BCR562E6327HTSA1 Information
BCR562E6327HTSA1 by Infineon Technologies AG is a Small Signal Bipolar Transistor.
Small Signal Bipolar Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for BCR562E6327HTSA1
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
03AJ0033
|
Newark | Brt Trans, 4.7K/4.7Kohm, Sot23, Collector Emitter Voltage V(Br)Ceo:-50V, Continuous Collector Current Ic:-500Ma, Base Input Resistor R1:4.7Kohm, Base-Emitter Resistor R2:4.7Kohm, Resistor Ratio, R1/R2:1(Ratio), Rf Transistor Rohs Compliant: Yes |Infineon BCR562E6327HTSA1 RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 0 |
|
$0.0940 / $0.3020 | Buy Now |
|
DISTI #
BCR562E6327HTSA1CT-ND
|
DigiKey | TRANS PREBIAS PNP 50V SOT23 Min Qty: 1 Lead time: 4 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
1821 In Stock |
|
$0.0529 / $0.3300 | Buy Now |
|
DISTI #
BCR562E6327HTSA1
|
Avnet Americas | Trans Digital BJT PNP 50V 500mA 3-Pin SOT-23 T/R - Tape and Reel (Alt: BCR562E6327HTSA1) RoHS: Compliant Min Qty: 18000 Package Multiple: 3000 Lead time: 4 Weeks, 0 Days Container: Reel | 0 |
|
$0.0393 / $0.0419 | Buy Now |
|
DISTI #
726-BCR562E6327HTSA1
|
Mouser Electronics | Digital Transistors PNP Silicon Digital TRANSISTOR RoHS: Compliant | 1100 |
|
$0.0520 / $0.3300 | Buy Now |
|
DISTI #
BCR562E6327HTSA1
|
TME | Transistor: PNP, bipolar, BRT, 50V, 0.5A, 0.33W, SOT23, R1: 4.7kΩ Min Qty: 1 | 0 |
|
$0.0660 / $0.8720 | RFQ |
|
DISTI #
BCR562E6327HTSA1
|
IBS Electronics | BIPOLAR JUNCTION TRANSISTOR PNP 500 MA 50 V SMD SOT-23 BCR562E6327 Min Qty: 18000 Package Multiple: 1 | 0 |
|
$0.0568 / $0.0611 | Buy Now |
|
DISTI #
TDSTD6872
|
Rutronik | PNP DIGITALTRANS. 50V SOT23 RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Container: Reel |
Stock DE - 9000 Stock HK - 0 Stock US - 0 Stock SG - 0 |
|
$0.0580 / $0.0688 | Buy Now |
|
|
Cytech Systems Limited | TRANS PREBIAS PNP 50V SOT23 | 9000 |
|
RFQ | |
|
DISTI #
SP000010859
|
EBV Elektronik | Trans Digital BJT PNP 50V 500mA 3Pin SOT23 TR (Alt: SP000010859) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 5 Weeks, 0 Days | EBV - 0 |
|
Buy Now | |
|
|
Vyrian | Transistors | 15034 |
|
RFQ |
Part Details for BCR562E6327HTSA1
BCR562E6327HTSA1 CAD Models
BCR562E6327HTSA1 Part Data Attributes
|
|
BCR562E6327HTSA1
Infineon Technologies AG
Buy Now
Datasheet
|
Compare Parts:
BCR562E6327HTSA1
Infineon Technologies AG
Small Signal Bipolar Transistor, 0.5A I(C), 50V V(BR)CEO, 1-Element, PNP, Silicon, ROHS COMPLIANT, SOT-23, 3 PIN
|
| Rohs Code | Yes | |
| Part Life Cycle Code | End Of Life | |
| Ihs Manufacturer | INFINEON TECHNOLOGIES AG | |
| Package Description | ROHS COMPLIANT, SOT-23, 3 PIN | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 4 Weeks | |
| Samacsys Manufacturer | Infineon | |
| Additional Feature | BUILT-IN BIAS RESISTOR RATIO 1 | |
| Collector Current-Max (IC) | 0.5 A | |
| Collector-Emitter Voltage-Max | 50 V | |
| Configuration | SINGLE WITH BUILT-IN RESISTOR | |
| DC Current Gain-Min (hFE) | 60 | |
| JESD-30 Code | R-PDSO-G3 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 3 | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Polarity/Channel Type | PNP | |
| Surface Mount | YES | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON | |
| Transition Frequency-Nom (fT) | 150 MHz |
