Part Details for ADUM1200BRZ-RL7 by Analog Devices Inc
Results Overview of ADUM1200BRZ-RL7 by Analog Devices Inc
- Distributor Offerings: (15 listings)
- Number of FFF Equivalents: (6 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (10 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Industrial Automation
Energy and Power Systems
Renewable Energy
ADUM1200BRZ-RL7 Information
ADUM1200BRZ-RL7 by Analog Devices Inc is an Other Interface IC.
Other Interface ICs are under the broader part category of Drivers And Interfaces.
A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.
Price & Stock for ADUM1200BRZ-RL7
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
60AK5722
|
Newark | Digital Isolator, 2Ch, -40 To 105Deg C, No. Of Channels:2Channels, Supply Voltage Min:2.7V, Supply Voltage Max:5.5V, Ic Case/Package:Nsoic, No. Of Pins:8Pins, Data Rate:10Mbps, Input Level:Cmos, Output Level:Cmos, Product Range:- Rohs Compliant: Yes |Analog Devices ADUM1200BRZ-RL7 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 2194 |
|
$2.5500 / $5.2000 | Buy Now |
|
DISTI #
ADUM1200BRZ-RL7CT-ND
|
DigiKey | DGTL ISOLTR 2.5KV 2CH GP 8-SOIC Min Qty: 1 Lead time: 39 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
1933 In Stock |
|
$2.3875 / $6.1900 | Buy Now |
|
DISTI #
584-ADUM1200BRZ-R7
|
Mouser Electronics | Digital Isolators DUAL-CHANNEL DIGITAL ISOLATORS RoHS: Compliant | 7469 |
|
$2.6300 / $4.7000 | Buy Now |
|
DISTI #
E54:1762_00115285
|
Arrow Electronics | Digital Isolator CMOS 2-CH 10Mbps 8-Pin SOIC N T/R RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 10 Weeks Date Code: 2509 | Europe - 35000 |
|
$2.2840 | Buy Now |
|
DISTI #
V36:1790_06223496
|
Arrow Electronics | Digital Isolator CMOS 2-CH 10Mbps 8-Pin SOIC N T/R RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 10 Weeks Date Code: 2305 | Americas - 2000 |
|
$2.2840 | Buy Now |
|
DISTI #
V72:2272_06223496
|
Arrow Electronics | Digital Isolator CMOS 2-CH 10Mbps 8-Pin SOIC N T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 10 Weeks Date Code: 2305 Container: Cut Strips | Americas - 1 |
|
$2.5640 | Buy Now |
|
|
Analog Devices Inc | DUAL-CHANNEL DIGITAL ISOLATORS Min Qty: 1000 Package Multiple: 1000 | 3000 |
|
$2.3875 / $6.1900 | Buy Now |
|
DISTI #
86316994
|
Verical | Digital Isolator CMOS 2-CH 10Mbps 8-Pin SOIC N T/R RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 | Americas - 35000 |
|
$2.2840 | Buy Now |
|
DISTI #
67507287
|
Verical | Digital Isolator CMOS 2-CH 10Mbps 8-Pin SOIC N T/R RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Date Code: 2305 | Americas - 2000 |
|
$2.2840 | Buy Now |
|
|
Quest Components | IC,DIGITAL COUPLER,HYBRID,SOP,8PIN,PLASTIC, TandR, LEAD FREE | 8000 |
|
$2.6042 / $5.2083 | Buy Now |
Part Details for ADUM1200BRZ-RL7
ADUM1200BRZ-RL7 CAD Models
ADUM1200BRZ-RL7 Part Data Attributes
|
|
ADUM1200BRZ-RL7
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
ADUM1200BRZ-RL7
Analog Devices Inc
Dual-Channel Digital Isolator (2/0 Channel Directionality)
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | SOIC | |
| Package Description | SOIC-8 | |
| Pin Count | 8 | |
| Manufacturer Package Code | R-8 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Additional Feature | ALSO OPERATES AT 5V NOMINAL SUPPLY | |
| Interface IC Type | DIGITAL ISOLATOR | |
| JESD-30 Code | R-PDSO-G8 | |
| JESD-609 Code | e3 | |
| Length | 4.9 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 2 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 105 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Equivalence Code | SOP8,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.75 mm | |
| Supply Voltage-Max | 5.5 V | |
| Supply Voltage-Min | 2.7 V | |
| Supply Voltage-Nom | 3 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3.9 mm |
Alternate Parts for ADUM1200BRZ-RL7
This table gives cross-reference parts and alternative options found for ADUM1200BRZ-RL7. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of ADUM1200BRZ-RL7, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| ADUM1200BRZ | Analog Devices Inc | $2.8051 | Dual-Channel Digital Isolator (2/0 Channel Directionality) | ADUM1200BRZ-RL7 vs ADUM1200BRZ |
| ADUM3200WBRZ | Analog Devices Inc | $4.3756 | Dual-Channel, Digital Isolator, Enhanced System-Level ESD Reliability | ADUM1200BRZ-RL7 vs ADUM3200WBRZ |
| ADUM1200WT | Analog Devices Inc | Check for Price | ADUM1200WT | ADUM1200BRZ-RL7 vs ADUM1200WT |
| ADUM3200WBRZ-RL7 | Analog Devices Inc | Check for Price | Dual-Channel, Digital Isolator, Enhanced System-Level ESD Reliability | ADUM1200BRZ-RL7 vs ADUM3200WBRZ-RL7 |
| ADUM1200BR-RL7 | Analog Devices Inc | Check for Price | Dual-Channel Digital Isolator (2/0 Channel Directionality) | ADUM1200BRZ-RL7 vs ADUM1200BR-RL7 |
| ISO7220BDG4 | Texas Instruments | Check for Price | Dual-channel, 2/0, 5-Mbps digital isolator 8-SOIC -40 to 125 | ADUM1200BRZ-RL7 vs ISO7220BDG4 |
