ADUC7024BSTZ62 Information
ADUC7024BSTZ62 by Analog Devices Inc is a Microcontroller.
Microcontrollers are under the broader part category of Microcontrollers and Processors.
Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.
Price & Stock for ADUC7024BSTZ62
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
49AK8956
|
Newark | Arm Mcu, 41.78Mhz, 30I/O, Lqfp-64, Product Range:Aduc Family Aduc7 Series Microcontrollers, Device Core:-, Data Bus Width:32 Bit, Operating Frequency Max:41.78Mhz, Program Memory Size:62Kb, No. Of Pins:64Pins, Ic Case/Package:Lqfp Rohs Compliant: Yes |Analog Devices ADUC7024BSTZ62 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 239 |
|
$12.1100 / $17.8400 | Buy Now |
|
DISTI #
ADUC7024BSTZ62-ND
|
DigiKey | IC MCU 16/32BIT 62KB FLSH 64LQFP Min Qty: 1 Lead time: 10 Weeks Container: Tray |
485 In Stock |
|
$11.7714 / $17.8400 | Buy Now |
|
DISTI #
584-ADUC7024BSTZ62
|
Mouser Electronics | ARM Microcontrollers - MCU Flash ARM7+10-ch,12-B ADC &2x12-B DAC IC RoHS: Compliant | 266 |
|
$11.2800 / $21.0000 | Buy Now |
|
|
Analog Devices Inc | Flash ARM7+10-ch,12-B ADC &2x1 Package Multiple: 1 | 97 |
|
$8.5800 / $17.8400 | Buy Now |
|
|
Rochester Electronics | 12-Bit Analog I/OARM7TDMI MCU RoHS: Compliant Status: Active Min Qty: 1 | 8 |
|
$9.5000 / $11.8800 | Buy Now |
|
|
LCSC | LQFP-64 Microcontrollers (MCU/MPU/SOC) ROHS | 5 |
|
$26.7644 / $28.2793 | Buy Now |
Part Details for ADUC7024BSTZ62
ADUC7024BSTZ62 CAD Models
ADUC7024BSTZ62 Part Data Attributes
|
|
ADUC7024BSTZ62
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
ADUC7024BSTZ62
Analog Devices Inc
Precision Analog Microcontroller, 12-Bit Analog I/O, ARM7TDMI® MCU
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | QFP | |
| Package Description | LQFP-64 | |
| Pin Count | 64 | |
| Manufacturer Package Code | ST-64-2 | |
| Reach Compliance Code | compliant | |
| ECCN Code | 5A991.B | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Has ADC | YES | |
| Address Bus Width | ||
| Bit Size | 32 | |
| CPU Family | ARM7 | |
| Clock Frequency-Max | 44 MHz | |
| DAC Channels | YES | |
| DMA Channels | NO | |
| External Data Bus Width | ||
| JESD-30 Code | S-PQFP-G64 | |
| JESD-609 Code | e3 | |
| Length | 10 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of I/O Lines | 31 | |
| Number of Terminals | 64 | |
| On Chip Program ROM Width | 8 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| PWM Channels | YES | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | LFQFP | |
| Package Equivalence Code | QFP64,.47SQ,20 | |
| Package Shape | SQUARE | |
| Package Style | FLATPACK, LOW PROFILE, FINE PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| RAM (bytes) | 8192 | |
| ROM (words) | 63488 | |
| ROM Programmability | FLASH | |
| Seated Height-Max | 1.6 mm | |
| Speed | 41.78 MHz | |
| Supply Current-Max | 50 mA | |
| Supply Voltage-Max | 3.6 V | |
| Supply Voltage-Min | 2.7 V | |
| Supply Voltage-Nom | 3 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Width | 10 mm | |
| uPs/uCs/Peripheral ICs Type | MICROCONTROLLER, RISC |
