DAL7W2P500M30LF Information
DAL7W2P500M30LF by Amphenol Communications Solutions is a D Type Connector.
D Type Connectors are under the broader part category of Connectors.
Connectors are devices that join electrical termination points to form circuits. With various types designed for specific functions like data, power, or signal transmission, choosing the right connector is essential for compatibility and device performance. Read more about Connectors on our Connectors part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| DAL7W2P500M30LF | Amphenol Communications Solutions | D-Sub Power Board Mount Connectors, Input Output Connectors, Mixed Signal and Power 7W2 Pin Right Angle Solder 30A, Europe Standard, 200 Cycles, Front: Threaded Insert M3, Back: Metal Brackets. |
Price & Stock for DAL7W2P500M30LF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
24AM1548
|
Newark | Dal7W2P500M30Lf-Dsun Power Stb 7W2 Pin Rohs Compliant: Yes |Amphenol Communications Solutions DAL7W2P500M30LF RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 0 Container: Bulk | 44 |
|
$13.3500 / $16.0000 | Buy Now |
|
DISTI #
24AC7853
|
Newark | D-Sub Conn, Combination, R/A Plug, Da7W2, Product Range:Dw Series, Insert Arrangement:Da-7W2, Gender:Plug, No. Of Contacts:7Contacts, Contact Type:5 Signal, 2 Power, Contact Termination Type:Solder, Connector Body Material:Steel Bodyrohs Compliant: Yes |Amphenol Communications Solutions DAL7W2P500M30LF RoHS: Compliant Min Qty: 200 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
$13.9900 / $14.4100 | Buy Now |
|
|
Onlinecomponents.com | RoHS: Compliant |
44 Partner Stock |
|
$13.2200 / $28.9600 | Buy Now |
|
DISTI #
DAL7W2P500M30LF
|
IBS Electronics | COMBINATION LAYOUT D SUB CONNECTOR DW SERIES DA-7W2 PLUG 7 CONTACTS 5 SIGNAL 2 POWER Min Qty: 9 Package Multiple: 1 | 44 |
|
$13.8250 / $14.0875 | Buy Now |
|
|
Master Electronics | RoHS: Compliant |
44 Partner Stock |
|
$13.2200 / $28.9600 | Buy Now |
Part Details for DAL7W2P500M30LF
DAL7W2P500M30LF CAD Models
DAL7W2P500M30LF Part Data Attributes
|
|
DAL7W2P500M30LF
Amphenol Communications Solutions
Buy Now
Datasheet
|
Compare Parts:
DAL7W2P500M30LF
Amphenol Communications Solutions
D-Sub Power Board Mount Connectors, Input Output Connectors, Mixed Signal and Power 7W2 Pin Right Angle Solder 30A, Europe Standard, 200 Cycles, Front: Threaded Insert M3, Back: Metal Brackets.
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | AMPHENOL COMMUNICATIONS SOLUTIONS | |
| Pin Count | 7W2 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8536.69.40.30 | |
| Samacsys Manufacturer | Amphenol Communications Solutions | |
| Body Breadth | 0.494 inch | |
| Body Length | 1.526 inch | |
| Connector Type | D SUBMINIATURE CONNECTOR | |
| Contact Arrangement | S5P2 | |
| Contact Finish Mating | NOT SPECIFIED | |
| Contact Finish Termination | Tin (Sn) - with Nickel (Ni) barrier | |
| Contact Gender | MALE | |
| Contact Material | NOT SPECIFIED | |
| Contact Resistance | 7.3 mΩ | |
| Contact Style | HYBRID | |
| DIN Conformance | NO | |
| Durability | 200 Cycles | |
| Empty Shell | NO | |
| Filter Feature | NO | |
| IEC Conformance | NO | |
| Insulation Resistance | 5000000000 Ω | |
| Insulator Material | POLYETHYLENE | |
| JESD-609 Code | e3 | |
| MIL Conformance | NO | |
| Mixed Contacts | YES | |
| Mounting Option 1 | M3 | |
| Mounting Option 2 | THREADED INSERT | |
| Mounting Style | RIGHT ANGLE | |
| Mounting Type | BOARD | |
| Number Of Connectors | ONE | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -55 °C | |
| Option | GENERAL PURPOSE | |
| Rated Current (Signal) | 7.5 A | |
| Reference Standard | UL | |
| Shell Material | STEEL | |
| Shell Size | 2/A | |
| Termination Type | SOLDER | |
| Total Number of Contacts | 7 | |
| UL Flammability Code | 94V-0 |
