ADP1043AACPZ-RL Information
ADP1043AACPZ-RL by Analog Devices Inc is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for ADP1043AACPZ-RL
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
2156-ADP1043AACPZ-RL-ND
|
DigiKey | IC SECONDARY SIDE CTRLR 32LFCSP Min Qty: 39 Lead time: 10 Weeks Container: Bulk MARKETPLACE PRODUCT |
6246 In Stock |
|
$7.8500 | Buy Now |
|
DISTI #
ADP1043AACPZ-RLTR-ND
|
DigiKey | IC SECONDARY SIDE CTRLR 32LFCSP Min Qty: 39 Lead time: 10 Weeks Container: Tape & Reel (TR) | Temporarily Out of Stock |
|
$7.1875 | Buy Now |
|
DISTI #
584-ADP1043AACPZ-R
|
Mouser Electronics | Switching Controllers 32 ld LFCSP (5x5mm CP-32-2) RoHS: Compliant | 0 |
|
$7.1800 | Order Now |
|
|
Analog Devices Inc | 32 ld LFCSP (5x5mm CP-32-2) Min Qty: 5000 Package Multiple: 5000 | 0 |
|
$5.4600 / $14.8800 | Buy Now |
Part Details for ADP1043AACPZ-RL
ADP1043AACPZ-RL CAD Models
ADP1043AACPZ-RL Part Data Attributes
|
|
ADP1043AACPZ-RL
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
ADP1043AACPZ-RL
Analog Devices Inc
Digital Controller for Isolated Power Supply Applications
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Not Recommended | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | QFN | |
| Package Description | LFCSP-32 | |
| Pin Count | 32 | |
| Manufacturer Package Code | CP-32-7 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Analog IC - Other Type | SWITCHING CONTROLLER | |
| Control Mode | CURRENT-MODE | |
| Control Technique | PULSE WIDTH MODULATION | |
| Input Voltage-Max | 3.6 V | |
| Input Voltage-Min | 3.1 V | |
| Input Voltage-Nom | 3.3 V | |
| JESD-30 Code | S-PQCC-N32 | |
| JESD-609 Code | e3 | |
| Length | 5 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 1 | |
| Number of Terminals | 32 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HVQCCN | |
| Package Equivalence Code | LCC32,.2SQ,20 | |
| Package Shape | SQUARE | |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1 mm | |
| Supply Voltage-Nom (Vsup) | 3.3 V | |
| Surface Mount | YES | |
| Switcher Configuration | SINGLE | |
| Switching Frequency-Max | 210 kHz | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 5 mm |
