DG442LEDY-T1-GE3 Information
DG442LEDY-T1-GE3 by Vishay Intertechnologies is a Multiplexer or Switch.
Multiplexers or Switches are under the broader part category of Signal Circuits.
A signal is an electronic means of transmitting information, either as an analog signal with continuous values or a digital signal with discrete values. Signals are used in various systems and networks. Read more about Signal Circuits on our Signal Circuits part category page.
Price & Stock for DG442LEDY-T1-GE3
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
24AC4684
|
Newark | Analogue Switch, 4Ch, Spst - No, Soic-16, No. Of Channels:4Channels, Analogue Switch Type:Spst - No, On State Resistance Max:26Ohm, Supply Voltage Range:3V To 16V, Analogue Switch Case:Soic, No. Of Pins:16Pins, Operating Temperature Rohs Compliant: Yes |Vishay DG442LEDY-T1-GE3 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 21 |
|
$0.8380 / $1.4600 | Buy Now |
|
DISTI #
22AC3986
|
Newark | Precision Monolithic Quad Spst Low S |Vishay DG442LEDY-T1-GE3 RoHS: Not Compliant Min Qty: 2500 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.5820 / $0.6860 | Buy Now |
|
DISTI #
DG442LEDY-T1-GE3
|
Avnet Americas | Analog Switch Quad SPST 16-Pin SOIC T/R - Tape and Reel (Alt: DG442LEDY-T1-GE3) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 13 Weeks, 0 Days Container: Reel | 0 |
|
$0.5567 | Buy Now |
|
DISTI #
78-DG442LEDY-T1-GE3
|
Mouser Electronics | Analog Switch ICs Mono quad SPST Pd 650mW SOIC-16 RoHS: Compliant | 11295 |
|
$0.5840 / $1.2600 | Buy Now |
|
DISTI #
DG442LEDY-T1-GE3
|
TTI | Analog Switch ICs Mono quad SPST Pd 650mW SOIC-16 RoHS: Compliant pbFree: Pb-Free Min Qty: 2500 Package Multiple: 2500 Container: Reel | Americas - 0 |
|
$0.7300 / $0.7600 | Buy Now |
|
DISTI #
DG442LEDY-T1-GE3
|
EBV Elektronik | Analog Switch Quad SPST 16Pin SOIC TR (Alt: DG442LEDY-T1-GE3) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 Lead time: 14 Weeks, 0 Days | EBV - 0 |
|
Buy Now |
Part Details for DG442LEDY-T1-GE3
DG442LEDY-T1-GE3 CAD Models
DG442LEDY-T1-GE3 Part Data Attributes
|
|
DG442LEDY-T1-GE3
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
DG442LEDY-T1-GE3
Vishay Intertechnologies
SPST,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | SOIC-16 | |
| Reach Compliance Code | compliant | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 13 Weeks | |
| Samacsys Manufacturer | Vishay | |
| Analog IC - Other Type | SPST | |
| JESD-30 Code | R-PDSO-G16 | |
| Length | 9.9 mm | |
| Neg Supply Voltage-Max (Vsup) | -8 V | |
| Neg Supply Voltage-Min (Vsup) | -3 V | |
| Neg Supply Voltage-Nom (Vsup) | -5 V | |
| Normal Position | NC | |
| Number of Channels | 1 | |
| Number of Functions | 4 | |
| Number of Terminals | 16 | |
| Off-state Isolation-Nom | 68 dB | |
| On-state Resistance Match-Nom | 0.1 Ω | |
| On-state Resistance-Max (Ron) | 30 Ω | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output | SEPARATE OUTPUT | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Equivalence Code | SOP16,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Seated Height-Max | 1.75 mm | |
| Signal Current-Max | 0.1 A | |
| Supply Current-Max (Isup) | 0.001 mA | |
| Supply Voltage-Max (Vsup) | 8 V | |
| Supply Voltage-Min (Vsup) | 3 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | YES | |
| Switch-off Time-Max | 55 ns | |
| Switch-on Time-Max | 75 ns | |
| Switching | BREAK-BEFORE-MAKE | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Width | 3.9 mm |
