BC856S-QX Information
BC856S-QX by Nexperia is a Small Signal Bipolar Transistor.
Small Signal Bipolar Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for BC856S-QX
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
1727-BC856S-QX-ND
|
DigiKey | TRANS 2PNP 65V 100MA 6-TSSOP Min Qty: 30000 Lead time: 6 Weeks Container: Tape & Reel (TR) | Temporarily Out of Stock |
|
$0.0281 | Buy Now |
|
DISTI #
BC856S-QX
|
Avnet Americas | Bipolar Transistor Array, Dual PNP, 65 V, 100 mA - Tape and Reel (Alt: BC856S-QX) RoHS: Compliant Min Qty: 33000 Package Multiple: 3000 Lead time: 6 Weeks, 0 Days Container: Reel | 0 |
|
$0.0177 / $0.0197 | Buy Now |
|
DISTI #
771-BC856S-QX
|
Mouser Electronics | Bipolar Transistors - BJT 65 V, 100 mA PNP/PNP general-purpose transistor RoHS: Compliant | 9116 |
|
$0.0280 / $0.2200 | Buy Now |
|
DISTI #
E02:0323_17295907
|
Arrow Electronics | Trans GP BJT PNP 65V 0.1A 400mW 6-Pin TSSOP T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 6 Weeks Date Code: 2446 | Europe - 84000 |
|
$0.0317 / $0.0419 | Buy Now |
|
DISTI #
88153302
|
Verical | Trans GP BJT PNP 65V 0.1A 400mW 6-Pin TSSOP T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Date Code: 2446 | Americas - 84000 |
|
$0.0318 / $0.0420 | Buy Now |
|
DISTI #
BC856S-QX
|
TTI | Bipolar Transistors - BJT 65 V, 100 mA PNP/PNP general-purpose transistor RoHS: Compliant pbFree: Pb-Free Min Qty: 3000 Package Multiple: 3000 Container: Reel |
Americas - 30000 In Stock |
|
$0.0285 / $0.0297 | Buy Now |
|
DISTI #
BC856S-QX
|
TME | Transistor: PNP x2, bipolar, 65V, 0.1A, 0.4W, SC88,SOT363 Min Qty: 1 | 0 |
|
$0.0259 / $0.1990 | RFQ |
|
DISTI #
BC856S-QX
|
Avnet Asia | Bipolar Transistor Array, Dual PNP, 65 V, 100 mA (Alt: BC856S-QX) RoHS: Compliant Min Qty: 33000 Package Multiple: 3000 Lead time: 6 Weeks, 0 Days | 0 |
|
$0.0415 / $0.0464 | Buy Now |
|
DISTI #
BC856S-QX
|
Avnet Silica | Bipolar Transistor Array Dual PNP 65 V 100 mA (Alt: BC856S-QX) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 8 Weeks, 0 Days | Silica - 24000 |
|
Buy Now | |
|
DISTI #
BC856S-QX
|
EBV Elektronik | Bipolar Transistor Array Dual PNP 65 V 100 mA (Alt: BC856S-QX) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 8 Weeks, 0 Days | EBV - 0 |
|
Buy Now |
Part Details for BC856S-QX
BC856S-QX CAD Models
BC856S-QX Part Data Attributes
|
|
BC856S-QX
Nexperia
Buy Now
Datasheet
|
Compare Parts:
BC856S-QX
Nexperia
BC856S-Q - 65 V, 100 mA PNP/PNP general-purpose transistor@en-us TSSOP 6-Pin
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | NEXPERIA | |
| Part Package Code | TSSOP | |
| Package Description | SC-88, SOT-363, TSSOP-6 | |
| Pin Count | 6 | |
| Manufacturer Package Code | SOT363 | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 6 Weeks | |
| Samacsys Manufacturer | Nexperia | |
| Collector Current-Max (IC) | 0.1 A | |
| Collector-Base Capacitance-Max | 2.5 pF | |
| Collector-Emitter Voltage-Max | 65 V | |
| Configuration | SEPARATE, 2 ELEMENTS | |
| DC Current Gain-Min (hFE) | 110 | |
| JESD-30 Code | R-PDSO-G6 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 2 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -65 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Polarity/Channel Type | PNP | |
| Power Dissipation-Max (Abs) | 0.4 W | |
| Reference Standard | AEC-Q101; IEC-60134 | |
| Surface Mount | YES | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON | |
| Transition Frequency-Nom (fT) | 100 MHz | |
| VCEsat-Max | 0.3 V |
