BSS138K-13 Information
BSS138K-13 by Diodes Incorporated is a Small Signal Field-Effect Transistor.
Small Signal Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for BSS138K-13
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
28AK6535
|
Newark | Mosfet, N-Ch, 50V, 0.31A, Sot-23 Rohs Compliant: Yes |Diodes Inc. BSS138K-13 RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 5420 |
|
$0.0620 / $0.1260 | Buy Now |
|
DISTI #
BSS138K-13DICT-ND
|
DigiKey | MOSFET N-CH 50V 310MA SOT23 Min Qty: 1 Lead time: 12 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
323691 In Stock |
|
$0.0295 / $0.1400 | Buy Now |
|
DISTI #
BSS138K-13
|
Avnet Americas | Power MOSFET, N Channel, 50 V, 310 mA, 1.3 ohm, SOT-23, Surface Mount - Tape and Reel (Alt: BSS138K-13) RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Lead time: 12 Weeks, 0 Days Container: Reel | 6000000 Factory Stock |
|
$0.0260 / $0.0266 | Buy Now |
|
DISTI #
621-BSS138K-13
|
Mouser Electronics | MOSFETs BSS Family SOT23 T&R 10K RoHS: Compliant | 301447 |
|
$0.0290 / $0.1400 | Buy Now |
|
DISTI #
E02:0323_12765705
|
Arrow Electronics | Trans MOSFET N-CH 50V 0.31A 3-Pin SOT-23 T/R RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Lead time: 8 Weeks Date Code: 2425 | Europe - 10000 |
|
$0.0308 | Buy Now |
|
DISTI #
V72:2272_21672051
|
Arrow Electronics | Trans MOSFET N-CH 50V 0.31A 3-Pin SOT-23 T/R RoHS: Compliant Min Qty: 2703 Package Multiple: 1 Lead time: 12 Weeks Date Code: 2424 Container: Cut Strips | Americas - 3761 |
|
$0.0271 / $0.0370 | Buy Now |
|
|
Quest Components | SMALL SIGNAL FIELD-EFFECT TRANSISTOR | 1687 |
|
$0.0414 / $0.0920 | Buy Now |
|
|
Quest Components | SMALL SIGNAL FIELD-EFFECT TRANSISTOR | 107 |
|
$0.0630 / $0.2100 | Buy Now |
|
DISTI #
BSS138K-13
|
Avnet Silica | Power MOSFET N Channel 50 V 310 mA 13 ohm SOT23 Surface Mount (Alt: BSS138K-13) RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Lead time: 10 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
|
New Advantage Corporation | RoHS: Compliant Min Qty: 1 Package Multiple: 10000 | 30000 |
|
$0.0377 / $0.0408 | Buy Now |
Part Details for BSS138K-13
BSS138K-13 CAD Models
BSS138K-13 Part Data Attributes
|
|
BSS138K-13
Diodes Incorporated
Buy Now
Datasheet
|
Compare Parts:
BSS138K-13
Diodes Incorporated
Small Signal Field-Effect Transistor,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | DIODES INC | |
| Package Description | SOT-23, 3 PIN | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 12 Weeks | |
| Samacsys Manufacturer | Diodes Incorporated | |
| Configuration | SINGLE WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 50 V | |
| Drain Current-Max (ID) | 0.31 A | |
| Drain-source On Resistance-Max | 3.5 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| Feedback Cap-Max (Crss) | 2.2 pF | |
| JESD-30 Code | R-PDSO-G3 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 3 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity/Channel Type | N-CHANNEL | |
| Power Dissipation-Max (Abs) | 0.54 W | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON |
