BFU520WX Information
BFU520WX by NXP Semiconductors is an RF Small Signal Bipolar Transistor.
RF Small Signal Bipolar Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for BFU520WX
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
2776270
|
Farnell | RF TRANSISTOR, NPN, 12V, 10GHZ, SOT-323 RoHS: Compliant Min Qty: 5 Lead time: 13 Weeks, 0 Days Container: Cut Tape | 9923 |
|
$0.1608 / $0.3820 | Buy Now |
|
DISTI #
2776270RL
|
Farnell | RF TRANSISTOR, NPN, 12V, 10GHZ, SOT-323 RoHS: Compliant Min Qty: 100 Lead time: 13 Weeks, 0 Days Container: Reel | 9923 |
|
$0.1608 / $0.2051 | Buy Now |
|
DISTI #
568-11505-1-ND
|
DigiKey | RF TRANS NPN 12V 10GHZ SC-70 Min Qty: 1 Lead time: 13 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
25142 In Stock |
|
$0.1411 / $0.3600 | Buy Now |
|
DISTI #
BFU520WX
|
Avnet Americas | Bipolar - RF Transistor, NPN, 12 V, 10 GHz, 450 mW, 30 mA, SOT-323 - Tape and Reel (Alt: BFU520WX) RoHS: Compliant Min Qty: 6000 Package Multiple: 3000 Lead time: 13 Weeks, 0 Days Container: Reel | 0 |
|
$0.1240 / $0.1282 | Buy Now |
|
DISTI #
771-BFU520WX
|
Mouser Electronics | RF Bipolar Transistors NPN wideband silicon RF transistor RoHS: Compliant | 38515 |
|
$0.1430 / $0.3600 | Buy Now |
|
DISTI #
V72:2272_06518338
|
Arrow Electronics | Trans RF BJT NPN 16V 0.05A 450mW 3-Pin SC-70 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 13 Weeks Date Code: 2204 Container: Cut Strips | Americas - 100 |
|
$0.1411 / $0.3507 | Buy Now |
|
DISTI #
69059761
|
Verical | Trans RF BJT NPN 16V 0.05A 450mW 3-Pin SC-70 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 229 Package Multiple: 1 Date Code: 2232 | Americas - 1505 |
|
$0.1350 / $0.3360 | Buy Now |
|
DISTI #
86267564
|
Verical | Trans RF BJT NPN 16V 0.05A 450mW 3-Pin SC-70 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 42 Package Multiple: 1 Date Code: 2204 | Americas - 100 |
|
$0.1411 / $0.2166 | Buy Now |
|
DISTI #
BFU520WX
|
Richardson RFPD | RF SMALL SIGNAL TRANSISTOR BIPOLAR/HBT RoHS: Compliant Min Qty: 6000 | 0 |
|
$0.1500 | Buy Now |
|
DISTI #
BFU520WX
|
Avnet Silica | Bipolar RF Transistor NPN 12 V 10 GHz 450 mW 30 mA SOT323 (Alt: BFU520WX) RoHS: Compliant Min Qty: 6000 Package Multiple: 3000 Lead time: 15 Weeks, 0 Days | Silica - 0 |
|
Buy Now |
Part Details for BFU520WX
BFU520WX CAD Models
BFU520WX Part Data Attributes
|
|
BFU520WX
NXP Semiconductors
Buy Now
Datasheet
|
Compare Parts:
BFU520WX
NXP Semiconductors
BFU520W - NPN wideband silicon RF transistor SC-70 3-Pin
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | NXP SEMICONDUCTORS | |
| Part Package Code | SC-70 | |
| Package Description | SC-70, 3 PIN | |
| Pin Count | 3 | |
| Manufacturer Package Code | SOT323 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.21.00 | |
| Factory Lead Time | 13 Weeks | |
| Samacsys Manufacturer | NXP | |
| Additional Feature | LOW NOISE | |
| Collector Current-Max (IC) | 0.03 A | |
| Collector-Emitter Voltage-Max | 12 V | |
| Configuration | SINGLE | |
| DC Current Gain-Min (hFE) | 60 | |
| Highest Frequency Band | L BAND | |
| JESD-30 Code | R-PDSO-G3 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 3 | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity/Channel Type | NPN | |
| Reference Standard | AEC-Q101; IEC-60134 | |
| Surface Mount | YES | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Transistor Application | AMPLIFIER | |
| Transistor Element Material | SILICON | |
| Transition Frequency-Nom (fT) | 10000 MHz |
