CS5361-KZZ Information
CS5361-KZZ by Cirrus Logic is an Analog to Digital Converter.
Analog to Digital Converters are under the broader part category of Converters.
A converter is an electrical circuit that transforms electric energy into a different form that will support a elecrical load needed by a device. Read more about Converters on our Converters part category page.
Price & Stock for CS5361-KZZ
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
CS5361-KZZ
|
Avnet Americas | Analog to Digital Converter, 24 bit, Delta-Sigma, 204 kSPS, Differential, Serial I2S, 4.75 V to 5.25 V, 24 Pins, TSSOP - Rail/Tube (Alt: CS5361-KZZ) RoHS: Compliant Min Qty: 186 Package Multiple: 62 Lead time: 111 Weeks, 0 Days Container: Tube | 0 |
|
RFQ | |
|
|
Bristol Electronics | 25 |
|
RFQ | ||
|
DISTI #
CS5361-KZZ
|
TME | IC: A/D converter, Ch: 2, 24bit, 2.37÷5.25V, TSSOP24 Min Qty: 1 | 5 |
|
$13.3000 / $18.0000 | Buy Now |
|
DISTI #
CS5361-KZZ
|
Avnet Silica | Analog to Digital Converter 24 bit DeltaSigma 204 kSPS Differential Serial I2S 475 V to 525 V 24 Pins TSSOP (Alt: CS5361-KZZ) RoHS: Compliant Min Qty: 186 Package Multiple: 62 | Silica - 0 |
|
Buy Now | |
|
|
Chip-Germany GmbH | RoHS: Not Compliant | 625 |
|
RFQ | |
|
|
Vyrian | Converters | 1231 |
|
RFQ | |
|
|
Win Source Electronics | IC ADC 24BIT SRL 192KHZ 24-TSSOP | 35600 |
|
$2.3426 / $3.0259 | Buy Now |
Part Details for CS5361-KZZ
CS5361-KZZ CAD Models
CS5361-KZZ Part Data Attributes
|
|
CS5361-KZZ
Cirrus Logic
Buy Now
Datasheet
|
Compare Parts:
CS5361-KZZ
Cirrus Logic
ADC, Delta-Sigma, 24-Bit, 1 Func, 2 Channel, Serial Access, PDSO24, 4.4 MM WIDTH, LEAD FREE, MO-153, TSSOP-24
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | CIRRUS LOGIC INC | |
| Part Package Code | TSSOP | |
| Package Description | 4.4 MM WIDTH, LEAD FREE, MO-153, TSSOP-24 | |
| Pin Count | 24 | |
| Reach Compliance Code | compliant | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 111 Weeks | |
| Samacsys Manufacturer | Cirrus Logic | |
| Analog Input Voltage-Max | 2 V | |
| Converter Type | ADC, DELTA-SIGMA | |
| JESD-30 Code | R-PDSO-G24 | |
| JESD-609 Code | e3 | |
| Length | 7.8 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Analog In Channels | 2 | |
| Number of Bits | 24 | |
| Number of Functions | 1 | |
| Number of Terminals | 24 | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | -10 °C | |
| Output Bit Code | 2'S COMPLEMENT BINARY | |
| Output Format | SERIAL | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSSOP24,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Sample Rate | 0.192 MHz | |
| Seated Height-Max | 1.1 mm | |
| Supply Voltage-Nom | 5 V | |
| Surface Mount | YES | |
| Temperature Grade | COMMERCIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 40 | |
| Width | 4.4 mm |
