BAS21HYT116 Information
BAS21HYT116 by ROHM Semiconductor is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for BAS21HYT116
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
91AH5787
|
Newark | Small Signal Diode, 250V, 0.2A, Sot-23, Diode Configuration:Single, Repetitive Peak Reverse Voltage:250V, Average Forward Current:200Ma, Forward Voltage Max:1.25V, Reverse Recovery Time:50Ns, Forward Surge Current:10A Rohs Compliant: Yes |Rohm BAS21HYT116 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 1815 |
|
$0.0370 | Buy Now |
|
DISTI #
846-BAS21HYT116CT-ND
|
DigiKey | DIODE STANDARD 200V 200MA SOT23 Min Qty: 1 Lead time: 17 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) | Temporarily Out of Stock |
|
$0.0437 / $0.3400 | Buy Now |
|
DISTI #
91AH5787
|
Avnet Americas | Switching Diode 200mA 3-Pin SOT-23 Emboss T/R - Product that comes on tape, but is not reeled (Alt: 91AH5787) RoHS: Not Compliant Min Qty: 1 Package Multiple: 1 Lead time: 24 Weeks, 4 Days Container: Ammo Pack | 5 Partner Stock |
|
$0.1140 / $0.3950 | Buy Now |
|
DISTI #
BAS21HYT116
|
Avnet Americas | Switching Diode 200mA 3-Pin SOT-23 Emboss T/R - Tape and Reel (Alt: BAS21HYT116) RoHS: Not Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 17 Weeks, 0 Days Container: Reel | 0 |
|
RFQ | |
|
DISTI #
755-BAS21HYT116
|
Mouser Electronics | Small Signal Switching Diodes 200V, 200mA, SOT-23, Single, Switching Diode RoHS: Compliant | 3549 |
|
$0.0510 / $0.3400 | Buy Now |
|
DISTI #
65091241
|
Verical | Diode Switching 250V 0.2A 3-Pin SSD T/R RoHS: Compliant Min Qty: 1316 Package Multiple: 1 Date Code: 2101 | Americas - 3000 |
|
$0.0539 / $0.0555 | Buy Now |
|
DISTI #
50585026
|
Verical | Diode Switching 250V 0.2A 3-Pin SSD T/R RoHS: Compliant Min Qty: 363 Package Multiple: 1 Date Code: 2001 | Americas - 364 |
|
$0.2163 | Buy Now |
|
|
Quest Components | 2691 |
|
$0.0990 / $0.3300 | Buy Now | |
|
DISTI #
BAS21HYT116
|
Avnet Asia | Switching Diode 200mA 3-Pin SOT-23 Emboss T/R (Alt: BAS21HYT116) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 24 Weeks, 0 Days | 0 |
|
RFQ | |
|
DISTI #
BAS21HYT116
|
Avnet Silica | Switching Diode 200mA 3Pin SOT23 Emboss TR (Alt: BAS21HYT116) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 29 Weeks, 0 Days | Silica - 0 |
|
Buy Now |
Part Details for BAS21HYT116
BAS21HYT116 CAD Models
BAS21HYT116 Part Data Attributes
|
|
BAS21HYT116
ROHM Semiconductor
Buy Now
Datasheet
|
Compare Parts:
BAS21HYT116
ROHM Semiconductor
Rectifier Diode,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ROHM CO LTD | |
| Package Description | SOT-23, 3 PIN | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.70 | |
| Factory Lead Time | 24 Weeks, 4 Days | |
| Date Of Intro | 2020-06-15 | |
| Samacsys Manufacturer | ROHM Semiconductor | |
| Additional Feature | HIGH RELIABILITY | |
| Application | GENERAL PURPOSE | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | RECTIFIER DIODE | |
| Forward Voltage-Max (VF) | 1.25 V | |
| JESD-30 Code | R-PDSO-G3 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Pk Forward Current-Max | 2 A | |
| Number of Elements | 1 | |
| Number of Phases | 1 | |
| Number of Terminals | 3 | |
| Operating Temperature-Max | 150 °C | |
| Output Current-Max | 0.2 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Power Dissipation-Max | 0.25 W | |
| Rep Pk Reverse Voltage-Max | 250 V | |
| Reverse Current-Max | 0.1 µA | |
| Reverse Recovery Time-Max | 0.05 µs | |
| Reverse Test Voltage | 200 V | |
| Surface Mount | YES | |
| Terminal Finish | Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 |
