BSS138-F085 by:

N-Channel Logic Level Enhancement Mode Field Effect Transistor 60V, 220mA, 3.5Ω, SOT-23 3L, 3000-REEL, Automotive Qualified

Part Details for BSS138-F085 by onsemi

Results Overview of BSS138-F085 by onsemi

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

BSS138-F085 Information

BSS138-F085 by onsemi is a Small Signal Field-Effect Transistor.
Small Signal Field-Effect Transistors are under the broader part category of Transistors.

A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.

Price & Stock for BSS138-F085

Part # Distributor Description Stock Price Buy
DISTI # 48AC0673
Newark N-Channel Logic Level Enhancement Mode Field Effect Transistor 60V, 220Ma, 3.5/Reel |Onsemi BSS138-F085 RoHS: Not Compliant Min Qty: 6000 Package Multiple: 1 Date Code: 0 Container: Reel 0
Buy Now
DISTI # BSS138-F085
Avnet Americas SINGLE NCH LOGIC LEVEL ENHANCEMENT MODE FIELD EFFECT XTOR - Tape and Reel (Alt: BSS138-F085) RoHS: Compliant Min Qty: 1429 Package Multiple: 1 Lead time: 0 Weeks, 2 Days Container: Reel 3000 Partner Stock
  • 1,429 $0.4672
  • 1,500 $0.4585
  • 2,900 $0.4515
  • 7,200 $0.4445
  • 15,000 $0.4375
$0.4375 / $0.4672 Buy Now
DISTI # BSS138-F085
Avnet Silica SINGLE NCH LOGIC LEVEL ENHANCEMENT MODE FIELD EFFECT XTOR (Alt: BSS138-F085) RoHS: Compliant Min Qty: 9000 Package Multiple: 3000 Lead time: 143 Weeks, 0 Days Silica - 0
Buy Now
DISTI # BSS138-F085
EBV Elektronik SINGLE NCH LOGIC LEVEL ENHANCEMENT MODE FIELD EFFECT XTOR (Alt: BSS138-F085) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 143 Weeks, 0 Days EBV - 0
Buy Now
Flip Electronics Stock, ship today 3000
RFQ
Vyrian Transistors 2718
RFQ

Part Details for BSS138-F085

BSS138-F085 CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

BSS138-F085 Part Data Attributes

Parametric Data
BSS138-F085 onsemi
Buy Now Datasheet
Compare Parts:
BSS138-F085 onsemi N-Channel Logic Level Enhancement Mode Field Effect Transistor 60V, 220mA, 3.5Ω, SOT-23 3L, 3000-REEL, Automotive Qualified
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Obsolete
Ihs Manufacturer ONSEMI
Part Package Code SOT-23 3L
Package Description SOT-23, 3 PIN
Manufacturer Package Code 318BM
Reach Compliance Code compliant
ECCN Code EAR99
Factory Lead Time 2 Days
Samacsys Manufacturer onsemi
Configuration SINGLE WITH BUILT-IN DIODE
DS Breakdown Voltage-Min 50 V
Drain Current-Max (ID) 0.22 A
Drain-source On Resistance-Max 6 Ω
FET Technology METAL-OXIDE SEMICONDUCTOR
JESD-30 Code R-PDSO-G3
Moisture Sensitivity Level 1
Number of Elements 1
Number of Terminals 3
Operating Mode ENHANCEMENT MODE
Operating Temperature-Max 150 °C
Operating Temperature-Min -55 °C
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Peak Reflow Temperature (Cel) 260
Polarity/Channel Type N-CHANNEL
Power Dissipation-Max (Abs) 0.36 W
Surface Mount YES
Terminal Form GULL WING
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
Transistor Application SWITCHING
Transistor Element Material SILICON

Alternate Parts for BSS138-F085

This table gives cross-reference parts and alternative options found for BSS138-F085. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of BSS138-F085, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
BSS138_F085 onsemi Check for Price N-Channel Logic Level Enhancement Mode Field Effect Transistor, SOT-23 3L, 15000-TAPE REEL BSS138-F085 vs BSS138_F085
BSS138TA Diodes Incorporated Check for Price Small Signal Field-Effect Transistor, 0.2A I(D), 50V, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, SOT-23, 3 PIN BSS138-F085 vs BSS138TA
BSS138LT1G onsemi $0.0968 Single N-Channel Logic Level Power MOSFET 50V, 200mA, 3.5Ω, SOT-23 (TO-236) 3 LEAD, 3000-REEL BSS138-F085 vs BSS138LT1G
BSS138LT1 onsemi Check for Price Single N-Channel Logic Level Power MOSFET 50V, 200mA, 3.5Ω, SOT-23 (TO-236) 3 LEAD, 3000-REEL BSS138-F085 vs BSS138LT1
BSS138 onsemi $0.1004 N-Channel Logic Level Enhancement Mode Field Effect Transistor, 50V, 220mA, SOT-23 (TO-236) 2.90x1.30x1.00, 1.90P, 3000-REEL BSS138-F085 vs BSS138
BSS138L onsemi $0.0534 Single N-Channel Logic Level Power MOSFET 50V, 200mA, 3.5Ω, SOT-23 (TO-236) 2.90x1.30x1.00, 1.90P, 3000-REEL BSS138-F085 vs BSS138L
BSS138-7-F Diodes Incorporated $0.0340 Small Signal Field-Effect Transistor, 0.2A I(D), 50V, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, GREEN, PLASTIC PACKAGE-3 BSS138-F085 vs BSS138-7-F
BSS138LT3G onsemi $0.0565 Single N-Channel Logic Level Power MOSFET 50V, 200mA, 3.5Ω, SOT-23 (TO-236) 3 LEAD, 10000-REEL BSS138-F085 vs BSS138LT3G
BSS138-G onsemi Check for Price N-Channel Logic Level Enhancement Mode Field Effect Transistor, 50V, 220mA, SOT-23 3L, 3000-REEL BSS138-F085 vs BSS138-G
BSS138DW-7-F Diodes Incorporated $0.0542 Small Signal Field-Effect Transistor, 0.2A I(D), 50V, 2-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, GREEN, PLASTC PACKAGE-6 BSS138-F085 vs BSS138DW-7-F

BSS138-F085 Frequently Asked Questions (FAQ)

  • The maximum operating temperature range for the BSS138-F085 is -55°C to 150°C.

  • Yes, the BSS138-F085 is suitable for high-frequency switching applications due to its low RDS(on) and low gate charge.

  • Yes, the BSS138-F085 is AEC-Q101 qualified, making it suitable for automotive applications.

  • The maximum drain-source voltage rating for the BSS138-F085 is 50V.

  • The BSS138-F085 is a logic-level MOSFET, which means it can be driven directly from a microcontroller or other low-voltage logic source.
