Part Details for ATSAM4S2AB-AN by Microchip Technology Inc

Results Overview of ATSAM4S2AB-AN by Microchip Technology Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Internet of Things (IoT) Smart Cities

ATSAM4S2AB-AN Information

ATSAM4S2AB-AN by Microchip Technology Inc is a Microcontroller.
Microcontrollers are under the broader part category of Microcontrollers and Processors.

Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.

Price & Stock for ATSAM4S2AB-AN

Part # Distributor Description Stock Price Buy
DISTI # 33AC1736
Newark Mcu, 32Bit, 120Mhz, Lqfp-48, Product Range:Sam 32 Family Sam 4S Series Microcontrollers, Device Core:Arm Cortex-M4, Data Bus Width:32 Bit, Operating Frequency Max:120Mhz, Program Memory Size:128Kb, No. Of Pins:48Pins, Qualification:-Rohs Compliant: Yes |Microchip ATSAM4S2AB-AN RoHS: Compliant Min Qty: 250 Package Multiple: 1 Date Code: 0 Container: Bulk 0
  • 100 $3.4300
$3.4300 Buy Now
DISTI # ATSAM4S2AB-AN-ND
DigiKey IC MCU 32BIT 128KB FLASH 48LQFP Min Qty: 1 Lead time: 7 Weeks Container: Tray 300
In Stock
  • 1 $4.0300
  • 25 $3.6800
  • 100 $3.3300
$3.3300 / $4.0300 Buy Now
DISTI # ATSAM4S2AB-AN
Avnet Americas ARM MCU, SAM32 Family SAM 4S Series Microcontrollers, ARM Cortex-M4, 32 bit, 120 MHz, 128 KB - Trays (Alt: ATSAM4S2AB-AN) RoHS: Not Compliant Min Qty: 250 Package Multiple: 250 Lead time: 7 Weeks, 0 Days Container: Tray 0
  • 250 $3.4168
  • 500 $3.3888
  • 1,000 $3.3604
  • 1,500 $3.3325
  • 2,000 $3.3043
$3.3043 / $3.4168 Buy Now
DISTI # ATSAM4S2AB-AN
Avnet Americas ARM MCU, SAM32 Family SAM 4S Series Microcontrollers, ARM Cortex-M4, 32 bit, 120 MHz, 128 KB - Trays (Alt: ATSAM4S2AB-AN) RoHS: Not Compliant Min Qty: 250 Package Multiple: 250 Lead time: 7 Weeks, 0 Days Container: Tray 0
  • 250 $3.4168
  • 500 $3.3888
  • 1,000 $3.3604
  • 1,500 $3.3325
  • 2,000 $3.3043
$3.3043 / $3.4168 Buy Now
DISTI # 556-ATSAM4S2AB-AN
Mouser Electronics ARM Microcontrollers - MCU LQFP,GREEN,IND TEMP,MRL B RoHS: Compliant 2539
  • 1 $4.0300
  • 25 $3.6800
  • 100 $3.3300
  • 250 $3.3200
$3.3200 / $4.0300 Buy Now
DISTI # ATSAM4S2AB-AN
Microchip Technology Inc LQFP,GREEN,IND TEMP,MRL B, LQFP, Projected EOL: 2044-08-11 COO: China ECCN: 3A991.a.2 RoHS: Compliant Lead time: 7 Weeks, 0 Days Container: Tray 3750

Alternates Available
  • 1 $4.0300
  • 25 $3.6800
  • 100 $3.3300
  • 1,000 $3.0300
  • 5,000 $2.9200
$2.9200 / $4.0300 Buy Now
Onlinecomponents.com MCU - 32-bit ARM Cortex M4 RISC - 128KB Flash - 1.2V/3.3V - 48-Pin LQFP - Tray RoHS: Compliant 3750 Factory Stock
  • 63 $5.0600
  • 125 $3.8300
  • 188 $3.5600
  • 250 $3.4900
$3.4900 / $5.0600 Buy Now
NAC 48LQFP,GREEN,EXT TEMP(105C),MRL B,128K FLASH,64K SRAM - Package: 48 LQFP 7x7x1.4mm TRAY RoHS: Compliant Min Qty: 250 Package Multiple: 250 Container: Tray 0
  • 1 $4.1300
  • 100 $3.7500
  • 500 $3.5100
  • 1,000 $3.4300
$3.4300 / $4.1300 Buy Now
DISTI # ATSAM4S2AB-AN
Avnet Silica ARM MCU SAM32 Family SAM 4S Series Microcontrollers ARM CortexM4 32 bit 120 MHz 128 KB (Alt: ATSAM4S2AB-AN) RoHS: Compliant Min Qty: 250 Package Multiple: 250 Lead time: 9 Weeks, 0 Days Silica - 0
Buy Now
DISTI # ATSAM4S2AB-AN
EBV Elektronik ARM MCU SAM32 Family SAM 4S Series Microcontrollers ARM CortexM4 32 bit 120 MHz 128 KB (Alt: ATSAM4S2AB-AN) RoHS: Compliant Min Qty: 250 Package Multiple: 250 Lead time: 8 Weeks, 0 Days EBV - 0
Buy Now
Master Electronics MCU - 32-bit ARM Cortex M4 RISC - 128KB Flash - 1.2V/3.3V - 48-Pin LQFP - Tray RoHS: Compliant 3750 Factory Stock
  • 63 $5.0600
  • 125 $3.8300
  • 188 $3.5600
  • 250 $3.4900
$3.4900 / $5.0600 Buy Now
Vyrian Peripheral ICs 1935
RFQ

Part Details for ATSAM4S2AB-AN

ATSAM4S2AB-AN CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

ATSAM4S2AB-AN Part Data Attributes

Parametric Data
ATSAM4S2AB-AN Microchip Technology Inc
Buy Now Datasheet
Compare Parts:
ATSAM4S2AB-AN Microchip Technology Inc RISC Microcontroller
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer MICROCHIP TECHNOLOGY INC
Package Description LQFP-48
Reach Compliance Code compliant
ECCN Code 3A991.A.2
HTS Code 8542.31.00.01
Factory Lead Time 7 Weeks
Samacsys Manufacturer Microchip
Has ADC YES
Address Bus Width
Bit Size 32
Boundary Scan YES
CPU Family CORTEX-M4
Clock Frequency-Max 50 MHz
DAC Channels YES
DMA Channels YES
External Data Bus Width
Format FLOATING POINT
Integrated Cache YES
JESD-30 Code S-PQFP-G48
JESD-609 Code e3
Length 7 mm
Low Power Mode YES
Number of DMA Channels 22
Number of I/O Lines 34
Number of Terminals 48
Number of Timers 6
On Chip Data RAM Width 8
On Chip Program ROM Width 8
Operating Temperature-Max 105 °C
Operating Temperature-Min -40 °C
PWM Channels YES
Package Body Material PLASTIC/EPOXY
Package Code LFQFP
Package Shape SQUARE
Package Style FLATPACK, LOW PROFILE, FINE PITCH
RAM (bytes) 65536
RAM (words) 65536
ROM (words) 131072
ROM Programmability FLASH
Seated Height-Max 1.6 mm
Speed 120 MHz
Supply Current-Max 25 mA
Supply Voltage-Max 1.32 V
Supply Voltage-Min 1.2 V
Supply Voltage-Nom 1.2 V
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish Matte Tin (Sn)
Terminal Form GULL WING
Terminal Pitch 0.5 mm
Terminal Position QUAD
Width 7 mm
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
