Part Details for DG212BDQ-T1-E3 by Vishay Intertechnologies

Results Overview of DG212BDQ-T1-E3 by Vishay Intertechnologies

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Education and Research Internet of Things (IoT) Computing and Data Storage Aerospace and Defense Healthcare Telecommunications Communication and Networking Automotive

DG212BDQ-T1-E3 Information

DG212BDQ-T1-E3 by Vishay Intertechnologies is a Multiplexer or Switch.
Multiplexers or Switches are under the broader part category of Signal Circuits.

A signal is an electronic means of transmitting information, either as an analog signal with continuous values or a digital signal with discrete values. Signals are used in various systems and networks. Read more about Signal Circuits on our Signal Circuits part category page.

Price & Stock for DG212BDQ-T1-E3

Part # Distributor Description Stock Price Buy
DISTI # 26AM3220
Newark Quad Spst Analog Switch Rohs Compliant: Yes |Vishay DG212BDQ-T1-E3 RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel 3000
  • 1 $0.8430
$0.8430 Buy Now
DISTI # 06J4739
Newark Analogue Switch, Quad, Spst-No, Tssop-16, Full Reel, Ic Function:Analog Switch, Power Supply Type:Single & Dual Supply, Supply Voltage Range:4.5V To 25V, ± 4.5V To ± 22V, Ic Case/Package:Tssop, No. Of Pins:16Pins, Interfaces:- Rohs Compliant: Yes |Vishay DG212BDQ-T1-E3 RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel 0
  • 2,000 $1.3600
  • 4,000 $1.2300
  • 6,000 $1.1800
  • 10,000 $1.1400
$1.1400 / $1.3600 Buy Now
DISTI # 16X9623
Newark Analogue Switch, Quad, Spst-No, Tssop-16, Supply Voltage Range:4.5V To 25V, ± 4.5V To ± 22V, Ic Case/Package:Tssop, No. Of Pins:16Pins, No. Of Channels:4Channels, On Resistance Max:160Ohm, Switch Configuration:Spst-No Rohs Compliant: Yes |Vishay DG212BDQ-T1-E3 RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Cut Tape 0
  • 1,000 $1.6500
$1.6500 Buy Now
DISTI # 56AJ9783
Newark Analogue Switch, Spst-No, -40 To 85Deg C Rohs Compliant: Yes |Vishay DG212BDQ-T1-E3 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape 0
  • 1 $2.6700
  • 10 $2.3600
  • 25 $2.2500
  • 50 $2.1300
  • 100 $2.0200
  • 250 $1.9300
  • 500 $1.7400
$1.7400 / $2.6700 Buy Now
DISTI # DG212BDQ-T1-E3
Avnet Americas Analog Switch Quad SPST 16-Pin TSSOP T/R - Tape and Reel (Alt: DG212BDQ-T1-E3) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 16 Weeks, 0 Days Container: Reel 3000
  • 3,000 $0.7581
$0.7581 Buy Now
DISTI # 781-DG212BDQ-E3
Mouser Electronics Analog Switch ICs RECOMMENDED ALT DG21 RoHS: Compliant 0
  • 1 $2.1600
  • 10 $1.6100
  • 25 $1.4900
  • 100 $1.3600
  • 250 $1.3000
  • 500 $1.2400
  • 1,000 $1.1900
  • 3,000 $1.0600
  • 6,000 $1.0100
$1.0100 / $2.1600 Order Now
DISTI # V72:2272_09212434
Arrow Electronics Analog Switch Quad SPST 16-Pin TSSOP T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 16 Weeks Date Code: 2329 Container: Cut Strips Americas - 20
  • 1 $1.3992
  • 10 $0.9228
$0.9228 / $1.3992 Buy Now
DISTI # DG212BDQ-T1-E3
TTI Analog Switch ICs RECOMMENDED ALT DG21 RoHS: Compliant pbFree: Pb-Free Min Qty: 3000 Package Multiple: 3000 Container: Reel Americas - 6000
In Stock
  • 3,000 $1.0300
  • 6,000 $1.0100
  • 12,000 $0.9900
  • 18,000 $0.9700
$0.9700 / $1.0300 Buy Now
DISTI # DG212BDQ-T1-E3
EBV Elektronik Analog Switch Quad SPST 16Pin TSSOP TR (Alt: DG212BDQ-T1-E3) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 17 Weeks, 0 Days EBV - 0
Buy Now
LCSC 85 4 SPST (Single Pole Single Throw) - Normally Open TSSOP-16 Analog Switches Multiplexers ROHS 1
  • 1 $1.6973
  • 10 $1.6611
  • 30 $1.6355
  • 100 $1.6098
$1.6098 / $1.6973 Buy Now

Part Details for DG212BDQ-T1-E3

DG212BDQ-T1-E3 Part Data Attributes

Parametric Data
DG212BDQ-T1-E3 Vishay Intertechnologies
Buy Now Datasheet
Compare Parts:
DG212BDQ-T1-E3 Vishay Intertechnologies SPST, 4 Func, 1 Channel, CMOS, PDSO16, ROHS COMPLIANT, TSSOP-16
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer VISHAY INTERTECHNOLOGY INC
Reach Compliance Code compliant
Factory Lead Time 16 Weeks
Samacsys Manufacturer Vishay
Analog IC - Other Type SPST
JESD-30 Code R-PDSO-G16
JESD-609 Code e3
Length 5 mm
Moisture Sensitivity Level 1
Neg Supply Voltage-Max (Vsup) -22 V
Neg Supply Voltage-Min (Vsup) -4.5 V
Neg Supply Voltage-Nom (Vsup) -15 V
Normal Position NO
Number of Channels 1
Number of Functions 4
Number of Terminals 16
Off-state Isolation-Nom 90 dB
On-state Resistance Match-Nom 2 Ω
On-state Resistance-Max (Ron) 85 Ω
Operating Temperature-Max 85 °C
Operating Temperature-Min -40 °C
Output SEPARATE OUTPUT
Package Body Material PLASTIC/EPOXY
Package Code TSSOP
Package Equivalence Code TSSOP16,.25
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Cel) 260
Qualification Status Not Qualified
Seated Height-Max 1.2 mm
Supply Voltage-Max (Vsup) 22 V
Supply Voltage-Min (Vsup) 4.5 V
Supply Voltage-Nom (Vsup) 15 V
Surface Mount YES
Switch-off Time-Max 200 ns
Switch-on Time-Max 300 ns
Switching BREAK-BEFORE-MAKE
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Pitch 0.65 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
Width 4.4 mm
