BVN-M-R001-1.0 Information
BVN-M-R001-1.0 by Isabellenhuette is a Fixed Resistor.
Fixed Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| MP-6ARJ45SNNR-001 | Amphenol Cables on Demand | Amphenol MP-6ARJ45SNNR-001 CAT6A FTP Shielded Patch Cable (650-MHz) with Snagless CAT-6A Shielded RJ45 Connectors (10GbE Optimized) - Red 1ft | |
| MP-64RJ4528GR-001 | Amphenol Cables on Demand | Amphenol MP-64RJ4528GR-001 Slim Category-6 (Thin CAT6) UTP 28-AWG Network Patch Cable (550-MHz) with Snagless RJ45 Connectors - Red 1ft | |
| MP-64RJ45UNNR-001 | Amphenol Cables on Demand | Amphenol MP-64RJ45UNNR-001 Cat6 UTP Patch Cable (550-MHz) with Snagless RJ45 Connectors - Red 1ft |
Price & Stock for BVN-M-R001-1.0
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
4423-BVN-M-R001-1.0CT-ND
|
DigiKey | RESISTOR - ISA-WELD SHUNT, 0.001 Min Qty: 1 Lead time: 40 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
9294 In Stock |
|
$0.6625 / $2.3400 | Buy Now |
|
|
NAC | RoHS: Compliant Min Qty: 1 Package Multiple: 9000 | 50 |
|
$0.7100 / $0.8800 | Buy Now |
Part Details for BVN-M-R001-1.0
BVN-M-R001-1.0 CAD Models
BVN-M-R001-1.0 Part Data Attributes
|
|
BVN-M-R001-1.0
Isabellenhuette
Buy Now
Datasheet
|
Compare Parts:
BVN-M-R001-1.0
Isabellenhuette
Fixed Resistor
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ISABELLENHUETTE HEUSLER GMBH & CO KG | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8533.21.00.30 | |
| Samacsys Manufacturer | Isabellenhütte | |
| Additional Feature | PRECISION | |
| Construction | Rectangular | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 4 | |
| Operating Temperature-Max | 170 °C | |
| Operating Temperature-Min | -65 °C | |
| Package Height | 1.9 mm | |
| Package Length | 3.1 mm | |
| Package Style | SMT | |
| Package Width | 4.1 mm | |
| Packing Method | TR | |
| Rated Power Dissipation (P) | 7 W | |
| Rated Temperature | 70 °C | |
| Reference Standard | AEC-Q200 | |
| Resistance | 0.001 Ω | |
| Resistor Type | FIXED RESISTOR | |
| Size Code | 1216 | |
| Surface Mount | YES | |
| Technology | METAL STRIP | |
| Temperature Coefficient | 50 ppm/°C | |
| Terminal Shape | J BEND | |
| Tolerance | 1% |
