CRS03(TE85L,Q,M) by: Toshiba America Electronic Components

DIODE SCHOTTKY 30V 1A 3-2A1A

Part Details for CRS03(TE85L,Q,M) by Toshiba America Electronic Components

Results Overview of CRS03(TE85L,Q,M) by Toshiba America Electronic Components

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Industrial Automation Energy and Power Systems Renewable Energy Automotive

CRS03(TE85L,Q,M) Information

CRS03(TE85L,Q,M) by Toshiba America Electronic Components is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.

A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.

Price & Stock for CRS03(TE85L,Q,M)

Part # Distributor Description Stock Price Buy
DISTI # 08AK5642
Newark Schottky Diode, 30V, 1A, Smd Rohs Compliant: Yes |Toshiba CRS03(TE85L, Q,M) RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape 165
  • 1 $0.3000
  • 10 $0.2140
  • 25 $0.1870
  • 50 $0.1590
  • 100 $0.1320
  • 250 $0.1270
  • 500 $0.1210
  • 1,000 $0.0970
$0.0970 / $0.3000 Buy Now
DISTI # CRS03QCT-ND
DigiKey DIODE SCHOTTKY 30V 1A SFLAT Min Qty: 1 Lead time: 16 Weeks Container: Digi-Reel®, Tape & Reel (TR), Cut Tape (CT) 18003
In Stock
  • 1 $0.2100
  • 10 $0.1400
  • 100 $0.1273
  • 3,000 $0.0899
  • 6,000 $0.0860
  • 9,000 $0.0852
  • 15,000 $0.0813
$0.0813 / $0.2100 Buy Now
DISTI # CRS03(TE85L,Q,M)
Avnet Americas - Tape and Reel (Alt: CRS03(TE85L,Q,M)) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 16 Weeks, 0 Days Container: Reel 0
  • 3,000 $0.0774
  • 6,000 $0.0761
  • 12,000 $0.0747
  • 18,000 $0.0735
  • 24,000 $0.0722
$0.0722 / $0.0774 Buy Now
DISTI # 757-CRS03(TE85L,Q,M)
Mouser Electronics Schottky Diodes & Rectifiers SBD 1A VRRM=30V VFM=0.45V RoHS: Compliant 5908
  • 1 $0.2100
  • 10 $0.1400
  • 100 $0.1290
  • 500 $0.1170
  • 1,000 $0.1100
  • 3,000 $0.0890
  • 6,000 $0.0860
  • 9,000 $0.0850
  • 24,000 $0.0840
$0.0840 / $0.2100 Buy Now
DISTI # V72:2272_13896318
Arrow Electronics Diode Schottky 30V 1A 2-Pin S-FLAT T/R Min Qty: 1 Package Multiple: 1 Lead time: 16 Weeks Container: Cut Strips Americas - 1263
  • 1,199 $0.0834
$0.0834 Buy Now
DISTI # V79:2366_25877450
Arrow Electronics Diode Schottky 30V 1A 2-Pin S-FLAT T/R Min Qty: 1 Package Multiple: 1 Date Code: 1733 Americas - 14
  • 14 $0.0761
$0.0761 Buy Now
DISTI # 69702254
Verical Diode Schottky 30V 1A 2-Pin S-FLAT T/R Min Qty: 653 Package Multiple: 1 Americas - 3000
  • 653 $0.0480
  • 1,000 $0.0479
  • 2,000 $0.0466
$0.0466 / $0.0480 Buy Now
DISTI # 88961392
Verical Diode Schottky 30V 1A 2-Pin S-FLAT T/R Min Qty: 71 Package Multiple: 1 Americas - 1263
  • 71 $0.0834
$0.0834 Buy Now
DISTI # CRS03(TE85L,Q,M)
Avnet Asia Diode Schottky 30V 1A 2-Pin S-FLAT T/R (Alt: CRS03(TE85L,Q,M)) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 24 Weeks, 0 Days 0
RFQ
DISTI # CRS03(TE85L,Q,M)
EBV Elektronik (Alt: CRS03(TE85L,Q,M)) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 21 Weeks, 0 Days EBV - 0
Buy Now

Part Details for CRS03(TE85L,Q,M)

CRS03(TE85L,Q,M) CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

CRS03(TE85L,Q,M) Part Data Attributes

Parametric Data
CRS03(TE85L,Q,M) Toshiba America Electronic Components
Buy Now Datasheet
Compare Parts:
CRS03(TE85L,Q,M) Toshiba America Electronic Components DIODE SCHOTTKY 30V 1A 3-2A1A
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer TOSHIBA CORP
Package Description 3-2A1A, S-FLAT-2
Reach Compliance Code unknown
Factory Lead Time 16 Weeks
Samacsys Manufacturer Toshiba
Application GENERAL PURPOSE
Configuration SINGLE
Diode Element Material SILICON
Diode Type RECTIFIER DIODE
JESD-30 Code R-PDSO-F2
Number of Elements 1
Number of Phases 1
Number of Terminals 2
Operating Temperature-Max 150 °C
Operating Temperature-Min -40 °C
Output Current-Max 1 A
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Peak Reflow Temperature (Cel) 260
Rep Pk Reverse Voltage-Max 30 V
Surface Mount YES
Technology SCHOTTKY
Terminal Form FLAT
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30

Alternate Parts for CRS03(TE85L,Q,M)

This table gives cross-reference parts and alternative options found for CRS03(TE85L,Q,M). The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of CRS03(TE85L,Q,M), but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
MXUMAF5818 Microsemi Corporation Check for Price Rectifier Diode, Schottky, 1 Element, 1A, 30V V(RRM), Silicon, PLASTIC PACKAGE-2 CRS03(TE85L,Q,M) vs MXUMAF5818
SS30-HF-W Rectron Semiconductor Check for Price Rectifier Diode, Schottky, 1 Element, 1A, 30V V(RRM), Silicon, CRS03(TE85L,Q,M) vs SS30-HF-W
B5818LWS-TP Micro Commercial Components Check for Price Rectifier Diode, CRS03(TE85L,Q,M) vs B5818LWS-TP
RB162M-30 ROHM Semiconductor Check for Price Rectifier Diode, Schottky, 1 Element, 1A, 30V V(RRM), Silicon, PMDU, 2 PIN CRS03(TE85L,Q,M) vs RB162M-30
56-5818 Minireel Components Check for Price Rectifier Diode, Schottky, 1 Element, 1A, 30V V(RRM), Silicon CRS03(TE85L,Q,M) vs 56-5818
B5818WSRQG Taiwan Semiconductor Check for Price Rectifier Diode, Schottky, 1 Element, 1A, 30V V(RRM), Silicon CRS03(TE85L,Q,M) vs B5818WSRQG
B5818W-TP Micro Commercial Components Check for Price Rectifier Diode, Schottky, 1 Element, 1A, 30V V(RRM), Silicon, ROHS COMPLIANT, PLASTIC PACKAGE-2 CRS03(TE85L,Q,M) vs B5818W-TP
SDB130 Kodenshi Sensing Check for Price SIGNAL DIODE CRS03(TE85L,Q,M) vs SDB130
KLFM130-MS Formosa Microsemi Co Ltd Check for Price Rectifier Diode, Schottky, 1 Element, 1A, 30V V(RRM), Silicon, CRS03(TE85L,Q,M) vs KLFM130-MS
S13F4 Yangzhou Yangjie Electronics Co Ltd Check for Price Rectifier Diode, Schottky, 1 Element, 1A, 30V V(RRM), Silicon, CRS03(TE85L,Q,M) vs S13F4

CRS03(TE85L,Q,M) Related Parts

CRS03(TE85L,Q,M) Frequently Asked Questions (FAQ)

  • A thermal pad is recommended under the package to improve heat dissipation. A minimum of 2oz copper thickness and a thermal relief pattern are also recommended.

  • Ensure that the device is operated within the recommended voltage and current ratings, and that the PCB is designed to minimize thermal resistance. Also, consider using a thermal interface material to improve heat transfer.

  • The recommended soldering conditions are: peak temperature 260°C, time above 217°C 30s, and time above 183°C 60s. Hand soldering is not recommended.

  • Store the devices in their original packaging, away from direct sunlight and moisture. Avoid bending or flexing the leads, and handle the devices by the body, not the leads.

  • Handle the devices in an ESD-controlled environment, wear an ESD wrist strap or use an ESD mat, and avoid touching the leads or die. Use ESD-safe packaging and storage materials.
