B88069X1023T203 Information
B88069X1023T203 by TDK Corporation is a Telecom Protection Circuit.
Telecom Protection Circuits are under the broader part category of Telecommunication Circuits.
A telecommunications circuit transmits and receives information between points. Key components include transmitters, receivers, amplifiers, and multiplexers. Read more about Telecommunication Circuits on our Telecommunication Circuits part category page.
Part Details for B88069X1023T203
B88069X1023T203 CAD Models
B88069X1023T203 Part Data Attributes
|
|
B88069X1023T203
TDK Corporation
Buy Now
Datasheet
|
Compare Parts:
B88069X1023T203
TDK Corporation
Surge Protection Circuit, ROHS COMPLIANT, PACKAGE-2
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TDK CORP | |
| Package Description | PACKAGE-2 | |
| Reach Compliance Code | compliant | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | TDK | |
| JESD-30 Code | R-XDSO-N2 | |
| Length | 4.5 mm | |
| Number of Functions | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 90 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | UNSPECIFIED | |
| Package Code | SON | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Seated Height-Max | 3.5 mm | |
| Surface Mount | YES | |
| Telecom IC Type | GAS DISCHARGE TUBE SUPPRESSOR | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Form | NO LEAD | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Width | 2.7 mm |
