ADN8102ACPZ-R7 Information
ADN8102ACPZ-R7 by Analog Devices Inc is an Other Signal Circuit.
Other Signal Circuits are under the broader part category of Signal Circuits.
A signal is an electronic means of transmitting information, either as an analog signal with continuous values or a digital signal with discrete values. Signals are used in various systems and networks. Read more about Signal Circuits on our Signal Circuits part category page.
Price & Stock for ADN8102ACPZ-R7
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
2156-ADN8102ACPZ-R7-ND
|
DigiKey | IC INTERFACE SPECIALIZED 64LFCSP Min Qty: 11 Lead time: 10 Weeks Container: Bulk MARKETPLACE PRODUCT |
750 In Stock |
|
$29.0200 | Buy Now |
|
DISTI #
ADN8102ACPZ-R7TR-ND
|
DigiKey | IC INTERFACE SPECIALIZED 64LFCSP Min Qty: 11 Lead time: 10 Weeks Container: Tape & Reel (TR) | Temporarily Out of Stock |
|
$26.5750 | Buy Now |
|
DISTI #
584-ADN8102ACPZ-R7
|
Mouser Electronics | Equalizers X-stream 3.75 Gbps Quad Bidirectional CX4 Equalizer RoHS: Compliant | 0 |
|
$26.5700 | Order Now |
|
|
Analog Devices Inc | Quad Bidirectional Cable Equal Min Qty: 750 Package Multiple: 750 | 0 |
|
$19.3300 / $42.3400 | Buy Now |
|
|
Rochester Electronics | ADN8102 - 3.75 GBPS Quad Bi-Directional CX4 Equalizer RoHS: Compliant Status: Active Min Qty: 1 | 750 |
|
$22.3800 / $27.9700 | Buy Now |
Part Details for ADN8102ACPZ-R7
ADN8102ACPZ-R7 CAD Models
ADN8102ACPZ-R7 Part Data Attributes
|
|
ADN8102ACPZ-R7
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
ADN8102ACPZ-R7
Analog Devices Inc
X-stream™ 3.75 Gbps Quad Bidirectional CX4 Equalizer
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Not Recommended | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Part Package Code | QFN | |
| Package Description | 9 X 9 MM, ROHS COMPLIANT, MO-220VMMD-4, LFCSP-64 | |
| Pin Count | 64 | |
| Manufacturer Package Code | CP-64-2 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Analog Devices | |
| Analog IC - Other Type | ANALOG CIRCUIT | |
| JESD-30 Code | S-XQCC-N64 | |
| JESD-609 Code | e3 | |
| Length | 9 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 1 | |
| Number of Terminals | 64 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | UNSPECIFIED | |
| Package Code | HVQCCN | |
| Package Equivalence Code | LCC64,.35SQ,20 | |
| Package Shape | SQUARE | |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1 mm | |
| Supply Voltage-Max (Vsup) | 3.6 V | |
| Supply Voltage-Min (Vsup) | 1.7 V | |
| Supply Voltage-Nom (Vsup) | 1.8 V | |
| Surface Mount | YES | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 9 mm |
