B10B-PHDSS-B(LF)(SN) by: JST Manufacturing

Board Connector, 10 Contact(s), 1 Row(s), Male, Straight, Solder Terminal, ROHS COMPLIANT

Part Details for B10B-PHDSS-B(LF)(SN) by JST Manufacturing

Results Overview of B10B-PHDSS-B(LF)(SN) by JST Manufacturing

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

B10B-PHDSS-B(LF)(SN) Information

B10B-PHDSS-B(LF)(SN) by JST Manufacturing is a Header and Edge Type Connector.
Headers and Edge Type Connectors are under the broader part category of Connectors.

Connectors are devices that join electrical termination points to form circuits. With various types designed for specific functions like data, power, or signal transmission, choosing the right connector is essential for compatibility and device performance. Read more about Connectors on our Connectors part category page.

Price & Stock for B10B-PHDSS-B(LF)(SN)

Part # Distributor Description Stock Price Buy
DISTI # 306-B10BPHDSSBLFSN
Mouser Electronics Headers & Wire Housings PHD HEADER (TOP) RoHS: Compliant 0
  • 1 $0.4400
  • 10 $0.3820
  • 25 $0.3360
  • 100 $0.2970
  • 250 $0.2600
  • 1,000 $0.2150
  • 2,500 $0.2040
  • 10,000 $0.1850
  • 20,000 $0.1760
$0.1760 / $0.4400 Order Now
DISTI # 50330009
Verical Conn Shrouded Header (4 Sides) HDR 10 POS 2mm Solder ST Thru-Hole Box RoHS: Compliant Min Qty: 211 Package Multiple: 1 Americas - 1053
  • 211 $0.2370
  • 500 $0.1920
  • 1,000 $0.1800
$0.1800 / $0.2370 Buy Now
DISTI # 62311484
Verical Conn Shrouded Header (4 Sides) HDR 10 POS 2mm Solder ST Thru-Hole Box RoHS: Compliant Min Qty: 37 Package Multiple: 1 Date Code: 2219 Americas - 468
  • 37 $0.2573
  • 100 $0.2548
  • 500 $0.2468
  • 1,000 $0.2371
$0.2371 / $0.2573 Buy Now
DISTI # B10B-PHDSS-B(LF)(SN)
IBS Electronics CONN SHROUDED HEADER HDR 10 POS 2MM SOLDER ST THRU-HOLE BOX Min Qty: 1000 Package Multiple: 1 0
  • 1,000 $0.2561
  • 1,500 $0.2509
  • 2,000 $0.2496
  • 5,000 $0.2444
  • 7,500 $0.2405
$0.2405 / $0.2561 Buy Now
LCSC 2x5P 10P PHD Tin 2mm 5 -25+85 3A 2 2mm Copper alloy Straight PluginP2mm Wire To Board Connector ROHS 60250
  • 5 $0.3015
  • 50 $0.2408
  • 150 $0.2148
  • 500 $0.1824
  • 2,500 $0.1680
  • 5,000 $0.1593
$0.1593 / $0.3015 Buy Now

Part Details for B10B-PHDSS-B(LF)(SN)

B10B-PHDSS-B(LF)(SN) CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

B10B-PHDSS-B(LF)(SN) Part Data Attributes

Parametric Data
B10B-PHDSS-B(LF)(SN) JST Manufacturing
Buy Now Datasheet
Compare Parts:
B10B-PHDSS-B(LF)(SN) JST Manufacturing Board Connector, 10 Contact(s), 1 Row(s), Male, Straight, Solder Terminal, ROHS COMPLIANT
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer J S T MFG CO LTD
Package Description ROHS COMPLIANT
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8536.69.40.40
Samacsys Manufacturer JST (JAPAN SOLDERLESS TERMINALS)
Additional Feature TOP ENTRY, LOW PROFILE
Connector Type BOARD CONNECTOR
Contact Finish Mating TIN OVER COPPER
Contact Finish Termination TIN
Contact Gender MALE
Contact Material COPPER ALLOY
DIN Conformance NO
Filter Feature NO
IEC Conformance NO
JESD-609 Code e3
MIL Conformance NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts NO
Mounting Style STRAIGHT
Mounting Type BOARD
Number Of Connectors ONE
Number of Rows Loaded 1
Option GENERAL PURPOSE
Terminal Pitch 2 mm
Termination Type SOLDER
Total Number of Contacts 10
UL Flammability Code 94V-0
