C0603C223K5RACAUTO7411 Information
C0603C223K5RACAUTO7411 by KEMET Corporation is a Ceramic Capacitor.
Ceramic Capacitors are under the broader part category of Capacitors.
A capacitor is a passive electronic component that stores energy. Capacitors are commonly used for energy storage, voltage suppression, and signal filtering. Read more about Capacitors on our Capacitors part category page.
Price & Stock for C0603C223K5RACAUTO7411
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
399-C0603C223K5RACAUTO7411CT-ND
|
DigiKey | CAP CER 0.022UF 50V X7R 0603 Min Qty: 1 Lead time: 11 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
12674 In Stock |
|
$0.0117 / $0.1100 | Buy Now |
|
DISTI #
80-C0603C223K5RAULR
|
Mouser Electronics | Multilayer Ceramic Capacitors MLCC - SMD/SMT 50V 0.022uF X7R 0603 10% AEC-Q200 RoHS: Compliant | 0 |
|
$0.0120 / $0.1000 | Order Now |
|
DISTI #
C0603C223K5RACAUTO74
|
TTI | Multilayer Ceramic Capacitors MLCC - SMD/SMT .022UF 50V 10% 0603 RoHS: Compliant pbFree: Pb-Free Min Qty: 15000 Package Multiple: 15000 Container: Reel |
Americas - 870000 In Stock |
|
$0.0111 / $0.0121 | Buy Now |
|
DISTI #
C0603C223K5RACAUTO7411
|
Avnet Asia | KEMC0603C223K5RACAUTO7411 0.022 UF 10% (Alt: C0603C223K5RACAUTO7411) RoHS: Compliant Min Qty: 15000 Package Multiple: 15000 Lead time: 27 Weeks, 0 Days | 0 |
|
$0.0114 / $0.0128 | Buy Now |
|
|
Vyrian | Capacitors | 441171 |
|
RFQ |
Part Details for C0603C223K5RACAUTO7411
C0603C223K5RACAUTO7411 CAD Models
C0603C223K5RACAUTO7411 Part Data Attributes
|
|
C0603C223K5RACAUTO7411
KEMET Corporation
Buy Now
Datasheet
|
Compare Parts:
C0603C223K5RACAUTO7411
KEMET Corporation
Capacitor, Ceramic, Chip, General Purpose, 0.022uF, 50V, ±10%, X7R, 0603 (1608 mm), -55º ~ +125ºC, 13" Special Reel/Unmarked
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | KEMET ELECTRONICS CORP | |
| Part Package Code | 0603 | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8532.24.00.20 | |
| Samacsys Manufacturer | KEMET | |
| Capacitance | 0.022 µF | |
| Capacitor Type | CERAMIC CAPACITOR | |
| Dielectric Material | CERAMIC | |
| Height | 0.8 mm | |
| JESD-609 Code | e3 | |
| Length | 1.6 mm | |
| Mounting Feature | SURFACE MOUNT | |
| Multilayer | Yes | |
| Negative Tolerance | 10% | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Style | SMT | |
| Packing Method | TR, PUNCHED PAPER, 13 INCH | |
| Positive Tolerance | 10% | |
| Rated (DC) Voltage (URdc) | 50 V | |
| Reference Standard | AEC-Q200 | |
| Size Code | 0603 | |
| Surface Mount | YES | |
| Temperature Characteristics Code | X7R | |
| Temperature Coefficient | 15% ppm/°C | |
| Terminal Finish | MATTE TIN OVER NICKEL | |
| Terminal Shape | WRAPAROUND | |
| Width | 0.8 mm |
C0603C223K5RACAUTO7411 Frequently Asked Questions (FAQ)
-
The recommended land pattern for the C0603C223K5RACAUTO7411 capacitor is a rectangular pad with a size of 0.6mm x 0.3mm, with a non-solder mask defined (NSMD) pad shape. The land pattern should be designed to accommodate the capacitor's termination style, which is a silver epoxy terminations.
-
The C0603C223K5RACAUTO7411 capacitor's capacitance value and ESR (Equivalent Series Resistance) change with temperature. The capacitance value decreases by approximately 10% over the operating temperature range of -55°C to 125°C, while the ESR increases by approximately 20% over the same temperature range. These changes should be considered in the design to ensure the capacitor meets the required specifications.
-
The C0603C223K5RACAUTO7411 capacitor is suitable for high-frequency applications up to 1 GHz. The capacitor's impedance and ESR are relatively low, making it suitable for decoupling and filtering applications in high-frequency circuits. However, the capacitor's performance should be verified through simulation and testing to ensure it meets the specific requirements of the application.
-
The C0603C223K5RACAUTO7411 capacitor has a high reliability and lifespan, with a typical failure rate of < 1% per 1,000 hours at 85°C and 85% relative humidity. The capacitor's lifespan is estimated to be > 10 years at room temperature, with a derating factor applied for higher temperatures and humidity levels.
-
Yes, the C0603C223K5RACAUTO7411 capacitor is RoHS (Restriction of Hazardous Substances) and REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) compliant, meeting the requirements of the European Union's directives for environmental protection.
