ADUC832BSZ-REEL Information
ADUC832BSZ-REEL by Analog Devices Inc is a Microcontroller.
Microcontrollers are under the broader part category of Microcontrollers and Processors.
Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| LMX2325TMX-G | Rochester Electronics LLC | LMX2325 - RoHS - T/R, PLL Freq Synthesizer |
Price & Stock for ADUC832BSZ-REEL
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
ADUC832BSZ-REELCT-ND
|
DigiKey | IC MCU 8BIT 62KB FLASH 52MQFP Min Qty: 1 Lead time: 10 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
2254 In Stock |
|
$17.0000 / $25.9300 | Buy Now |
|
DISTI #
584-ADUC832BSZ-R
|
Mouser Electronics | 8-bit Microcontrollers - MCU 12-bit ADC with Embedded 8-bit MCU RoHS: Compliant | 936 |
|
$17.0000 / $28.7700 | Buy Now |
|
|
Analog Devices Inc | 12-bit ADC with Embedded 8-bit Min Qty: 1 Package Multiple: 800 | 8451 |
|
$12.9100 / $25.9300 | Buy Now |
|
DISTI #
71328393
|
Verical | MCU 8-bit 8052 CISC 62KB Flash 3V/5V 52-Pin MQFP T/R RoHS: Compliant Min Qty: 800 Package Multiple: 800 | Americas - 8000 |
|
$16.8213 | Buy Now |
|
|
Vyrian | Peripheral ICs | 4452 |
|
RFQ |
Part Details for ADUC832BSZ-REEL
ADUC832BSZ-REEL CAD Models
ADUC832BSZ-REEL Part Data Attributes
|
|
ADUC832BSZ-REEL
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
ADUC832BSZ-REEL
Analog Devices Inc
ADUC832BSZ-REEL
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | QFN | |
| Package Description | LFCSP-56 | |
| Pin Count | 52 | |
| Manufacturer Package Code | S-52-2 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.31.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Has ADC | YES | |
| Additional Feature | ALSO OPERATES AT 5V SUPPLY | |
| Address Bus Width | 24 | |
| Bit Size | 8 | |
| Clock Frequency-Max | 16.78 MHz | |
| DAC Channels | YES | |
| DMA Channels | YES | |
| External Data Bus Width | 8 | |
| JESD-30 Code | S-PQCC-N56 | |
| JESD-609 Code | e3 | |
| Length | 8 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of I/O Lines | 32 | |
| Number of Terminals | 56 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| PWM Channels | YES | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HVQCCN | |
| Package Shape | SQUARE | |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| ROM Programmability | FLASH | |
| Seated Height-Max | 1 mm | |
| Speed | 16.78 MHz | |
| Supply Voltage-Max | 3.3 V | |
| Supply Voltage-Min | 2.7 V | |
| Supply Voltage-Nom | 3 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 40 | |
| Width | 8 mm | |
| uPs/uCs/Peripheral ICs Type | MICROCONTROLLER |
Alternate Parts for ADUC832BSZ-REEL
This table gives cross-reference parts and alternative options found for ADUC832BSZ-REEL. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of ADUC832BSZ-REEL, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| ADUC831BSZ | Analog Devices Inc | $20.5571 | MicroConverter®, 12-Bit ADCs and DACs with Embedded 62 kBytes Flash MCU | ADUC832BSZ-REEL vs ADUC831BSZ |
| ADUC842BSZ62-5 | Analog Devices Inc | $24.5357 | ADUC842BSZ62-5 | ADUC832BSZ-REEL vs ADUC842BSZ62-5 |
| ADUC841BS | Analog Devices Inc | Check for Price | IC 8-BIT, FLASH, 25 MHz, MICROCONTROLLER, PQFP52, PLASTIC, QFP-52, Microcontroller | ADUC832BSZ-REEL vs ADUC841BS |
| ADUC841BCP8-5 | Analog Devices Inc | Check for Price | IC 8-BIT, FLASH, 20 MHz, MICROCONTROLLER, QCC56, 8 X 8 MM, LEAD FRAME, MO-220VLLD2, CSP-56, Microcontroller | ADUC832BSZ-REEL vs ADUC841BCP8-5 |
| ADUC843BCP8-3 | Analog Devices Inc | Check for Price | IC 8-BIT, FLASH, 8.38 MHz, MICROCONTROLLER, QCC56, 8 X 8 MM, LEAD FRAME, MO-220VLLD2, CSP-56, Microcontroller | ADUC832BSZ-REEL vs ADUC843BCP8-3 |
| ADUC841BCPZ62-3 | Analog Devices Inc | Check for Price | ADUC841BCPZ62-3 | ADUC832BSZ-REEL vs ADUC841BCPZ62-3 |
| ADUC831BS | Analog Devices Inc | Check for Price | IC 8-BIT, FLASH, 16.78 MHz, MICROCONTROLLER, PQFP52, PLASTIC, MQFP-52, Microcontroller | ADUC832BSZ-REEL vs ADUC831BS |
| ADUC843BCP32-3 | Analog Devices Inc | Check for Price | IC 8-BIT, FLASH, 8.38 MHz, MICROCONTROLLER, QCC56, 8 X 8 MM, LEAD FRAME, MO-220VLLD2, CSP-56, Microcontroller | ADUC832BSZ-REEL vs ADUC843BCP32-3 |
| ADUC841BCP | Analog Devices Inc | Check for Price | IC 8-BIT, FLASH, 25 MHz, MICROCONTROLLER, QCC56, 8 X 8 MM, CSP-56, Microcontroller | ADUC832BSZ-REEL vs ADUC841BCP |
| ADUC842BCP32-5 | Analog Devices Inc | Check for Price | IC 8-BIT, FLASH, 16.78 MHz, MICROCONTROLLER, QCC56, 8 X 8 MM, LEAD FRAME, MO-220VLLD2, CSP-56, Microcontroller | ADUC832BSZ-REEL vs ADUC842BCP32-5 |
