BC817DPN-TP Information
BC817DPN-TP by Micro Commercial Components is a Small Signal Bipolar Transistor.
Small Signal Bipolar Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for BC817DPN-TP
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
353-BC817DPN-TP-ND
|
DigiKey | TRANS NPN/PNP 45V 500MA SOT-23 Min Qty: 3000 Lead time: 16 Weeks Container: Bulk | Temporarily Out of Stock |
|
$0.0773 | Buy Now |
|
DISTI #
833-BC817DPN-TP
|
Mouser Electronics | Bipolar Transistors - BJT NPN/PNP SIGNAL TRANSISTOR RoHS: Compliant | 0 |
|
$0.0510 / $0.4200 | Order Now |
|
|
Bristol Electronics | Min Qty: 14 | 960 |
|
$0.1125 / $0.3750 | Buy Now |
|
|
Quest Components | 768 |
|
$0.1000 / $0.5000 | Buy Now | |
|
|
Vyrian | Transistors | 2875 |
|
RFQ |
Part Details for BC817DPN-TP
BC817DPN-TP CAD Models
BC817DPN-TP Part Data Attributes
|
|
BC817DPN-TP
Micro Commercial Components
Buy Now
Datasheet
|
Compare Parts:
BC817DPN-TP
Micro Commercial Components
Small Signal Bipolar Transistor,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | MICRO COMMERCIAL COMPONENTS CORP | |
| Package Description | , | |
| Reach Compliance Code | unknown | |
| ECCN Code | EAR99 | |
| Samacsys Manufacturer | MCC | |
| Collector Current-Max (IC) | 0.5 A | |
| Collector-Base Capacitance-Max | 5 pF | |
| Collector-Emitter Voltage-Max | 45 V | |
| Configuration | SEPARATE, 2 ELEMENTS | |
| DC Current Gain-Min (hFE) | 40 | |
| JESD-30 Code | R-PDSO-G6 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 2 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity/Channel Type | NPN AND PNP | |
| Power Dissipation-Max (Abs) | 0.6 W | |
| Surface Mount | YES | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 10 | |
| Transistor Element Material | SILICON | |
| Transition Frequency-Nom (fT) | 100 MHz | |
| VCEsat-Max | 0.7 V |
Alternate Parts for BC817DPN-TP
This table gives cross-reference parts and alternative options found for BC817DPN-TP. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of BC817DPN-TP, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| BC817DPN-25_R1_00001 | PanJit Semiconductor | Check for Price | Small Signal Bipolar Transistor, | BC817DPN-TP vs BC817DPN-25_R1_00001 |
| BC817DPNF | Nexperia | Check for Price | BC817DPN - NPN/PNP general purpose transistor@en-us TSOP 6-Pin | BC817DPN-TP vs BC817DPNF |
| 934057320115 | Nexperia | Check for Price | Small Signal Bipolar Transistor | BC817DPN-TP vs 934057320115 |
| BC817DPN,125 | NXP Semiconductors | Check for Price | BC817DPN - NPN/PNP general purpose transistor TSOP 6-Pin | BC817DPN-TP vs BC817DPN,125 |
| BC817DPN_R1_00001 | PanJit Semiconductor | Check for Price | Small Signal Bipolar Transistor | BC817DPN-TP vs BC817DPN_R1_00001 |
| BC817DPN,115 | NXP Semiconductors | Check for Price | BC817DPN - NPN/PNP general purpose transistor TSOP 6-Pin | BC817DPN-TP vs BC817DPN,115 |
| BC817DPN | NXP Semiconductors | Check for Price | TRANSISTOR 500 mA, 45 V, 2 CHANNEL, NPN AND PNP, Si, SMALL SIGNAL TRANSISTOR, PLASTIC, SC-74, 6 PIN, BIP General Purpose Small Signal | BC817DPN-TP vs BC817DPN |
| 934057320135 | Nexperia | Check for Price | Small Signal Bipolar Transistor, 0.5A I(C), 45V V(BR)CEO, 2-Element, NPN and PNP, Silicon | BC817DPN-TP vs 934057320135 |
BC817DPN-TP Frequently Asked Questions (FAQ)
-
The recommended storage temperature for BC817DPN-TP is -40°C to 150°C.
-
Yes, BC817DPN-TP is lead-free and RoHS compliant, making it suitable for use in environmentally friendly designs.
-
The maximum power dissipation for BC817DPN-TP is 500 mW, making it suitable for low-power applications.
-
While BC817DPN-TP can be used in high-frequency applications, its performance may degrade above 100 MHz. It's recommended to use a more specialized transistor for high-frequency applications.
-
The typical hFE (current gain) for BC817DPN-TP is 100-400, making it suitable for general-purpose amplification and switching applications.
