B80C1500B Information
B80C1500B by Diotec Semiconductor AG is a Bridge Rectifier Diode.
Bridge Rectifier Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for B80C1500B
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
4878-B80C1500B-ND
|
DigiKey | BRIDGE RECT 1P 160V 1.8A 4-SIP Min Qty: 1 Lead time: 2 Weeks Container: Box |
371 In Stock |
|
$0.5193 / $1.7400 | Buy Now |
|
DISTI #
637-B80C1500B
|
Mouser Electronics | Bridge Rectifiers Bridge, single phase, GBS_SIL-1.5-2.3, 160V, 2.3A, 150C RoHS: Compliant | 137 |
|
$0.5370 / $1.7400 | Buy Now |
|
|
Onlinecomponents.com | Bridge - Single Phase - GBS_SIL-1.5-2.3 - 160V - 2.3A RoHS: Compliant | 7500 Factory Stock |
|
$0.3947 / $0.5990 | Buy Now |
|
DISTI #
87344582
|
Verical | Diode Rectifier Bridge Single 160V 2.5A 4-Pin Box Min Qty: 62 Package Multiple: 1 | Americas - 1009 |
|
$0.6538 / $1.1466 | Buy Now |
|
DISTI #
88080823
|
Verical | Diode Rectifier Bridge Single 160V 2.5A 4-Pin Box Min Qty: 120 Package Multiple: 1 | Americas - 440 |
|
$0.8051 | Buy Now |
|
DISTI #
B80C1500B-DIO
|
TME | Bridge rectifier: single-phase, Urmax: 160V, If: 1.5A, Ifsm: 50A Min Qty: 1 | 570 |
|
$0.4740 / $0.9680 | Buy Now |
|
|
ComSIT USA | Bridge Rectifier Diode, 1.5A, 160V V(RRM) ECCN: EAR99 RoHS: Compliant |
|
|
RFQ | |
|
|
Master Electronics | Bridge - Single Phase - GBS_SIL-1.5-2.3 - 160V - 2.3A RoHS: Compliant | 7500 Factory Stock |
|
$0.3947 / $0.5990 | Buy Now |
|
|
New Advantage Corporation | Bridge Rectifier 2,3A/160V SIL w+w- RoHS: Compliant Min Qty: 1 Package Multiple: 1 | 352 |
|
$0.7384 / $0.7999 | Buy Now |
Part Details for B80C1500B
B80C1500B CAD Models
B80C1500B Part Data Attributes
|
|
B80C1500B
Diotec Semiconductor AG
Buy Now
Datasheet
|
Compare Parts:
B80C1500B
Diotec Semiconductor AG
Bridge Rectifier Diode, 1.5A, 160V V(RRM),
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | DIOTEC SEMICONDUCTOR AG | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Samacsys Manufacturer | Diotec | |
| Configuration | BRIDGE, 4 ELEMENTS | |
| Diode Type | BRIDGE RECTIFIER DIODE | |
| Forward Voltage-Max (VF) | 1.1 V | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Pk Forward Current-Max | 50 A | |
| Number of Elements | 4 | |
| Number of Phases | 1 | |
| Operating Temperature-Max | 150 °C | |
| Output Current-Max | 1.5 A | |
| Peak Reflow Temperature (Cel) | 260 | |
| Rep Pk Reverse Voltage-Max | 160 V | |
| Surface Mount | NO |
B80C1500B Frequently Asked Questions (FAQ)
-
The recommended operating temperature range for the B80C1500B is -40°C to 150°C.
-
To ensure reliability, it's essential to follow the recommended derating curves for voltage and current, and to provide adequate heat sinking and thermal management.
-
The maximum allowable power dissipation for the B80C1500B is 150W, but this can be affected by factors such as ambient temperature, heat sinking, and thermal resistance.
-
Yes, the B80C1500B can be used in switching regulator applications, but it's essential to ensure that the device is operated within its safe operating area (SOA) and that the switching frequency is within the recommended range.
-
To protect the B80C1500B from EOS, it's essential to use proper circuit protection devices such as TVS diodes, and to follow recommended PCB layout and design practices to minimize the risk of electrical overstress.
