Part Details for ADUM1285WCRZ-RL7
ADUM1285WCRZ-RL7 CAD Models
ADUM1285WCRZ-RL7 Part Data Attributes
|
|
ADUM1285WCRZ-RL7
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
ADUM1285WCRZ-RL7
Analog Devices Inc
3kV rms, Default Low, Dual-Channel Digital Isolators (2/0 Channel Directionality)
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | SOIC | |
| Package Description | SOIC-8 | |
| Pin Count | 8 | |
| Manufacturer Package Code | R-8 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Interface IC Type | DIGITAL ISOLATOR | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e3 | |
| Length | 4.9 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Equivalence Code | SOP8,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Seated Height-Max | 1.75 mm | |
| Supply Voltage-Max | 5.5 V | |
| Supply Voltage-Min | 3 V | |
| Supply Voltage-Nom | 5 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3.9 mm |
ADUM1285WCRZ-RL7 Frequently Asked Questions (FAQ)
-
The maximum operating temperature range for the ADUM1285WCRZ-RL7 is -40°C to 125°C.
-
Yes, the ADUM1285WCRZ-RL7 is capable of supporting high-speed data transmission up to 150 Mbps.
-
Yes, the ADUM1285WCRZ-RL7 is compatible with industrial standards such as IEC 60601-1, IEC 61010-1, and UL 1577.
-
The typical propagation delay for the ADUM1285WCRZ-RL7 is 10 ns.
-
Yes, the ADUM1285WCRZ-RL7 can be used for isolated power supply applications, providing up to 5000 Vrms of isolation voltage.
