Peak Reverse Voltage:1.8Kv, Average Forward Current:63A, Diode Configuration:Single, Forward Voltage Max:4.1V, Reverse Recovery Time:300Ns, Forward Surge Current:540A, No. Of Pins:2 Pin Rohs Compliant: Yes |Littelfuse DSDI60-18A RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 94 |
|
$7.2100 / $12.2900 | Buy Now |
|
DISTI #
75576582
|
RS | Power Diode Discretes-FRED TO-247AD Min Qty: 300 Package Multiple: 1 Lead time: 8 Weeks, 0 Days Container: Bulk | 0 |
|
$10.4700 / $11.3800 | RFQ |
|
|
Cytech Systems Limited | DIODE GEN PURP 1.8KV 63A TO247AD | 210 |
|
RFQ |
Part Details for DSDI60-18A
DSDI60-18A CAD Models
DSDI60-18A Part Data Attributes
|
|
DSDI60-18A
Littelfuse Inc
Buy Now
Datasheet
|
Compare Parts:
DSDI60-18A
Littelfuse Inc
Rectifier Diode, 1 Phase, 1 Element, 63A, 1800V V(RRM), Silicon, TO-247AD, TO-247AD, 2 PIN
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | LITTELFUSE INC | |
| Package Description | TO-247AD, 2 PIN | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.80 | |
| Samacsys Manufacturer | LITTELFUSE | |
| Additional Feature | HIGH RELIABILITY, LOW NOISE, FREE WHEELING DIODE, SNUBBER DIODE | |
| Application | FAST RECOVERY | |
| Case Connection | CATHODE | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | RECTIFIER DIODE | |
| Forward Voltage-Max (VF) | 3.7 V | |
| JEDEC-95 Code | TO-247AD | |
| JESD-30 Code | R-PSFM-T2 | |
| Non-rep Pk Forward Current-Max | 500 A | |
| Number of Elements | 1 | |
| Number of Phases | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Output Current-Max | 63 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | FLANGE MOUNT | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Power Dissipation-Max | 312 W | |
| Qualification Status | Not Qualified | |
| Rep Pk Reverse Voltage-Max | 1800 V | |
| Reverse Recovery Time-Max | 0.04 µs | |
| Surface Mount | NO | |
| Terminal Form | THROUGH-HOLE | |
| Terminal Position | SINGLE | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
