BTS730 Information
BTS730 by Infineon Technologies AG is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for BTS730
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
|
Bristol Electronics | 927 |
|
RFQ | ||
|
|
Bristol Electronics | Min Qty: 2 | 9 |
|
$2.7664 / $4.2560 | Buy Now |
|
|
Quest Components | 741 |
|
$3.4200 / $6.8400 | Buy Now | |
|
|
Quest Components | 7 |
|
$2.8500 / $5.7000 | Buy Now | |
|
|
Chip 1 Exchange | INSTOCK | 958 |
|
RFQ | |
|
|
Win Source Electronics | IC PWM PWR N-CH UNIT PDSO-20 | 22000 |
|
$3.7538 / $5.6306 | Buy Now |
Part Details for BTS730
BTS730 CAD Models
BTS730 Part Data Attributes
|
|
BTS730
Infineon Technologies AG
Buy Now
Datasheet
|
Compare Parts:
BTS730
Infineon Technologies AG
Fluorescent Light Controller, PDSO20, PLASTIC, DSO-20
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | INFINEON TECHNOLOGIES AG | |
| Part Package Code | SOIC | |
| Package Description | PLASTIC, DSO-20 | |
| Pin Count | 20 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Infineon | |
| Analog IC - Other Type | FLUORESCENT LIGHT CONTROLLER | |
| Control Technique | PULSE WIDTH MODULATION | |
| Input Voltage-Max | 16.9 V | |
| Input Voltage-Min | 5.9 V | |
| Input Voltage-Nom | 12 V | |
| JESD-30 Code | R-PDSO-G20 | |
| JESD-609 Code | e3 | |
| Length | 12.8 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 1 | |
| Number of Terminals | 20 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 2.65 mm | |
| Surface Mount | YES | |
| Switcher Configuration | SINGLE | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Width | 7.5 mm |
Alternate Parts for BTS730
This table gives cross-reference parts and alternative options found for BTS730. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of BTS730, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| BTS630E3230 | Siemens | Check for Price | Fluorescent Light Controller, PSFM7 | BTS730 vs BTS630E3230 |
BTS730 Frequently Asked Questions (FAQ)
-
The maximum current rating of the BTS730 is 30A, but it can be increased to 40A with proper heat sinking and cooling.
-
The BTS730 has an internal overvoltage protection (OVP) circuit that limits the voltage to 45V. However, it's still recommended to add external protection, such as a TVS diode, to ensure the device is protected from high voltage spikes.
-
The minimum input voltage required for the BTS730 to operate is 6.5V, but it's recommended to use a minimum of 8V to ensure stable operation.
-
The BTS730 is rated for operation up to 150°C, but it's recommended to derate the current and voltage ratings at high temperatures to ensure reliable operation.
-
The BTS730 has a thermal pad on the bottom of the package that should be connected to a heat sink or a thermal interface material to ensure proper cooling. A thermal resistance of less than 10°C/W is recommended.
