CDCLVP111VF Information
CDCLVP111VF by Texas Instruments is a Clock Driver.
Clock Drivers are under the broader part category of Logic Components.
Digital logic governs the behavior of signals in electronic circuits, enabling complex decisions based on simple binary inputs (yes/no). Logic components perform operations from these signals. Read more about Logic Components on our Logic part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| CDCLVP111VF | Texas Instruments | 1:10 LVPECL Buffer with Selectable Input 32-LQFP -40 to 85 | |
| CDCLVP111VFR | Texas Instruments | 1:10 LVPECL Buffer with Selectable Input 32-LQFP -40 to 85 |
Price & Stock for CDCLVP111VF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-24168-ND
|
DigiKey | IC CLK BUFFER 2:10 3.5GHZ 32LQFP Min Qty: 250 Lead time: 6 Weeks Container: Tray | Temporarily Out of Stock |
|
$6.3600 | Buy Now |
|
DISTI #
595-CDCLVP111VF
|
Mouser Electronics | Clock Buffer 1:10 LVPECL Buffer w / Selectable Input A 595-CDCLVP111VFR RoHS: Compliant | 0 |
|
$6.0100 / $12.1200 | Order Now |
|
DISTI #
J56:1989_00124354
|
Arrow Electronics | Clock Driver 10-OUT 2-IN 1:10 32-Pin LQFP Tray RoHS: Compliant Min Qty: 250 Package Multiple: 250 Lead time: 6 Weeks Date Code: 2238 | Europe - 750 |
|
$5.1200 | Buy Now |
|
|
Bristol Electronics | 1489 |
|
RFQ | ||
|
|
Quest Components | 1143 |
|
$7.7040 / $11.5560 | Buy Now |
Part Details for CDCLVP111VF
CDCLVP111VF CAD Models
CDCLVP111VF Part Data Attributes
|
|
CDCLVP111VF
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
CDCLVP111VF
Texas Instruments
1:10 LVPECL buffer with selectable input 32-LQFP -40 to 85
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | QFP | |
| Package Description | LQFP-32 | |
| Pin Count | 32 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Additional Feature | LVECL MODE: VCC = 0V WITH VEE = -2.375V TO -3.8V; ALSO OPERATES AT 3.3 V SUPPLY | |
| Family | 111 | |
| Input Conditioning | DIFFERENTIAL MUX | |
| JESD-30 Code | S-PQFP-G32 | |
| JESD-609 Code | e4 | |
| Length | 7 mm | |
| Logic IC Type | LOW SKEW CLOCK DRIVER | |
| Max I(ol) | 0.005 A | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Inverted Outputs | ||
| Number of Terminals | 32 | |
| Number of True Outputs | 10 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | LQFP | |
| Package Equivalence Code | QFP32,.35SQ,32 | |
| Package Shape | SQUARE | |
| Package Style | FLATPACK, LOW PROFILE | |
| Packing Method | TRAY | |
| Peak Reflow Temperature (Cel) | 260 | |
| Power Supply Current-Max (ICC) | 85 mA | |
| Prop. Delay@Nom-Sup | 0.35 ns | |
| Propagation Delay (tpd) | 0.35 ns | |
| Qualification Status | Not Qualified | |
| Same Edge Skew-Max (tskwd) | 0.03 ns | |
| Seated Height-Max | 1.6 mm | |
| Supply Voltage-Max (Vsup) | 3.8 V | |
| Supply Voltage-Min (Vsup) | 2.375 V | |
| Supply Voltage-Nom (Vsup) | 2.5 V | |
| Surface Mount | YES | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.8 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 7 mm | |
| fmax-Min | 3500 MHz |
