CSS2H-2512R-L500F Information
CSS2H-2512R-L500F by Bourns Inc is a Metal Alloy Resistor.
Metal Alloy Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| TPS65251-2RHAT | Texas Instruments | 4.5-V to 18-V input, 3A/2A/2A output, Synchronous triple buck converter 40-VQFN -40 to 125 | |
| TPS65251-2RHAR | Texas Instruments | 4.5-V to 18-V input, 3A/2A/2A output, Synchronous triple buck converter 40-VQFN -40 to 125 |
Price & Stock for CSS2H-2512R-L500F
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
69AK4221
|
Newark | Res, 500, 1%, 6W, 2512, Metal Strip Rohs Compliant: Yes |Bourns CSS2H-2512R-L500F RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 1 Container: Reel | 6000 |
|
$0.5290 | Buy Now |
|
DISTI #
34AK1558
|
Newark | Current Sense Res, 500U, 6W, 2512, Resistance:500Μohm, Product Range:Css2H-2512 Series, Resistor Case/Package:2512 [6432 Metric], Power Rating:6W, Resistance Tolerance:± 1%, Resistor Technology:Metal Strip, Product Length:6.35Mm Rohs Compliant: Yes |Bourns CSS2H-2512R-L500F RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 5508 |
|
$0.4450 | Buy Now |
|
DISTI #
CSS2H-2512R-L500FCT-ND
|
DigiKey | RES SMD 500 UOHM 1% 6W 2512 Min Qty: 1 Lead time: 10 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
9521 In Stock |
|
$0.4790 / $1.7800 | Buy Now |
|
DISTI #
CSS2H-2512R-L500F
|
Avnet Americas | SMD Current Sense Resistor, 500 ?ohm, CSS2H-2512 Series, 2512 [6432 Metric], 6 W, ? 1% - Tape and Reel (Alt: CSS2H-2512R-L500F) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 10 Weeks, 0 Days Container: Reel | 0 |
|
$0.4686 / $0.4999 | Buy Now |
|
DISTI #
34AK1558
|
Avnet Americas | SMD Current Sense Resistor, 500 ?ohm, CSS2H-2512 Series, 2512 [6432 Metric], 6 W, ? 1% - Product that comes on tape, but is not reeled (Alt: 34AK1558) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 11 Weeks, 3 Days Container: Ammo Pack | 0 |
|
$0.7040 / $1.2800 | Buy Now |
|
DISTI #
652-CSS2H2512RL500F
|
Mouser Electronics | Current Sense Resistors - SMD 0.5mOHMS 6W 1% AEC-Q200 RoHS: Compliant | 7837 |
|
$0.5120 / $1.7800 | Buy Now |
|
DISTI #
E02:0323_09360588
|
Arrow Electronics | Res Metal Strip 2512 0.0005 Ohm 1% 6W ±50ppm/°C Pad SMD T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 12 Weeks | Europe - 147000 |
|
$0.5171 | Buy Now |
|
DISTI #
V36:1790_17084300
|
Arrow Electronics | Res Metal Strip 2512 0.0005 Ohm 1% 6W ±50ppm/°C Pad SMD T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 10 Weeks Date Code: 2238 | Americas - 15000 |
|
$0.4541 | Buy Now |
|
DISTI #
V72:2272_17084300
|
Arrow Electronics | Res Metal Strip 2512 0.0005 Ohm 1% 6W ±50ppm/°C Pad SMD T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 10 Weeks Date Code: 1850 Container: Cut Strips | Americas - 3316 |
|
$0.4886 / $0.5467 | Buy Now |
|
DISTI #
70883921
|
RS | Current Sense Resistor,0.5 milliohms / 6 W / 3 W / 1 %,CSS4J-4026 Series Min Qty: 6000 Package Multiple: 1 Lead time: 11 Weeks, 0 Days Container: Bulk | 0 |
|
$1.0900 / $1.2800 | RFQ |
Part Details for CSS2H-2512R-L500F
CSS2H-2512R-L500F CAD Models
CSS2H-2512R-L500F Part Data Attributes
|
|
CSS2H-2512R-L500F
Bourns Inc
Buy Now
Datasheet
|
Compare Parts:
CSS2H-2512R-L500F
Bourns Inc
Fixed Resistor, Metal Alloy, 6W, 0.0005ohm, 1% +/-Tol, 50ppm/Cel, 2512
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | BOURNS INC | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8533.21.00.30 | |
| Factory Lead Time | 11 Weeks, 3 Days | |
| Samacsys Manufacturer | Bourns | |
| Construction | Rectangular | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 170 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Height | 1.21 mm | |
| Package Length | 6.35 mm | |
| Package Style | SMT | |
| Package Width | 3.05 mm | |
| Packing Method | TR, Embossed , 13 Inch | |
| Rated Power Dissipation (P) | 6 W | |
| Rated Temperature | 70 °C | |
| Reference Standard | AEC-Q200 | |
| Resistance | 0.5 Ω | |
| Resistor Type | FIXED RESISTOR | |
| Size Code | 2512 | |
| Surface Mount | YES | |
| Technology | METAL STRIP | |
| Temperature Coefficient | 100 ppm/°C | |
| Terminal Shape | GULL WING | |
| Tolerance | 1% |
