CD54HCT27F3A Information
CD54HCT27F3A by Texas Instruments is a Gate.
Gates are under the broader part category of Logic Components.
Digital logic governs the behavior of signals in electronic circuits, enabling complex decisions based on simple binary inputs (yes/no). Logic components perform operations from these signals. Read more about Logic Components on our Logic part category page.
Part Details for CD54HCT27F3A
CD54HCT27F3A CAD Models
CD54HCT27F3A Part Data Attributes
|
|
CD54HCT27F3A
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
CD54HCT27F3A
Texas Instruments
Military 3-ch, 3-input, 4.5-V to 5.5-V NOR gates 14-CDIP -55 to 125
|
| Pbfree Code | Yes | |
| Rohs Code | No | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | DIP | |
| Package Description | CERAMIC, DIP-14 | |
| Pin Count | 14 | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Family | HCT | |
| JESD-30 Code | R-GDIP-T14 | |
| JESD-609 Code | e0 | |
| Length | 19.56 mm | |
| Load Capacitance (CL) | 50 pF | |
| Logic IC Type | NOR GATE | |
| Max I(ol) | 0.004 A | |
| Number of Functions | 3 | |
| Number of Inputs | 3 | |
| Number of Terminals | 14 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | CERAMIC, GLASS-SEALED | |
| Package Code | DIP | |
| Package Equivalence Code | DIP14,.3 | |
| Package Shape | RECTANGULAR | |
| Package Style | IN-LINE | |
| Packing Method | TUBE | |
| Power Supply Current-Max (ICC) | 0.04 mA | |
| Prop. Delay@Nom-Sup | 35 ns | |
| Propagation Delay (tpd) | 35 ns | |
| Qualification Status | Not Qualified | |
| Schmitt Trigger | NO | |
| Screening Level | 38535Q/M;38534H;883B | |
| Seated Height-Max | 5.08 mm | |
| Supply Voltage-Max (Vsup) | 5.5 V | |
| Supply Voltage-Min (Vsup) | 4.5 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | NO | |
| Technology | CMOS | |
| Temperature Grade | MILITARY | |
| Terminal Finish | Tin/Lead (Sn/Pb) | |
| Terminal Form | THROUGH-HOLE | |
| Terminal Pitch | 2.54 mm | |
| Terminal Position | DUAL | |
| Width | 7.62 mm |
CD54HCT27F3A Frequently Asked Questions (FAQ)
-
The recommended operating voltage range for CD54HCT27F3A is 4.5V to 5.5V.
-
To ensure proper thermal management, it is recommended to provide a heat sink or a thermal pad on the package, and to keep the ambient temperature within the specified operating range.
-
The maximum clock frequency supported by CD54HCT27F3A is 30 MHz.
-
Yes, CD54HCT27F3A can be used in a 3.3V system, but it is recommended to use a voltage regulator to ensure a stable 3.3V supply, and to check the device's performance at the lower voltage.
-
It is recommended to follow a controlled power-up and power-down sequence to prevent damage to the device, such as slowly ramping up the power supply voltage and ensuring that all inputs are at a valid logic level before applying power.
