BSL307SPL6327HTSA1 Information
BSL307SPL6327HTSA1 by Infineon Technologies AG is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for BSL307SPL6327HTSA1
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
85973300
|
Verical | Trans MOSFET P-CH 30V 5.5A Automotive 6-Pin TSOP T/R RoHS: Compliant Min Qty: 1299 Package Multiple: 1 Date Code: 1401 | Americas - 666689 |
|
$0.2889 | Buy Now |
|
|
Rochester Electronics | Power Field-Effect Transistor, 5.5A, 30V, 0.043ohm, P-Channel, MOSFET RoHS: Compliant Status: Obsolete Min Qty: 1 | 666689 |
|
$0.1433 / $0.2311 | Buy Now |
|
DISTI #
SP000095798
|
EBV Elektronik | Trans MOSFET PCH 30V 55A 6Pin TSOP TR (Alt: SP000095798) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 143 Weeks, 0 Days | EBV - 0 |
|
Buy Now | |
|
|
Vyrian | Transistors | 675634 |
|
RFQ |
Part Details for BSL307SPL6327HTSA1
BSL307SPL6327HTSA1 CAD Models
BSL307SPL6327HTSA1 Part Data Attributes
|
|
BSL307SPL6327HTSA1
Infineon Technologies AG
Buy Now
Datasheet
|
Compare Parts:
BSL307SPL6327HTSA1
Infineon Technologies AG
Power Field-Effect Transistor, 5.5A I(D), 30V, 0.043ohm, 1-Element, P-Channel, Silicon, Metal-oxide Semiconductor FET, ROHS COMPLIANT, PLASTIC, TSOP-6
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | INFINEON TECHNOLOGIES AG | |
| Part Package Code | TSOP | |
| Package Description | ROHS COMPLIANT, PLASTIC, TSOP-6 | |
| Pin Count | 6 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 4 Weeks | |
| Samacsys Manufacturer | Infineon | |
| Additional Feature | LOGIC LEVEL COMPATIBLE, AVALANCHE RATED | |
| Avalanche Energy Rating (Eas) | 44 mJ | |
| Configuration | SINGLE WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 30 V | |
| Drain Current-Max (ID) | 5.5 A | |
| Drain-source On Resistance-Max | 0.043 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| JESD-30 Code | R-PDSO-G6 | |
| Number of Elements | 1 | |
| Number of Terminals | 6 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 150 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Polarity/Channel Type | P-CHANNEL | |
| Pulsed Drain Current-Max (IDM) | 22 A | |
| Qualification Status | Not Qualified | |
| Surface Mount | YES | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Transistor Element Material | SILICON |
