DRB30-12-1 Information
DRB30-12-1 by TDK-Lambda Corporation is a Power Supply Module.
Power Supply Modules are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for DRB30-12-1
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
18X3669
|
Newark | Ac-Dc Converter, Din Rail, 1 O/P, 30W, 2.5A, 12V, Power Supply Applications:Ite, No. Of Outputs:1 Output, Output Power Max:30W, Output Voltage - Output 1:12Vdc, Output Current - Output 1:2.5A, Output Voltage - Output 2:- Rohs Compliant: Yes |Tdk-Lambda DRB30-12-1 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk | 80 |
|
$42.5700 | Buy Now |
|
DISTI #
285-DRB30-12-1-ND
|
DigiKey | AC/DC DIN RAIL SUPPLY 12V 30W Min Qty: 1 Lead time: 8 Weeks Container: Bulk |
1176 In Stock |
|
$40.8500 | Buy Now |
|
DISTI #
967-DRB30-12-1
|
Mouser Electronics | DIN Rail Power Supplies 12Vout 2.5A 30W DIN Rail PS RoHS: Compliant | 81 |
|
$40.8500 | Buy Now |
|
|
Onlinecomponents.com | DIN Rail AC-DC Power Supply - 30W - 12 VDC - Input: 85 to 264VAC RoHS: Compliant |
88 In Stock |
|
$38.6200 / $42.1100 | Buy Now |
|
DISTI #
87335199
|
Verical | AC/DC Power Supply Single-OUT 12V 2.5A 30W Min Qty: 2 Package Multiple: 1 | Americas - 11 |
|
$68.3043 | Buy Now |
|
|
Quest Components | 1 |
|
$34.1250 | Buy Now | |
|
DISTI #
DRB30-12-1
|
TME | Power supply: switching, for DIN rail, 30W, 12VDC, 2.5A, 85÷264VAC Min Qty: 1 | 15 |
|
$47.6700 / $50.8600 | Buy Now |
|
DISTI #
000000000005398585
|
Sager | DIN Rail Power Supplies 12Vout 2.5A 30W DIN Rail PS Min Qty: 1 | 0 |
|
$36.6700 / $40.8500 | Buy Now |
|
|
Master Electronics | DIN Rail AC-DC Power Supply - 30W - 12 VDC - Input: 85 to 264VAC RoHS: Compliant |
88 In Stock |
|
$38.6200 / $42.1100 | Buy Now |
|
|
Neutron USA | DIN Rail Power Supplies 12Vout 2.5A 30W DIN Rail PS | 50 |
|
$102.9900 | Buy Now |
Part Details for DRB30-12-1
DRB30-12-1 CAD Models
DRB30-12-1 Part Data Attributes
|
|
DRB30-12-1
TDK-Lambda Corporation
Buy Now
Datasheet
|
Compare Parts:
DRB30-12-1
TDK-Lambda Corporation
AC-DC Regulated Power Supply Module, 1 Output, 30W, Hybrid, ROHS COMPLIANT, PACKAGE-6
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Transferred | |
| Ihs Manufacturer | TDK-LAMBDA CORP | |
| Package Description | ROHS COMPLIANT, PACKAGE-6 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Samacsys Manufacturer | TDK Lambda | |
| Additional Feature | DC INPUT VOLTAGE IS 120 TO 373V | |
| Analog IC - Other Type | AC-DC REGULATED POWER SUPPLY MODULE | |
| Input Voltage-Max | 264 V | |
| Input Voltage-Min | 85 V | |
| Input Voltage-Nom | 110 V | |
| JESD-30 Code | X-XXMA-X6 | |
| Number of Functions | 1 | |
| Number of Outputs | 1 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 55 °C | |
| Operating Temperature-Min | -20 °C | |
| Output Voltage-Max | 15 V | |
| Output Voltage-Min | 12 V | |
| Output Voltage-Nom | 12 V | |
| Package Body Material | UNSPECIFIED | |
| Package Code | XMA | |
| Package Shape | UNSPECIFIED | |
| Package Style | MICROELECTRONIC ASSEMBLY | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Surface Mount | NO | |
| Technology | HYBRID | |
| Temperature Grade | OTHER | |
| Terminal Form | UNSPECIFIED | |
| Terminal Position | UNSPECIFIED | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Total Power Output-Max | 30 W | |
| Trim/Adjustable Output | YES |
DRB30-12-1 Frequently Asked Questions (FAQ)
-
The maximum operating temperature range for the DRB30-12-1 is -40°C to +85°C, with a derating of 2.5% per °C above 60°C.
-
Yes, the DRB30-12-1 is designed to operate in humid environments, but it's recommended to follow the guidelines for humidity and moisture protection outlined in the datasheet to ensure reliable operation.
-
The recommended input capacitor value for the DRB30-12-1 is 10uF to 22uF, with a voltage rating of at least 25V. However, the optimal value may vary depending on the specific application and input voltage ripple requirements.
-
Yes, multiple DRB30-12-1 modules can be paralleled to increase the output current, but it's essential to ensure that the modules are identical and that the output voltage is matched within 1% to prevent current imbalance and reduce the risk of oscillation.
-
The typical efficiency of the DRB30-12-1 is around 85% to 90% depending on the input voltage and output load conditions. However, the actual efficiency may vary depending on the specific application and operating conditions.
