CDBHM160L-HF Information
CDBHM160L-HF by Comchip Technology Corporation Ltd is a Bridge Rectifier Diode.
Bridge Rectifier Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for CDBHM160L-HF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
641-1431-1-ND
|
DigiKey | BRIDGE RECT 1PHASE 60V 1A MBS Min Qty: 1 Lead time: 10 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
223221 In Stock |
|
$0.2680 / $1.2000 | Buy Now |
|
DISTI #
750-CDBHM160L-HF
|
Mouser Electronics | Schottky Diodes & Rectifiers Schottky Brdge Rect 1A 60V Low Vf RoHS: Compliant | 8428 |
|
$0.2810 / $0.9400 | Buy Now |
|
DISTI #
V72:2272_14718603
|
Arrow Electronics | Rectifier Bridge Diode Single 60V 1A 4-Pin Case MBS T/R RoHS: Compliant Min Qty: 3 Package Multiple: 1 Lead time: 10 Weeks Date Code: 2208 Container: Cut Strips | Americas - 3 |
|
$0.2779 | Buy Now |
|
|
NAC | Bridge Rectifier Diode, Schottky, 1A, 60V V(RRM) RoHS: Compliant Min Qty: 2500 Package Multiple: 2500 | 0 |
|
$0.2820 / $0.6900 | Buy Now |
Part Details for CDBHM160L-HF
CDBHM160L-HF CAD Models
CDBHM160L-HF Part Data Attributes
|
|
CDBHM160L-HF
Comchip Technology Corporation Ltd
Buy Now
Datasheet
|
Compare Parts:
CDBHM160L-HF
Comchip Technology Corporation Ltd
Bridge Rectifier Diode, Schottky, 1A, 60V V(RRM),
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | COMCHIP TECHNOLOGY CO LTD | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.80 | |
| Samacsys Manufacturer | Comchip Technology | |
| Breakdown Voltage-Min | 60 V | |
| Configuration | BRIDGE, 4 ELEMENTS | |
| Diode Element Material | SILICON | |
| Diode Type | BRIDGE RECTIFIER DIODE | |
| Forward Voltage-Max (VF) | 0.65 V | |
| JESD-30 Code | R-PDSO-G4 | |
| Non-rep Pk Forward Current-Max | 40 A | |
| Number of Elements | 4 | |
| Number of Phases | 1 | |
| Number of Terminals | 4 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -55 °C | |
| Output Current-Max | 0.8 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Reference Standard | UL RECOGNIZED | |
| Rep Pk Reverse Voltage-Max | 60 V | |
| Surface Mount | YES | |
| Technology | SCHOTTKY | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
